Ford New Holland TR96 Combine Parts
Browse Ford New Holland TR96 Combine replacement parts. Everything from routine maintenance items to hard-to-find components.
The Ford New Holland TR96, produced from 1986 to 1997, was a popular combine known for its Twin Rotor design, offering efficient grain separation. With engine horsepower ranging around 240 HP, the TR96 handled various header widths effectively. Farmers appreciated its robust design and ability to handle high-yielding crops, making it a reliable workhorse in the field.
About the TR96
The Ford New Holland TR96 was introduced in 1986 and remained in production until 1997, becoming a staple on many farms. Powering the TR96 was a Ford 6.6L (401 CID) turbocharged diesel engine producing approximately 240 horsepower. The TR96 employed a unique Twin Rotor separation system, providing increased threshing capacity and reduced grain loss compared to conventional combines. Its grain tank held approximately 225 bushels, and the unloading auger could empty the tank at a rate of around 80 bushels per minute. Available header widths ranged from 15 to 30 feet, allowing for versatile harvesting. Options included straw choppers and spreaders for residue management. The cab offered improved operator comfort and visibility. The TR96 was particularly well-suited for harvesting wheat, corn, and soybeans, demonstrating its versatility across different grain crops.
TR96 Specifications
| Engine | Ford 6.6L (401 CID) 240 HP Turbocharged Diesel |
|---|---|
| Separator Type | Twin Rotor - Two 17 inch diameter rotors |
| Grain Tank | 225 bushels |
| Unloading Rate | 80 bu/min |
| Header Widths | 15-30 ft |
| Fuel Capacity | 135 gallons |
| Weight | 23,500 lbs |
| Years Produced | 1986-1997 |
TR96 Maintenance Tips
- Concave Adjustment: Regularly check and adjust concave clearance according to the crop being harvested to optimize threshing efficiency and minimize grain damage.
- Belt and Chain Tension: Inspect all belts and chains for proper tension and wear. Replace worn components promptly to prevent breakdowns during harvest.
- Sieve and Chaffer Cleaning: Clean the sieves and chaffer frequently to remove debris and ensure proper grain cleaning. A clogged cleaning system reduces harvest efficiency and increases grain loss.
- Bearing Greasing: Grease all bearings according to the manufacturer's recommendations. Proper lubrication extends bearing life and prevents costly repairs.
TR96 History & Background
The Ford New Holland TR96 was a significant advancement in combine technology, building upon the success of earlier TR series models. Its Twin Rotor design offered improved threshing and separation capabilities. It cemented Ford New Holland's position as a leading manufacturer of harvesting equipment during its production run.
Frequently Asked Questions
Which A/C compressor is recommended for the Ford New Holland TR96 combine?
The D6NN19D623A - Compressor, w/o Clutch is a suitable replacement for the A/C system on your TR96 combine. This model features a LH Suction and Rotoloc Head.
What fuel filter is compatible with the Ford New Holland TR96?
For the Ford New Holland TR96, the FF185 - Filter, Fuel is a primary spin-on fuel filter designed for this model.
Which rasp bar fits the LH rotor of the Ford New Holland TR96?
The 9800347 - Rasp Bar is designed for the LH rotor (trailing position) on the TR96. It is sold as a set of two.
What are some essential replacement parts for the Ford New Holland TR96 combine?
Key replacement parts for the TR96 combine include the 86514256 - Belt, Unload Auger, 86548970 - Bearing, Flange, 87639816 - Clutch, Jaw, 9672301 - Filter, Coolant, and the 9807217 - Blower Motor. Additionally, the 84000052 - Bushing, Rubber; Shaker Shoe is also a common wear item.

86610859 - Rotor; High Speed Belt
SKU: 86610859
3 in stock

86537318 - Drive 193" Belt
SKU: 86537318
9 in stock

86514256 - Unload Auger Belt
SKU: 86514256
235 in stock

80259346 - A/C Compressor Belt
SKU: 80259346
221 in stock

626657 - AC Compressor / Alternator Belt
SKU: 626657
59 in stock

574844 - ADAPTOR BEARING
SKU: 574844
873 in stock

48198 - BEARING
SKU: 48198
222 in stock

168636 - ADAPTOR BEARING
SKU: 168636
873 in stock

C5NN13N359E - Warning Lamp / Turn Signal (12 Volt)
SKU: C5NN13N359E
96 in stock

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED
SKU: 9703399-LED
288 in stock

130609 - AMBER FL LIGHT
SKU: 130609
96 in stock

904-022 - (1lb) 7/32 x 5/8" OH Rivet
SKU: 904-022
Out of stock

801-432 - Bolt-On Chrome 11ga Top Serrated 10' (RH)
SKU: 801-432
Out of stock
606657 - CRRG BOLT 7/16-14 X 1-1/2
SKU: 606657
320 in stock

606656 - CRRG BOLT 7/16-14 X 1-1/4
SKU: 606656
525 in stock

211-012 - Heavy Smooth Black
SKU: 211-012
250 in stock

V70267 - Expansion Valve
SKU: V70267
339 in stock

V56662 - 3sp) Rev rotation 3/8" X 4 1/4" shaft Blower Motor (4 wire) (12volt
SKU: V56662
47 in stock

V35513 - Sub To BM333812
SKU: V35513
47 in stock

V31505 - Sub To 220-256
SKU: V31505
73 in stock

V18380 - 3sp) Rev rotation 3/8" X 4 1/4" shaft Blower Motor (4 wire) (12volt
SKU: V18380
47 in stock

V103596 - 3sp) Rev rotation 3/8" X 4 1/4" shaft Blower Motor (4 wire) (12volt
SKU: V103596
47 in stock

KB402009 - York w/o Clutch (ER-210-L LH Suction Rotolock Head) New Compressor
SKU: KB402009
18 in stock

E5NN18527AA - 3sp) Rev rotation 3/8" X 4 1/4" shaft Blower Motor (4 wire) (12volt
SKU: E5NN18527AA
47 in stock
