John Deere 9560 Combine Parts
John Deere 9560 Combine parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The John Deere 9560 combine, manufactured from 2003 to 2006, was a popular choice for farmers needing a dependable grain harvesting solution. Powered by a John Deere PowerTech engine pushing around 265 HP, and available with header widths up to 30 feet, this conventional combine was known for its robust performance and ease of operation. Farmers appreciated its balance of power and simplicity.
About the 9560
The John Deere 9560 combine was introduced in 2003 as part of the '60 Series' and remained in production until 2006. It features a John Deere PowerTech 6.8L engine, delivering approximately 265 horsepower (198 kW) with a displacement of 414 cubic inches. The 9560 utilizes a conventional threshing system with a 59-inch wide cylinder, known for its effective grain separation and gentle handling of crops like wheat and soybeans. Its grain tank holds around 220 bushels, and the unloading auger provides a discharge rate of approximately 2.1 bushels per second (126 bu/min), ensuring efficient unloading. Available header widths ranged up to 30 feet, accommodating various field sizes and harvesting requirements. The 9560 offered options for chopper and spreader attachments to manage crop residue. The cab provided a comfortable working environment with features like air conditioning and adjustable seating. This model excelled in harvesting grains like wheat, soybeans, and corn, offering a reliable and efficient harvesting solution for many farmers.
9560 Specifications
| Engine | John Deere PowerTech 265 HP 6.8L Diesel |
|---|---|
| Separator Type | Conventional - 59-inch wide cylinder |
| Grain Tank | 220 bushels |
| Unloading Rate | 126 bu/min |
| Header Widths | Up to 30 ft |
| Fuel Capacity | 150 gallons |
| Weight | Approximately 24,000 lbs |
| Years Produced | 2003-2006 |
9560 Maintenance Tips
- Concave Adjustment: Regularly check and adjust the concave clearance to ensure proper threshing and minimize grain loss. Refer to the operator's manual for recommended settings based on the crop being harvested.
- Belt and Chain Tension: Inspect and maintain proper tension on all belts and chains to prevent slippage and premature wear. Loose belts and chains can lead to inefficient operation and potential damage.
- Sieve and Chaffer Cleaning: Regularly clean the sieves and chaffer to remove debris and ensure proper airflow for efficient grain separation. Clogged sieves can result in grain loss over the back.
- Bearing Greasing: Follow the recommended greasing schedule for all bearings to ensure proper lubrication and prevent premature failure. Use high-quality grease specifically designed for agricultural equipment.
9560 History & Background
The John Deere 9560 was introduced in 2003 as part of the '60 Series' combines, offering an updated design and improved performance compared to its predecessors. While it didn't undergo major redesigns during its production run, it represented a significant step in combine technology for John Deere's conventional combine offerings. It provided a reliable option for farmers needing a mid-sized combine with proven performance.
Frequently Asked Questions
Which main bearing is suitable for the John Deere 9560 engine?
For the John Deere 9560, the RE529319 - Main Bearing, Std. is a suitable replacement for the engine.
What bearing is used in the feeder drum assembly on the John Deere 9560?
The AH219987 - Bearing w/ Housing; Feeder Drum (Import) is a commonly used replacement for the feeder drum on the John Deere 9560.
Which stationary straw chopper blade fits the John Deere 9560?
For the straw chopper on the John Deere 9560, consider the H215004 - Blade, Straw Chopper, Stationary.
What are common replacement parts for the John Deere 9560 combine?
Key replacement parts for the John Deere 9560 include the AH206756 - Concave Insert - C/W Spring, Pin, Roll Pin & Washer, H144667 - Paddle, Elevator Chain, H165407 - Wear Plate, Front Beater, JD9459 - Bearing, Fan Driver Jackshaft, and the VPK1551 - Hydraulic Filter.

T20328 - Oil Filler Cap Gasket
SKU: T20328
48 in stock

RE64509 - High Compression Piston Piston Liner Kit
SKU: RE64509
60 in stock

RE527832 - Upper Gasket Set
SKU: RE527832
17 in stock

RE524529 - Fuel Injection Pump Pressure Relief Valve
SKU: RE524529
82 in stock

RE521756 - Engine Oil Pump
SKU: RE521756
16 in stock

RE520036 - Rear Crankshaft Seal
SKU: RE520036
236 in stock

RE519115 - Valve; Intake/Exhaust Seal
SKU: RE519115
290 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

T20006 - Exhaust Manifold Gasket
SKU: T20006
834 in stock

T122075 - Oil Cooler (2 PK) O-Ring
SKU: T122075
43 in stock

RE69243 - Engine Oil Dipstick
SKU: RE69243
217 in stock

RE65912 - Thrust (.010") Bearing
SKU: RE65912
73 in stock

RE65911 - Main (.010") Bearing
SKU: RE65911
721 in stock

RE65909 - Connecting Rod (.010") Bearing
SKU: RE65909
79 in stock

RE65908B - Connecting Rod (.020") Bearing
SKU: RE65908B
8 in stock

RE65908 - Connecting Rod (Std) Bearing
SKU: RE65908
7182 in stock

RE65168B - Thrust (.020") Bearing
SKU: RE65168B
14 in stock

RE65168 - Thrust (Std) Bearing
SKU: RE65168
627 in stock

RE65165 - Main (Std) Bearing
SKU: RE65165
6921 in stock

RE62777 - Exhaust Manifold; Outer (2/Pack) Gasket
SKU: RE62777
896 in stock

RE62776 - Exhaust Manifold; Inner Gasket
SKU: RE62776
1106 in stock

RE61812 - Air Intake Temperature Sensor
SKU: RE61812
138 in stock
