John Deere 4420 Combine Parts
John Deere 4420 Combine parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The John Deere 4420 combine, manufactured from 1980 to 1984, was a popular choice for farmers needing a reliable and efficient machine. Powered by a John Deere diesel engine producing around 105 HP, the 4420 offered header widths up to 20 feet. Its conventional separator system and easy-to-maintain design made it a workhorse in the field, especially for smaller to medium-sized farms.
About the 4420
The John Deere 4420 was introduced in 1980 as part of the 4000 series combine lineup and remained in production until 1984. This combine is equipped with a John Deere 4276T 4.5L (276 ci) 4-cylinder turbocharged diesel engine, rated at approximately 105 horsepower. The 4420 utilizes a conventional threshing system with a 38-inch wide cylinder. Grain tank capacity is around 75 bushels, and the unloading auger can empty the tank at a rate of approximately 25 bushels per minute. Available header widths ranged from 13 to 20 feet, allowing for versatility in different field conditions. While a chopper or spreader was an option, many models were sold without. The cab offered basic operator comfort with options for air conditioning. The 4420 excels at harvesting grains like wheat, soybeans, and corn, offering a balance of capacity and maneuverability.
4420 Specifications
| Engine | John Deere 4276T 105 HP 4.5L Diesel |
|---|---|
| Separator Type | Conventional - 38-inch Cylinder |
| Grain Tank | 75 bushels |
| Unloading Rate | 25 bu/min |
| Header Widths | 13-20 ft |
| Fuel Capacity | 55 gallons |
| Weight | 13,500 lbs |
| Years Produced | 1980-1984 |
4420 Maintenance Tips
- Concave Adjustment: Regularly check and adjust concave clearance according to the crop being harvested to optimize threshing performance and minimize grain loss.
- Belt and Chain Tension: Inspect all belts and chains for wear and proper tension. Loose belts or chains can lead to reduced efficiency and potential component failure.
- Sieve and Chaffer Cleaning: Keep the sieves and chaffer clean to ensure proper separation of grain from chaff and debris. Regular cleaning prevents plugging and maximizes harvesting efficiency.
- Bearing Greasing: Follow the recommended greasing schedule for all bearings on the combine. Proper lubrication extends bearing life and prevents costly breakdowns during harvest season.
4420 History & Background
The John Deere 4420 was introduced in 1980, building upon the success of previous John Deere combine models. While not a revolutionary design, it offered improvements in fuel efficiency and operator comfort compared to earlier models. The 4420 served as a dependable and cost-effective harvesting solution for many farmers during its production years.
Frequently Asked Questions
Which fuel lift pump is compatible with the John Deere 4420?
The RE27667 - Pump, Fuel Lift Transfer is the correct fuel lift pump for the John Deere 4420 combine.
What pre-cleaner bowl is suitable for the John Deere 4420?
For the John Deere 4420, the R28795 - Bowl, Pre-Cleaner (10.5") is the appropriate replacement.
Which drive gear is needed for the shoe auger on the John Deere 4420?
The H137215 - Drive Gear, Shoe Auger is the correct part for the shoe auger drive system on your John Deere 4420.
What are essential wear parts for the John Deere 4420 combine?
Essential wear parts for the John Deere 4420 combine include the H138762 - Belt, Secondary Countershaft / Front Straw Chopper, RE27348 - Bearing, Connecting Rod (Std), AH154697 - Bushing, Isolator (10 Per Pk), AR89564 - Injector, Pencil, and R51936 - Grommet, Injector Lines.
