John Deere 9560 Combine Parts

9560 parts and accessories

The John Deere 9560 combine, manufactured from 2003 to 2006, was a popular choice for farmers needing a dependable grain harvesting solution. Powered by a John Deere PowerTech engine pushing around 265 HP, and available with header widths up to 30 feet, this conventional combine was known for its robust performance and ease of operation. Farmers appreciated its balance of power and simplicity.

The John Deere 9560 combine was introduced in 2003 as part of the '60 Series' and remained in production until 2006. It features a John Deere PowerTech 6.8L engine, delivering approximately 265 horsepower (198 kW) with a displacement of 414 cubic inches. The 9560 utilizes a conventional threshing system with a 59-inch wide cylinder, known for its effective grain separation and gentle handling of crops like wheat and soybeans. Its grain tank holds around 220 bushels, and the unloading auger provides a discharge rate of approximately 2.1 bushels per second (126 bu/min), ensuring efficient unloading. Available header widths ranged up to 30 feet, accommodating various field sizes and harvesting requirements. The 9560 offered options for chopper and spreader attachments to manage crop residue. The cab provided a comfortable working environment with features like air conditioning and adjustable seating. This model excelled in harvesting grains like wheat, soybeans, and corn, offering a reliable and efficient harvesting solution for many farmers.

Specifications

Engine	John Deere PowerTech 265 HP 6.8L Diesel
Separator Type	Conventional - 59-inch wide cylinder
Grain Tank	220 bushels
Unloading Rate	126 bu/min
Header Widths	Up to 30 ft
Fuel Capacity	150 gallons
Weight	Approximately 24,000 lbs
Years Produced	2003-2006

Maintenance Tips

Concave Adjustment: Regularly check and adjust the concave clearance to ensure proper threshing and minimize grain loss. Refer to the operator's manual for recommended settings based on the crop being harvested.
Belt and Chain Tension: Inspect and maintain proper tension on all belts and chains to prevent slippage and premature wear. Loose belts and chains can lead to inefficient operation and potential damage.
Sieve and Chaffer Cleaning: Regularly clean the sieves and chaffer to remove debris and ensure proper airflow for efficient grain separation. Clogged sieves can result in grain loss over the back.
Bearing Greasing: Follow the recommended greasing schedule for all bearings to ensure proper lubrication and prevent premature failure. Use high-quality grease specifically designed for agricultural equipment.

History & Background

The John Deere 9560 was introduced in 2003 as part of the '60 Series' combines, offering an updated design and improved performance compared to its predecessors. While it didn't undergo major redesigns during its production run, it represented a significant step in combine technology for John Deere's conventional combine offerings. It provided a reliable option for farmers needing a mid-sized combine with proven performance.

Frequently Asked Questions

What engine is in the John Deere 9560?

The John Deere 9560 is equipped with a John Deere PowerTech 6.8L diesel engine producing approximately 265 horsepower.

What is the grain tank capacity on a 9560?

The grain tank capacity of the John Deere 9560 is approximately 220 bushels, with an unloading rate of around 126 bushels per minute.

What type of separator does the 9560 have?

The John Deere 9560 utilizes a conventional threshing system with a 59-inch wide cylinder for separating grain from the crop material.

What are common parts needed for the 9560?

Commonly needed parts for the John Deere 9560 include concaves, rasp bars, belts, chains, bearings, auger fingers, and sickle sections for the header.
