John Deere 1032 Combine Parts
Shop John Deere 1032 Combine parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere 1032 combine, produced from approximately 1974-1980, was a popular choice for farmers seeking a reliable and straightforward harvesting solution. Powered by a John Deere diesel engine offering around 105 HP, the 1032 was typically equipped with header widths ranging from 13 to 15 feet. Its conventional cylinder and concave system made it effective for harvesting a variety of grains, particularly wheat and soybeans.
About the 1032
The John Deere 1032 combine was a workhorse on many farms during its production run from approximately 1974 to 1980. It was designed to be a reliable and affordable option for smaller to medium-sized operations. Powering the 1032 was a John Deere 404 cubic inch diesel engine, generating approximately 105 horsepower. This provided sufficient power for its header and threshing capabilities. The 1032 used a conventional threshing system with a cylinder and concave. Grain tank capacity was around 70 bushels. Unloading rates were generally around 30-40 bushels per minute. Header widths offered typically ranged from 13 to 15 feet, offering flexibility for different field sizes. While chopper and spreader options existed, they weren't universally equipped, depending on the original purchaser's needs. The cab, while not as luxurious as later models, provided basic operator comfort and control. The John Deere 1032 proved particularly adept at harvesting wheat, soybeans, and other small grains.
1032 Specifications
| Engine | John Deere 404D 105 HP Diesel |
|---|---|
| Separator Type | Conventional - 6-bar cylinder |
| Grain Tank | 70 bushels |
| Unloading Rate | 35 bu/min |
| Header Widths | 13-15 ft |
| Fuel Capacity | 35 gallons |
| Weight | Approx. 12,000 lbs |
| Years Produced | 1974-1980 |
1032 Maintenance Tips
- Concave Adjustment: Regularly check and adjust concave clearance according to the crop being harvested to optimize threshing and minimize grain loss.
- Belt and Chain Tension: Inspect all belts and chains for wear and proper tension. Loose belts and chains can slip, reducing efficiency and leading to premature failure.
- Sieve and Chaffer Cleaning: Clean the sieves and chaffer frequently to remove debris and ensure proper airflow for effective grain cleaning.
- Bearing Greasing: Grease all bearings according to the manufacturer's recommendations to prevent overheating and extend bearing life.
1032 History & Background
The John Deere 1032 was introduced in the mid-1970s as a part of John Deere's 32 series combines, offering a cost-effective harvesting solution. It filled a gap in John Deere's lineup, providing a smaller, more accessible combine than its larger counterparts. While not revolutionary in design, it represented a reliable and durable option that contributed to John Deere's continued market dominance.
Frequently Asked Questions
Which water pump fits the John Deere 1032 combine?
The recommended water pump for the John Deere 1032 combine is AR97708 - Pump, Water.
What fuel lift pump is recommended for the John Deere 1032?
For the John Deere 1032, the recommended fuel lift transfer pump is RE27667 - Pump, Fuel Lift Transfer.
What type of tooth ring is used in the slip clutch of a John Deere 1032?
The John Deere 1032 combine uses the Z699H - Tooth Ring; Slip Clutch for its slip clutch mechanism.
What are common replacement parts for the John Deere 1032?
Commonly needed replacement parts for the John Deere 1032 include the T19044 - Filter, Lube, Spin-on, 411-042 - Black 12ga Top Serrated for cutting applications, a AR92893 - Seal, Rear Crankshaft W/ Wear Sleeve, a RE33705 - Thermostat, 180°, RE27348 - Bearing, Connecting Rod (Std), and T20077 - Keeper, Valve.

T26321 - Lower Bushing
SKU: T26321
69 in stock

T20215 - Thermostat Housing (5 pack) Gasket
SKU: T20215
86 in stock

RE27667 - Fuel Lift Transfer Pump
SKU: RE27667
2834 in stock

RE27348 - Connecting Rod (Std) Bearing
SKU: RE27348
1575 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

T20073 - Camshaft Follower
SKU: T20073
131 in stock

RE52020 - Oil Pump Repair Kit
SKU: RE52020
23 in stock

RE35685 - Oil Pump
SKU: RE35685
141 in stock

RE31929 - Engine Oil Cooler
SKU: RE31929
27 in stock

RE27368 - Main (.030") Bearing
SKU: RE27368
10 in stock

RE27364 - Connecting Rod (.030") Bearing Set
SKU: RE27364
24 in stock

RE27360 - Main (.020") Bearing
SKU: RE27360
55 in stock

RE27358 - Connecting Rod (.020") Bearing Set
SKU: RE27358
193 in stock

RE27353 - Main (.010") Bearing
SKU: RE27353
105 in stock

RE27352 - Main (Std) Bearing
SKU: RE27352
105 in stock

RE27349 - Connecting Rod (.010") Bearing Set
SKU: RE27349
626 in stock

RE26283 - Balancer with Gear (LH) Shaft
SKU: RE26283
30 in stock

RE26282 - Balancer w/ Gear (RH) Shaft
SKU: RE26282
2 in stock

RE20585 - Crankshaft
SKU: RE20585
9 in stock

AT27622 - Return Fuel Tee
SKU: AT27622
168 in stock

AH75397 - Cylinder End
SKU: AH75397
29 in stock

Z38186 - Feeder House Main Drive Belt
SKU: Z38186
4 in stock

AT35123 - 37 DEG Elbow Fitting
SKU: AT35123
34 in stock
