Ford New Holland TL80 Tractor Parts

TL80 parts and accessories

The Ford New Holland TL80 tractor, manufactured from 1998 to 2003, was a popular choice for farmers due to its reliable performance and versatile capabilities. Powered by a 75 HP Iveco diesel engine, the TL80 delivered ample power for various farming tasks. Its robust design and PTO horsepower made it well-suited for haying, tilling, and general farm work, contributing to its enduring appeal.

The Ford New Holland TL80 tractor was produced between 1998 and 2003, forming part of the TL series designed to offer a blend of power and maneuverability. It's powered by an Iveco 8045.05 diesel engine, producing approximately 75 horsepower. The engine has a displacement of 4.0 liters (244 cubic inches). The standard transmission is a mechanical synchro with 12 forward and 12 reverse gears, providing a good range of speeds for different field conditions. The TL80 features an independent 540 RPM PTO, enabling efficient operation of various implements. The hydraulic system delivers around 13.2 GPM (50 lpm) of flow to power implements and the power steering, typically equipped with two rear remotes. The 3-point hitch is a Category II, offering a lift capacity of approximately 5,732 lbs. This tractor is commonly used for row crop work, hay production, livestock operations involving feeding and manure handling, and general tillage activities. It distinguished itself in the Ford New Holland lineup with its balanced power-to-weight ratio, offering more power than compact tractors, but still nimble enough for smaller fields.

Specifications

Engine	Iveco 8045.05 75 HP Diesel
PTO HP	65 HP @ 540 RPM
Transmission	Synchro Shuttle 12F/12R
Hydraulics	13.2 GPM, 2 remotes
3-Point Hitch	Category II, 5732 lbs
Fuel Capacity	26.4 gallons
Weight	7452 lbs
Years Produced	1998-2003

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using the manufacturer's recommended oil type and a quality filter.
Hydraulic System: Inspect hydraulic oil levels regularly and change the hydraulic filter every 500 hours or annually, whichever comes first. Use the recommended hydraulic fluid to prevent pump damage.
Fuel System: Use clean, high-quality diesel fuel and check the fuel filter regularly. Drain any water or sediment from the fuel tank to prevent fuel injector issues.
Seasonal Storage: Before storing the tractor for an extended period, fill the fuel tank to prevent condensation, lubricate all grease fittings, and disconnect the battery to prevent drain.

History & Background

Introduced in 1998, the Ford New Holland TL80 was part of the TL series, representing a new generation of utility tractors designed for enhanced performance and operator comfort. While it didn't undergo major redesigns during its production run, it maintained a consistent build quality and reliability that made it a popular choice for farmers needing a versatile machine. The TL80 played a significant role in providing a reliable and powerful option for a broad range of agricultural tasks.

Frequently Asked Questions

What engine is in the Ford New Holland TL80?

The Ford New Holland TL80 is equipped with an Iveco 8045.05 4-cylinder diesel engine producing 75 horsepower and displacing 4.0 liters (244 cubic inches).

What is the PTO horsepower on a TL80?

The PTO horsepower on the Ford New Holland TL80 is rated at 65 HP and operates at 540 RPM.

What oil filter fits the TL80?

The Ford New Holland TL80 typically uses a spin-on oil filter. Common cross-references include Fleetguard LF3349, Baldwin B1421, or Wix 51794. Always verify compatibility with your specific tractor's documentation.

What are common parts needed for the TL80?

Commonly replaced parts for the Ford New Holland TL80 include engine oil filters, fuel filters, hydraulic filters, air filters, fan belts, hydraulic cylinder seals, steering components (tie rod ends, ball joints), and clutch components such as clutch discs and pressure plates.
