Ford New Holland 2131 Tractor Parts

2131 parts and accessories

The Ford New Holland 2131 was a popular utility tractor produced in the late 1950s and early 1960s, known for its reliability and versatility on the farm. Powered by a gasoline engine producing around 34 horsepower and boasting approximately 30 PTO horsepower, it was a workhorse for various agricultural tasks. Farmers appreciated its compact size and maneuverability in smaller fields and around livestock.

The Ford New Holland 2131 tractor was manufactured from 1957 to 1962, becoming a staple in many farming operations. It features a Continental Z134 gasoline engine, producing roughly 34 horsepower with a displacement of 134 cubic inches. The transmission is a 4-speed manual gear type providing reliable performance. The independent PTO delivers around 30 horsepower at 540 RPM, suitable for operating various implements. The hydraulic system provides a flow rate of approximately 4 GPM, powering the 3-point hitch, which is a Category I type. Common applications for the 2131 included row crop work, haying, livestock feeding, and light tillage. What sets it apart from some models is its compact design combined with adequate power for its size, making it a versatile machine for smaller farms or specialized tasks.

Specifications

Engine	Continental Z134 34 HP Gasoline
PTO HP	30 HP @ 540 RPM
Transmission	4-Speed Manual
Hydraulics	4 GPM, 0 remotes
3-Point Hitch	Category I, 1500 lbs lift
Fuel Capacity	12 gallons
Weight	2645 lbs
Years Produced	1957-1962

Maintenance Tips

Change the engine oil and filter every 100-200 hours of operation. Use a high-quality oil specified for gasoline engines of this era.
Inspect and maintain the hydraulic system regularly. Check for leaks and ensure the hydraulic fluid is clean and at the correct level. Replace the hydraulic filter as needed.
Keep the fuel system clean to prevent issues. Use fresh fuel and consider adding a fuel stabilizer, especially during seasonal storage. Drain the fuel bowl regularly to remove any water or sediment.
Before storing the tractor for the winter, drain the fuel tank, change the engine oil, and grease all fittings. Protect the tires from direct sunlight and consider using a battery maintainer.

History & Background

The Ford New Holland 2131 was introduced in 1957 as part of the Hundred Series tractors from Ford. It remained relatively unchanged throughout its production run, establishing itself as a reliable and affordable option for smaller farms. Its simple design and robust engine contributed to its longevity and popularity in the agricultural sector.

Frequently Asked Questions

What engine is in the Ford New Holland 2131?

The Ford New Holland 2131 is equipped with a Continental Z134 gasoline engine, producing approximately 34 horsepower with a displacement of 134 cubic inches.

What is the PTO horsepower on a 2131?

The Ford New Holland 2131 delivers around 30 PTO horsepower at 540 RPM.

What oil filter fits the 2131?

Common oil filter cross-references for the Ford New Holland 2131 include Fram PH25, Wix 51010, and NAPA 1010. Always verify compatibility with your specific engine configuration.

What are common parts needed for the 2131?

Common wear parts for the Ford New Holland 2131 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic seals, tie rod ends, drag links, clutch discs, pressure plates, and throwout bearings.
