John Deere T660 Combine Parts
John Deere T660 Combine parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The John Deere T660 combine, produced from approximately 2012 to 2015, offered farmers a powerful and efficient grain harvesting solution. Boasting around 360 engine horsepower and available with header widths up to 40 feet, the T660 featured a robust conventional threshing and separating system. Its reliability and high throughput made it a popular choice for harvesting wheat, soybeans, and other grains.
About the T660
The John Deere T660 was introduced as part of the T-Series combine lineup, manufactured approximately from 2012 to 2015. Powering the T660 is a John Deere PowerTech 9.0L 6-cylinder diesel engine, delivering approximately 360 horsepower. This engine provides ample power for threshing and separating high volumes of grain. The T660 utilizes a conventional threshing system featuring a high-capacity cylinder and concave. Grain tank capacity is rated at approximately 300 bushels, and the unloading auger achieves a rate of around 3.3 bushels per second (200 bu/min), minimizing downtime during harvest. Available header widths range from 25 to 40 feet, catering to various field sizes and crop types. The T660 offered options for both straw choppers and spreaders to manage residue efficiently. The combine's cab is designed for operator comfort and visibility, featuring advanced controls and monitoring systems. The T660 excels at harvesting small grains like wheat and barley, as well as soybeans and other row crops.
T660 Specifications
| Engine | John Deere PowerTech 9.0L 360 HP Diesel |
|---|---|
| Separator Type | Conventional - 66-inch wide cylinder |
| Grain Tank | 300 bushels |
| Unloading Rate | 200 bu/min |
| Header Widths | 25-40 ft |
| Fuel Capacity | 210 gallons |
| Weight | Approximately 33,000 lbs |
| Years Produced | 2012-2015 (approximate) |
T660 Maintenance Tips
- Concave Adjustment: Regularly inspect and adjust concave clearance to ensure proper threshing without excessive grain damage. Refer to the operator's manual for recommended settings based on crop type and conditions.
- Belt and Chain Tension: Check belt and chain tension throughout the combine regularly, especially the header drive belt and feeder house chain. Loose belts and chains can cause slippage, reduced performance, and premature wear.
- Sieve and Chaffer Cleaning: Clean sieves and chaffers frequently to remove debris and prevent plugging. This ensures optimal cleaning performance and reduces grain loss. Use compressed air or a brush to remove accumulated material.
- Bearing Greasing: Follow the recommended greasing schedule in the operator's manual for all bearings. Proper lubrication extends bearing life and prevents costly breakdowns.
T660 History & Background
The John Deere T660 was introduced to provide farmers with a high-capacity, conventional combine option. While not a revolutionary design change, it represented an evolution of Deere's conventional combine technology, focusing on increased throughput and efficiency. The T660 played a significant role in meeting the demands of larger farming operations.
Frequently Asked Questions
Which fuel filter fits the John Deere T660?
The recommended fuel filter for the John Deere T660 combine is the RE533910 - Filter, Fuel, Spin-on.
What thrust bearing is used for the separator fan drive on the John Deere T660?
For the separator fan drive on the T660, we recommend the AH229175 - Bearing, Thrust; Seperator Fan Drive.
Which concave insert is recommended for the T660 combine?
The AH206756 - Concave Insert - C/W Spring, Pin, Roll Pin & Washer is a suitable replacement concave insert for the John Deere T660.
What are common wear parts needed for the T660?
For the T660, commonly needed replacement parts include the RE509672 - Filter, Lube, Cartridge, VPK1551 - Hydraulic Filter, H132057 - Tooth, Cylinder Spike; w/ Hardware, H144667 - Paddle, Elevator Chain, and H171960 - Wear Strip, Upper Return.

RE524529 - Fuel Injection Pump Pressure Relief Valve
SKU: RE524529
82 in stock

RE520036 - Rear Crankshaft Seal
SKU: RE520036
236 in stock

RE61253 - Std. Thrust Washer Set
SKU: RE61253
10 in stock

RE57604 - Dual; Heavy Duty Torsional Damper
SKU: RE57604
Out of stock

RE549752 - Pressure Sensor
SKU: RE549752
73 in stock

RE543187 - Engine Oil W/O Gear Pump
SKU: RE543187
9 in stock

RE542461 - Exhaust Manifold Pressure Sensor
SKU: RE542461
243 in stock

RE539761 - Fuel Pump
SKU: RE539761
7 in stock

RE538131 - Exhaust System Diesel Oxidation Catalyst Pressure Sensor
SKU: RE538131
278 in stock

RE538128 - Fuel Pressure Sensor
SKU: RE538128
82 in stock

RE538127 - Fuel Temperature Sensor
SKU: RE538127
6 in stock

RE537640 - Engine Oil Pressure Sensor
SKU: RE537640
93 in stock

RE537639 - Manifold Air Pressure Sensor
SKU: RE537639
255 in stock

RE537637 - Coolant Temperature Sensor
SKU: RE537637
191 in stock

RE537636 - EGR Temperature Sensor
SKU: RE537636
149 in stock

RE537635 - Manifold Air Temperature Sensor
SKU: RE537635
130 in stock

RE537634 - Engine; Magnetic Pickup Sensor
SKU: RE537634
132 in stock

RE536275 - Fuel Rail Pressure Sensor
SKU: RE536275
163 in stock

RE536274 - Rail Fuel Injection Pressure Relief Valve
SKU: RE536274
242 in stock

RE534183 - .011 Undersize Thrust Bearing
SKU: RE534183
Out of stock

RE534181 - .011 Undersize Main Bearing
SKU: RE534181
16 in stock

RE531288 - Turbocharger
SKU: RE531288
11 in stock

RE529320 - Std. Thrust Bearing
SKU: RE529320
440 in stock

RE529319 - Std. Main Bearing
SKU: RE529319
4392 in stock
