John Deere T560 Combine Parts

T560 parts and accessories

The John Deere T560 combine, manufactured from 2012 onwards, delivers a powerful and efficient harvesting experience. Boasting engine power up to 373 horsepower and compatible with header widths up to 36 feet, it's a versatile machine for various crops. Its efficient rotary separator system and large grain tank capacity have made the T560 a popular choice for farmers looking for high throughput and reliable performance.

The John Deere T560 combine, introduced as part of the T-Series combines, has been a mainstay in fields since 2012. It's powered by a John Deere PowerTech 9.0L engine, producing up to 373 horsepower (278 kW), delivering robust power for demanding harvesting conditions. The T560 utilizes a single rotor separator system, maximizing threshing efficiency while minimizing grain damage. Its grain tank holds approximately 300 bushels, allowing for extended harvesting periods before unloading. The unloading auger operates at a rate of around 3.3 bushels per second (200 bu/min), quickly emptying the tank. Available header widths range from 25 to 36 feet, accommodating various field sizes and crop types. Chopper and spreader options effectively manage residue, ensuring proper field preparation for subsequent planting. The T560's cab features advanced technology and ergonomic design for operator comfort and efficiency. This combine excels at harvesting crops such as wheat, barley, canola, soybeans, and corn.

Specifications

Engine	John Deere PowerTech 9.0L 373 HP Diesel
Separator Type	Single Rotor - 31-inch Diameter, 125-inch Length
Grain Tank	300 bushels
Unloading Rate	200 bu/min
Header Widths	25-36 ft
Fuel Capacity	211 gallons
Weight	~35,000 lbs
Years Produced	2012-Present

Maintenance Tips

Concave Adjustment: Regularly inspect and adjust the concave clearance based on the crop being harvested to optimize threshing and minimize grain loss.
Belt and Chain Tension: Check belt and chain tension regularly, especially before and during harvest season, to prevent slippage and ensure proper component operation.
Sieve and Chaffer Cleaning: Clean the sieves and chaffer screens frequently to remove debris and ensure proper grain separation, preventing losses over the back of the combine.
Bearing Greasing: Grease all bearings according to the manufacturer's recommended schedule to reduce friction and prevent premature wear, extending the life of critical components.

History & Background

The John Deere T560 was introduced as a part of the T-Series combine family, designed to offer a balance of capacity and efficiency for mid-sized farming operations. Since its introduction in 2012, the T560 has seen continuous improvements in engine technology, operator comfort, and harvesting performance. It represents a significant step in combine design, bridging the gap between conventional and larger rotary machines.

Frequently Asked Questions

What engine is in the John Deere T560?

The John Deere T560 is equipped with a John Deere PowerTech 9.0L diesel engine producing up to 373 horsepower.

What is the grain tank capacity on a T560?

The grain tank capacity of the John Deere T560 is approximately 300 bushels with an unloading rate of approximately 200 bushels per minute.

What type of separator does the T560 have?

The T560 utilizes a single rotary separator with a 31-inch diameter and 125-inch length for efficient threshing and grain separation.

What are common parts needed for the T560?

Common parts needed for the T560 include concaves, rasp bars, belts, chains, bearings, auger fingers, and sickle sections, all of which are subject to wear during the harvesting season.
