John Deere S770 Combine Parts
Shop John Deere S770 Combine parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere S770 combine, manufactured from 2017 onwards, offers a powerful solution for grain harvesting. With engine options around 400 HP and header widths reaching up to 40 feet, its rotary separator system provides efficient threshing. Farmers appreciated the S770 for its advanced technology, increased capacity, and ability to handle a variety of crops effectively.
About the S770
The John Deere S770 combine was introduced in 2017 as part of the S700 series, building upon the success of the S600 series. Powering the S770 is a John Deere PowerTech 9.0L engine producing around 400 horsepower. The heart of the S770 is its single rotor separator, designed for high-capacity threshing and separation, especially in tough crop conditions. The Dyna-Flo Plus cleaning system enhances cleaning capacity, maximizing grain quality and minimizing losses. It features a grain tank capacity of approximately 300 bushels and an unloading auger capable of speeds up to 4.0 bushels per second (240 bu/min). Available header widths range from 30 to 40 feet, catering to diverse field sizes and crop types. Chopper and spreader options ensure efficient residue management for improved soil health. The S770's cab offers enhanced comfort and control with advanced monitoring systems. The S770 performs exceptionally well in corn, soybeans, wheat, and other small grains.
S770 Specifications
| Engine | John Deere PowerTech 9.0L 402 HP Diesel |
|---|---|
| Separator Type | Rotary - Single Rotor |
| Grain Tank | 300 bushels |
| Unloading Rate | 240 bu/min |
| Header Widths | 30-40 ft |
| Fuel Capacity | 250 gallons |
| Weight | 36,800 lbs |
| Years Produced | 2017-Present |
S770 Maintenance Tips
- Concave Adjustment: Regularly check and adjust concave clearance based on crop type and conditions to optimize threshing performance and minimize grain damage.
- Belt and Chain Tension: Inspect belt and chain tension regularly. Loose belts or chains can slip, reducing efficiency and potentially causing damage.
- Sieve and Chaffer Cleaning: Clean sieves and chaffers frequently to prevent plugging and maintain optimal cleaning performance. This will minimize grain loss out the back of the combine.
- Bearing Greasing: Regularly grease all bearings according to the manufacturer's recommendations to ensure smooth operation and prevent premature wear.
S770 History & Background
The John Deere S770 combine was introduced in 2017 as part of the S700 series, replacing and improving upon earlier models. It represented a significant advancement in combine technology, incorporating features designed to enhance efficiency, capacity, and operator comfort. The S770 helped continue John Deere's tradition of developing top-performing combines, especially in diverse harvesting conditions.
Frequently Asked Questions
Which fuel filter is recommended for the John Deere S770?
For optimal engine performance, the RE533910 - Filter, Fuel, Spin-on is recommended for the John Deere S770 combine.
What hydraulic filter fits the John Deere S770 combine?
The VPK1551 - Hydraulic Filter is designed to fit the hydraulic system of the John Deere S770, ensuring clean fluid operation.
Which cab air filter should I use for the John Deere S770?
For maintaining a clean operator environment in the John Deere S770, the L214634 - Filter, Cab Air, Recirculation is an essential replacement part.
What are common wear parts for the John Deere S770 combine?
For maintaining the efficiency of your S770, commonly replaced wear parts include the HXE95511 - Belt, Feed Beater Drive, the H174885 - Belt; Fixed Speed Feeder House, Extra Heavy Duty, the AH219987 - Bearing w/ Housing; Feeder Drum, the H171960 - Wear Strip, Upper Return, and the H227474 - Sprocket, Upper Feeder House.

RE524529 - Fuel Injection Pump Pressure Relief Valve
SKU: RE524529
82 in stock

RE57604 - Dual; Heavy Duty Torsional Damper
SKU: RE57604
Out of stock

RE549752 - Pressure Sensor
SKU: RE549752
73 in stock

RE548027 - Belt Tensioner
SKU: RE548027
143 in stock

RE542461 - Exhaust Manifold Pressure Sensor
SKU: RE542461
243 in stock

RE539761 - Fuel Pump
SKU: RE539761
7 in stock

RE538143 - Torsional Damper
SKU: RE538143
Out of stock

RE538128 - Fuel Pressure Sensor
SKU: RE538128
82 in stock

RE538127 - Fuel Temperature Sensor
SKU: RE538127
6 in stock

RE537640 - Engine Oil Pressure Sensor
SKU: RE537640
93 in stock

RE537639 - Manifold Air Pressure Sensor
SKU: RE537639
255 in stock

RE537637 - Coolant Temperature Sensor
SKU: RE537637
191 in stock

RE537636 - EGR Temperature Sensor
SKU: RE537636
149 in stock

RE537635 - Manifold Air Temperature Sensor
SKU: RE537635
130 in stock

RE537634 - Engine; Magnetic Pickup Sensor
SKU: RE537634
132 in stock

RE529187 - Valve Stem Seal
SKU: RE529187
50 in stock

RE528400 - O/H Gasket Set
SKU: RE528400
18 in stock

RE523811 - Fuel Rail Pressure Sensor
SKU: RE523811
68 in stock

RE522823 - Air Temperature Sensor
SKU: RE522823
253 in stock

RE522794 - Fuel Pressure Sensor
SKU: RE522794
2 in stock

RE520465 - Torsional Damper
SKU: RE520465
Out of stock

RE515636 - Engine Restrictor
SKU: RE515636
3 in stock

RE505265 - Roller Idler
SKU: RE505265
78 in stock

RE48419 - Temperature Sensor
SKU: RE48419
129 in stock
