John Deere 9860STS Combine Parts

Shop John Deere 9860STS Combine parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.

The John Deere 9860STS combine, manufactured from 2003 to 2010, was a powerhouse known for its high-capacity harvesting. Powered by a robust engine producing over 350 horsepower, it handled wide headers effectively. The heart of this machine was its single-rotor separator, which proved popular among farmers seeking increased throughput and grain quality compared to conventional combines.

About the 9860STS

The John Deere 9860STS was introduced in 2003 as part of the STS (Single Tine Separation) combine series and remained in production until 2010. It's equipped with a John Deere 9.0L PowerTech engine producing 375 horsepower (max boost to 400 HP). This displacement provided ample power for demanding harvest conditions. The 9860STS uses a single-rotor separator, featuring a bullet rotor design with adjustable concaves for optimal threshing and separation. Grain tank capacity is 300 bushels, and the unloading auger boasts a speed of 3.0 bu/sec (180 bu/min). Compatible header widths range from 20 to 36 feet, allowing for efficient harvesting across various crop types. Chopper and spreader options were available to manage residue effectively. The cab featured enhanced comfort and technology, including advanced monitoring systems. The 9860STS excels in harvesting corn, soybeans, wheat, and other small grains due to its high capacity and efficient separation system.

9860STS Specifications

EngineJohn Deere 9.0L PowerTech 375 HP Diesel (Max Boost 400 HP)
Separator TypeSingle Rotor - Bullet Rotor with Adjustable Concaves
Grain Tank300 bushels
Unloading Rate180 bu/min
Header Widths20-36 ft
Fuel Capacity200 gallons
Weight32,500 lbs (approximate)
Years Produced2003-2010

9860STS Maintenance Tips

  • Concave Adjustment: Regularly inspect and adjust concave clearance according to the crop being harvested. Proper clearance minimizes grain loss and maximizes threshing efficiency.
  • Belt and Chain Tension: Maintain proper tension on all belts and chains to ensure smooth operation and prevent premature wear. Check for wear and replace as needed.
  • Sieve and Chaffer Cleaning: Regularly clean the sieves and chaffer to prevent buildup of debris, which can reduce cleaning efficiency and increase grain loss.
  • Bearing Greasing: Follow the manufacturer's recommended greasing schedule for all bearings to ensure proper lubrication and prevent bearing failure.

9860STS History & Background

The John Deere 9860STS was introduced in 2003 as a key model in the STS series, marking John Deere's commitment to rotary combine technology. It built upon the success of previous models by offering increased capacity and improved grain quality. The 9860STS played a significant role in advancing harvesting efficiency for farmers across the globe during its production run.

Frequently Asked Questions

Which hydraulic filter is recommended for the John Deere 9860STS?

For optimal hydraulic system performance, we recommend the VPK1551 hydraulic filter for the 9860STS combine.

What wear plate is used for the front beater on a 9860STS?

The H165407 wear plate is designed for the front beater assembly on the John Deere 9860STS.

Which belt is appropriate for the feed beater drive on the 9860STS?

The HXE95511 is the recommended belt for the feed beater drive system on the John Deere 9860STS combine.

What are common wear parts for the John Deere 9860STS combine?

Key wear parts for the 9860STS include the H215004 - Blade, Straw Chopper, Stationary, the AH229175 - Bearing, Thrust; Seperator Fan Drive, H171061 - Bushing, Clean Grain Elevator, H133143 - Sprocket, Clean Grain Elevator, Lower, and AH170119 - Louver, Sieve, Wide General Purpose. Regular inspection and replacement of these components are vital for maintaining optimal combine performance.

Showing 1-24 of 507 products
