John Deere 9610 Combine Parts
Shop John Deere 9610 Combine parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere 9610 combine, produced from 1996 to 1998, was a popular choice for farmers seeking a reliable and efficient conventional harvesting solution. Powered by a robust John Deere engine producing approximately 260 horsepower, it offered header widths up to 30 feet. The 9610's conventional cylinder and straw walker design provided excellent grain separation in a variety of crops, contributing to its reputation for productivity.
About the 9610
The John Deere 9610 was introduced in 1996 as part of the '10 Series' combines, replacing earlier models and incorporating advancements in operator comfort and harvesting technology. This combine is powered by a John Deere 6762T diesel engine, a 7.6L (466 ci) turbocharged six-cylinder engine, delivering approximately 260 horsepower. The 9610 utilizes a conventional threshing system, featuring a 66-inch wide cylinder and multiple straw walkers to separate grain from the crop. The grain tank capacity is 220 bushels, with an unloading auger capable of discharging grain at a rate of approximately 65 bushels per minute. Available header widths ranged from 15 to 30 feet, allowing farmers to optimize harvesting efficiency based on field conditions and crop type. Options included straw choppers and spreaders to manage residue effectively. The cab was designed with operator comfort in mind, featuring improved visibility and controls. The 9610 is well-suited for harvesting a wide range of crops including wheat, soybeans, corn, and barley.
9610 Specifications
| Engine | John Deere 6762T 260 HP 7.6L Diesel |
|---|---|
| Separator Type | Conventional - 66-inch Cylinder |
| Grain Tank | 220 bushels |
| Unloading Rate | 65 bu/min |
| Header Widths | 15-30 ft |
| Fuel Capacity | 150 gallons |
| Weight | 23,500 lbs |
| Years Produced | 1996-1998 |
9610 Maintenance Tips
- Regularly inspect and adjust the concave clearance to ensure optimal threshing performance.
- Check and maintain proper tension on all belts and chains, replacing worn components as needed to prevent breakdowns.
- Clean the sieves and chaffer frequently to remove debris and maintain efficient grain separation.
- Grease all bearings according to the manufacturer's recommendations to prevent premature wear and failure.
- Before each harvest season, thoroughly inspect the combine, checking fluids, filters, and performing necessary maintenance to ensure reliable operation.
9610 History & Background
The John Deere 9610 was a significant model in the evolution of John Deere combines, representing a refinement of their conventional harvesting technology. Introduced in 1996, it offered improved performance and operator comfort compared to its predecessors. It was eventually replaced by newer models with advancements in rotary separation technology.
Frequently Asked Questions
Which main bearing is appropriate for the John Deere 9610 engine?
For a standard replacement main bearing, consider the RE529319 - Main Bearing, Std.. It ensures proper fit and function for your engine.
What straw chopper blade is recommended for the 9610 combine?
The H215004 - Blade, Straw Chopper, Stationary is a suitable replacement component for the 9610's straw chopper assembly.
Which concave insert is compatible with the 9610's threshing system?
The AH206756 - Concave Insert - C/W Spring, Pin, Roll Pin & Washer is designed for optimal performance in the 9610 combine's separator.
What are common replacement parts for the John Deere 9610?
Regularly needed components for the John Deere 9610 include the AH206756 - Concave Insert - C/W Spring, Pin, Roll Pin & Washer, H132057 - Tooth, Cylinder Spike; w/ Hardware, AH229175 - Bearing, Thrust; Seperator Fan Drive, H167127 - Bushing, Paddled Straw Chopper Blade, AH125975 - Bearing, Cleaning Shoe Shaft, and the R83021 - Gasket, Exhaust Manifold.

RE520036 - Rear Crankshaft Seal
SKU: RE520036
236 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

RE65265 - Hand Primer
SKU: RE65265
176 in stock

RE62777 - Exhaust Manifold; Outer (2/Pack) Gasket
SKU: RE62777
896 in stock

RE61253 - Std. Thrust Washer Set
SKU: RE61253
10 in stock

RE57604 - Dual; Heavy Duty Torsional Damper
SKU: RE57604
Out of stock

RE57603 - Torsional Damper
SKU: RE57603
Out of stock

RE57054 - Camshaft W/ Tappets
SKU: RE57054
30 in stock

RE55475 - Head Gasket
SKU: RE55475
43 in stock

RE535300 - Crankshaft
SKU: RE535300
10 in stock

RE534314 - Crankshaft
SKU: RE534314
10 in stock

RE534183 - .011 Undersize Thrust Bearing
SKU: RE534183
Out of stock

RE534181 - .011 Undersize Main Bearing
SKU: RE534181
16 in stock

RE529320 - Std. Thrust Bearing
SKU: RE529320
440 in stock

RE529319 - Std. Main Bearing
SKU: RE529319
4392 in stock

RE527550 - Head Gasket Set
SKU: RE527550
7 in stock

RE527549 - Overhaul Gasket Set
SKU: RE527549
Out of stock

RE524105 - Oil Cooler To Block Gasket
SKU: RE524105
205 in stock

RE508156 - Low Compression Piston Piston Liner Kit
SKU: RE508156
69 in stock

RE507076 - Engine Oil Pump
SKU: RE507076
43 in stock

RE505265 - Roller Idler
SKU: RE505265
78 in stock

RE503528 - Piston Rings
SKU: RE503528
21 in stock

RE500934 - Torsional Damper
SKU: RE500934
20 in stock
