John Deere 7720 Combine Parts
Shop John Deere 7720 Combine parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The John Deere 7720 combine, manufactured from 1980 to 1984, was a popular choice for farmers needing a reliable and capable machine. Powered by a John Deere diesel engine producing around 175 HP, it offered header widths up to 30 feet, allowing for efficient harvesting of various crops. Its conventional separator design provided dependable performance and made it a respected workhorse in the field.
About the 7720
The John Deere 7720 combine was introduced in 1980 as part of the '20 Series', replacing older models and offering improvements in capacity and operator comfort. It was produced until 1984. The 7720 is powered by a John Deere 6.6L (404 cu in) 6-cylinder diesel engine, delivering approximately 175 horsepower. It utilizes a conventional threshing system with a 43-inch wide cylinder and a walker separation system. The grain tank holds approximately 155 bushels, and the unloading auger can empty the tank at a rate of around 45-50 bushels per minute. Available header widths ranged from 13 to 30 feet, accommodating different row spacings and crop types. Chopper and spreader options were available to manage residue. The cab featured improved ergonomics compared to previous models, offering a more comfortable operating environment. The 7720 is particularly well-suited for harvesting wheat, soybeans, and corn, providing reliable performance in a range of field conditions.
7720 Specifications
| Engine | John Deere 6.6L 175 HP Diesel |
|---|---|
| Separator Type | Conventional - 43-inch Cylinder |
| Grain Tank | 155 bushels |
| Unloading Rate | 45-50 bu/min |
| Header Widths | 13-30 ft |
| Fuel Capacity | 95 gallons |
| Weight | 17,500 lbs |
| Years Produced | 1980-1984 |
7720 Maintenance Tips
- Concave Adjustment: Regularly check and adjust the concave clearance to ensure proper threshing and minimize grain damage. Consult your operator's manual for recommended settings based on the crop being harvested.
- Belt and Chain Tension: Inspect all belts and chains for proper tension and wear. Adjust tensioners as needed to prevent slippage and premature failure. Lubricate chains regularly.
- Sieve and Chaffer Cleaning: Clean the sieves and chaffer frequently to remove debris and ensure proper grain separation. Clogged sieves can lead to grain loss and reduced efficiency.
- Bearing Greasing: Grease all bearings according to the manufacturer's recommended schedule. Proper lubrication is crucial for preventing bearing failure and extending the life of your combine.
7720 History & Background
The John Deere 7720 was introduced in 1980 as part of the '20 Series' combines, representing a significant upgrade in harvesting technology at the time. It replaced earlier models and offered increased capacity and improved operator comfort. The 7720 became known for its reliability and efficiency, contributing to its lasting impact on the agricultural landscape.
Frequently Asked Questions
What diesel fuel filter is recommended for the John Deere 7720?
For optimal engine performance, the AR50041 diesel fuel filter is recommended for the John Deere 7720.
Which wobble box shaft nut fits the 7720 combine?
The E59303 nut is designed for the wobble box shaft on the John Deere 7720 combine.
What drive gear is used for the shoe auger on the John Deere 7720?
The H137215 drive gear is the correct replacement for the shoe auger on the 7720 model.

VTK17892-3 - Valve Train Kit (.003")
SKU: VTK17892-3
1 in stock

VTK17892 - Valve Train Kit (Std)
SKU: VTK17892
6 in stock

T23425 - Fuel Injection Return (12 pk) T Boot
SKU: T23425
114 in stock

T20328 - Oil Filler Cap Gasket
SKU: T20328
48 in stock

RE520036 - Rear Crankshaft Seal
SKU: RE520036
236 in stock

RE19778 - Turbocharger
SKU: RE19778
133 in stock

T20129 - Valve Stem Cap
SKU: T20129
155 in stock

T20077 - Valve Keeper
SKU: T20077
1248 in stock

RE62777 - Exhaust Manifold; Outer (2/Pack) Gasket
SKU: RE62777
896 in stock

RE53422 - Crankshaft w/ A-R26049 Gear
SKU: RE53422
42 in stock

RE524105 - Oil Cooler To Block Gasket
SKU: RE524105
205 in stock

RE507076 - Engine Oil Pump
SKU: RE507076
43 in stock

RE48380 - Piston Rings
SKU: RE48380
37 in stock

RE47336G - Head Gasket
SKU: RE47336G
15 in stock

RE47336 - Head Gasket
SKU: RE47336
15 in stock

RE27786 - Leak-Off Fuel Line
SKU: RE27786
488 in stock

RE22764 - Rear Crankshaft Seal
SKU: RE22764
236 in stock

R60239 - Rear Spindle Thrust Washer
SKU: R60239
133 in stock

H158884 - Spindle Bushing
SKU: H158884
271 in stock

AH94057 - Cylinder End
SKU: AH94057
41 in stock

AH87542 - Spindle (LH)
SKU: AH87542
5 in stock

AH87540 - Spindle (RH)
SKU: AH87540
12 in stock

AH75397 - Cylinder End
SKU: AH75397
29 in stock

AH156821 - Rear Axle Spindle Housing
SKU: AH156821
9 in stock
