Ford New Holland TS6020 Tractor Parts

TS6020 parts and accessories

The Ford New Holland TS6020 tractor, a reliable workhorse on farms from 2003 to 2007, is powered by a robust Shibaura N844L diesel engine producing around 59 horsepower. Known for its simple design and dependable performance, the TS6020 delivered approximately 50 PTO horsepower, making it a popular choice for a variety of farming tasks like haying and light tillage.

The Ford New Holland TS6020 was manufactured between 2003 and 2007, filling a need for a mid-size, versatile tractor in the Ford New Holland lineup. Its heart is the Shibaura N844L naturally aspirated diesel engine. This 2.2-liter (134.2 cu in) four-cylinder engine generates approximately 59 horsepower at the flywheel. The TS6020 typically came with a synchronized mechanical transmission offering 9 forward and 3 reverse speeds, or optionally a 12 forward and 12 reverse synchronized shuttle. The independent PTO delivers around 50 horsepower and offers a standard 540 RPM rear PTO. Hydraulics provide around 8.2 GPM of flow to power implements. It features a Category II three-point hitch with a lift capacity of approximately 2,866 lbs. The TS6020 was commonly utilized for various farming applications including hay production, livestock feeding, light tillage operations, and row crop work. It distinguished itself from smaller compact tractors with its greater power and heavier build while remaining more maneuverable than larger row crop tractors.

Specifications

Engine	Shibaura N844L 59 HP 134.2 ci Diesel
PTO HP	50 HP @ 540 RPM
Transmission	Synchro Shuttle 9F/3R or 12F/12R
Hydraulics	8.2 GPM, 1 remotes
3-Point Hitch	Category II, 2866 lbs
Fuel Capacity	14.5 gallons
Weight	5589 lbs
Years Produced	2003-2007

Maintenance Tips

Check and change the engine oil and filter every 250 hours of operation, using the recommended oil type (typically a 15W-40 diesel engine oil).
Inspect and service the hydraulic system regularly, paying attention to hydraulic fluid levels and filter condition. Change hydraulic fluid and filter every 500 hours, or as recommended by the manufacturer.
Keep the fuel system clean by using quality fuel and changing the fuel filter regularly (every 250 hours). This prevents fuel injector clogs and ensures optimal engine performance.
Before seasonal storage, completely fill the fuel tank to prevent condensation buildup, grease all lubrication points, and disconnect the battery to prevent parasitic drain.

History & Background

Introduced in 2003, the Ford New Holland TS6020 aimed to provide a dependable and affordable tractor for smaller farms and as a utility tractor on larger operations. It saw no major redesigns during its production run. The TS6020 served as a solid performer in the Ford New Holland stable, helping farmers with a range of tasks.

Frequently Asked Questions

What engine is in the Ford New Holland TS6020?

The Ford New Holland TS6020 is equipped with a Shibaura N844L 2.2L (134.2 cu in) four-cylinder diesel engine producing 59 horsepower.

What is the PTO horsepower on a TS6020?

The PTO horsepower on the Ford New Holland TS6020 is approximately 50 horsepower at 540 RPM.

What oil filter fits the TS6020?

The recommended oil filter for the TS6020 is typically a Fram PH3600 or equivalent, such as a Wix 51348 or a NAPA 1348. Always verify fitment with your parts supplier using your tractor's serial number.

What are common parts needed for the TS6020?

Common parts needed for the TS6020 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic cylinder seal kits, tie rod ends, and clutch components.
