Ford New Holland TN55S Tractor Parts

TN55S parts and accessories

The Ford New Holland TN55S tractor, produced from 1997-2003, offered farmers a versatile solution for various agricultural tasks. Powered by a Shibaura 2.2L 52 HP diesel engine and delivering around 45 PTO horsepower, the TN55S was a popular choice due to its compact size, reliable performance, and ease of operation. This made it ideal for smaller farms and operations needing a dependable utility tractor.

The Ford New Holland TN55S was introduced in 1997 as part of the TN series, designed to offer a modern and efficient compact tractor solution. Production continued through 2003. At its heart lies a Shibaura N844L 2.2L (134.3 cu in) four-cylinder diesel engine, providing a rated 52 horsepower. It features a mechanical fuel system known for its reliability. The transmission is a synchronized shuttle with 12 forward and 12 reverse gears, offering a good range of speeds for various field operations. The PTO delivers approximately 45 horsepower at the 540 RPM setting. Hydraulics are handled by an open-center system with a flow rate of around 9.5 GPM, providing ample power for implements. The three-point hitch is a Category I, allowing for the use of many implements with a lift capacity around 2,200 lbs. Common applications for the TN55S include hay production, livestock management (feeding, manure handling), light tillage work, and row crop cultivation in smaller fields. It stood out from other models in the lineup due to its balanced power-to-weight ratio and its synchro-shuttle transmission that simplified direction changes, improving operator productivity.

Specifications

Engine	Shibaura N844L 52 HP 2.2L Diesel
PTO HP	45 HP @ 540 RPM
Transmission	Synchro Shuttle 12F/12R
Hydraulics	9.5 GPM, 2 remotes
3-Point Hitch	Category I, 2200 lbs
Fuel Capacity	13.2 gallons
Weight	4167 lbs
Years Produced	1997-2003

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using a high-quality diesel engine oil that meets the manufacturer's specifications. Regularly check the oil level and top off as needed.
Hydraulic System: Inspect hydraulic hoses and fittings for leaks regularly. Replace the hydraulic filter every 500 hours or as recommended in the operator's manual to prevent contamination and maintain optimal performance.
Fuel System: Use clean, high-quality diesel fuel. Drain the fuel tank sediment bowl regularly to remove water and debris. Replace the fuel filter annually or after every 500 hours of operation to prevent fuel starvation and engine damage.
Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel with a fuel stabilizer, grease all lubrication points, and disconnect the battery. Store the tractor in a dry, covered location to protect it from the elements.

History & Background

The Ford New Holland TN55S was launched in 1997 as a part of the TN series of compact tractors. It represented a significant step forward in terms of operator comfort and functionality for tractors in its size class. This model was a popular choice for small to medium-sized farms and helped solidify Ford New Holland's reputation for reliable and versatile agricultural equipment.

Frequently Asked Questions

What engine is in the Ford New Holland TN55S?

The Ford New Holland TN55S is equipped with a Shibaura N844L 2.2L four-cylinder diesel engine, producing 52 horsepower.

What is the PTO horsepower on a TN55S?

The PTO horsepower on the Ford New Holland TN55S is approximately 45 HP, available at 540 RPM.

What oil filter fits the TN55S?

Common oil filter cross-references for the TN55S include Fram PH3614, Wix 51348, and New Holland 86546614. Always verify compatibility with your specific tractor using the parts manual or a reliable parts lookup tool.

What are common parts needed for the TN55S?

Commonly needed parts for the TN55S include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic cylinder seal kits, tie rod ends, and clutch components like the clutch disc and pressure plate.
