Ford New Holland TD80D Tractor Parts

TD80D parts and accessories

The Ford New Holland TD80D, manufactured from 2003 to 2007, is a reliable agricultural tractor known for its versatility. Powered by a robust 78 HP diesel engine and offering a PTO horsepower of around 68 HP, the TD80D became popular with farmers for its ability to handle a variety of tasks, from haying to light tillage.

The Ford New Holland TD80D was introduced in 2003 as part of the TD-D series, offering a balance of power and economy for small to medium-sized farms. Production continued until 2007. The TD80D is powered by an Iveco 8045.05.276 diesel engine, producing approximately 78 horsepower. This 4-cylinder engine has a displacement of 274 cubic inches (4.5L). It features a mechanical fuel injection system for reliable operation. The transmission is a mechanical synchroshift, offering 12 forward and 12 reverse speeds, providing ample gear choices for various field conditions. The independent PTO delivers around 68 horsepower at 540 RPM, suitable for operating hay balers, mowers, and other PTO-driven implements. Its hydraulic system has a flow rate of approximately 11.9 GPM powering two rear remotes. The 3-point hitch is a Category II, with a lift capacity of around 5,291 lbs, making it capable of handling a wide range of implements. Common farming applications include hay production, livestock operations (feeding and manure handling), light tillage, and row crop work. Compared to smaller models in the TD-D series, the TD80D offers significantly more horsepower and hydraulic capacity, while remaining more economical than larger frame tractors.

Specifications

Engine	Iveco 8045.05.276 78 HP Diesel
PTO HP	68 HP @ 540 RPM
Transmission	Synchroshift 12F/12R
Hydraulics	11.9 GPM, 2 remotes
3-Point Hitch	Category II, 5291 lbs
Fuel Capacity	23.8 gallons
Weight	7,519 lbs
Years Produced	2003-2007

Maintenance Tips

Check engine oil level daily and change the oil and filter every 250 hours using a high-quality 15W-40 diesel engine oil.
Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and maintain proper system performance.
Use a fuel additive to prevent gelling in cold weather and regularly drain water from the fuel filter to ensure optimal fuel system operation.
Before storing the tractor for the off-season, drain the fuel tank, change the engine oil and filter, and grease all lubrication points to prevent corrosion and ensure easy start-up in the spring.

History & Background

The Ford New Holland TD80D was launched in 2003 as a key model in the TD-D series, filling a crucial power segment for mixed farming operations. While no major redesigns occurred during its production run, it remained a popular and dependable choice for farmers seeking a versatile and cost-effective tractor.

Frequently Asked Questions

What engine is in the Ford New Holland TD80D?

The Ford New Holland TD80D is equipped with an Iveco 8045.05.276 4-cylinder diesel engine producing 78 horsepower with a displacement of 274 cubic inches (4.5L).

What is the PTO horsepower on a TD80D?

The TD80D has a PTO horsepower rating of approximately 68 HP at 540 RPM. It is equipped with an independent PTO.

What oil filter fits the TD80D?

A common oil filter for the TD80D is a Fleetguard LF3349 or equivalent. Cross-references include Wix 51791 and Baldwin B1421.

What are common parts needed for the TD80D?

Commonly replaced parts include engine oil filters, fuel filters, air filters, hydraulic filters, belts (fan belt, alternator belt), hydraulic cylinder seal kits, steering linkage components, and clutch disc and pressure plate assemblies.
