Ford New Holland T5030 Tractor Parts

T5030 parts and accessories

The Ford New Holland T5030 tractor, manufactured from 2007-2012, was a popular choice for farmers seeking a reliable and versatile machine. Powered by a 76 HP diesel engine, the T5030 delivered ample power for various tasks. Its robust design and efficient PTO, rated at 65 HP, made it well-suited for haying, livestock operations, and general farm work.

The Ford New Holland T5030 was part of the T5000 series, introduced to replace the popular TN series. Production spanned from 2007 to 2012, offering a balance of power and maneuverability for diverse farming applications. The T5030 features a reliable Iveco 8000 series 3.9L 4-cylinder diesel engine producing approximately 76 horsepower. The engine's displacement contributes to its strong low-end torque, essential for demanding tasks. Transmission options included a 12x12 Synchro Shuttle, providing a wide range of speeds for optimal performance in various field conditions, and a 24x24 Dual Command transmission, with a two-speed powershift. Its PTO system delivers 65 HP, available in both 540 and 1000 RPM configurations. The hydraulic system boasts a capacity of around 16.1 GPM, operating with two or three remote valves to power implements. The T5030 is equipped with a Category II 3-point hitch, capable of lifting approximately 5,203 lbs. Common applications include hay production, livestock handling, and light tillage operations. The T5030 stood out for its comfortable cab (optional), ease of operation, and a good balance of features for its size, making it a versatile workhorse on many farms.

Specifications

Engine	Iveco 8000 Series 76 HP 3.9L Diesel
PTO HP	65 HP @ 540/1000 RPM
Transmission	12x12 Synchro Shuttle or 24x24 Dual Command
Hydraulics	16.1 GPM, 2-3 remotes
3-Point Hitch	Category II, 5,203 lbs lift capacity
Fuel Capacity	25.1 gallons
Weight	7,720 lbs
Years Produced	2007-2012

Maintenance Tips

Change engine oil and filter every 250 hours using the recommended oil type and a quality filter. Regularly inspect the air filter and clean or replace as needed.
Maintain the hydraulic system by checking fluid levels regularly and changing the hydraulic filter according to the manufacturer's recommendations. Inspect hydraulic hoses and fittings for leaks or damage.
Use clean, high-quality fuel and ensure the fuel filter is changed at the recommended intervals to prevent fuel system problems. Drain water from the fuel tank periodically.
Before seasonal storage, drain fluids, grease all fittings, and protect the tractor from the elements. Consider using fuel stabilizer to prevent fuel degradation during storage.

History & Background

The Ford New Holland T5030 was introduced in 2007 as part of the T5000 series, succeeding the TN series. This series aimed to provide enhanced operator comfort and improved performance compared to its predecessors. The T5030 gained recognition for its versatility and reliability, becoming a valuable asset for many farming operations during its production run.

Frequently Asked Questions

What engine is in the Ford New Holland T5030?

The Ford New Holland T5030 is equipped with an Iveco 8000 series 3.9L 4-cylinder diesel engine, producing approximately 76 horsepower.

What is the PTO horsepower on a T5030?

The Ford New Holland T5030 has a PTO horsepower rating of 65 HP. It offers both 540 and 1000 RPM PTO options.

What oil filter fits the T5030?

The recommended oil filter for the T5030 is commonly a New Holland 84210798 or a cross-reference such as a Wix 51773, or a Fram PH2870B. Always verify with your specific engine's manual.

What are common parts needed for the T5030?

Common wear parts for the T5030 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic seals, steering components, and clutch components. Maintaining these parts is essential for optimal tractor performance.
