Ford New Holland T3020 Tractor Parts

T3020 parts and accessories

The Ford New Holland T3020 tractor, manufactured between 2004 and 2007, provided reliable performance for various farming tasks. Powered by a Shibaura N844L diesel engine producing around 33 HP, and delivering approximately 27 PTO horsepower, the T3020 was favored by farmers for its compact size, fuel efficiency, and versatility in smaller-acreage operations and specialty farming applications.

The Ford New Holland T3020 was introduced in 2004 as part of the T3000 series of compact utility tractors. Production continued until 2007. At its heart lies a Shibaura N844L 4-cylinder diesel engine, delivering a gross engine power of around 33 horsepower. This naturally aspirated engine has a displacement of 84.4 cubic inches (1.4 liters). The standard transmission is a gear-type transmission offering 8 forward and 8 reverse speeds, providing ample options for various field conditions. The T3020's PTO delivers approximately 27 horsepower at the standard 540 RPM, making it suitable for powering implements like rotary cutters, tillers, and small balers. Its hydraulic system delivers a flow of around 6.6 gallons per minute, sufficient for operating implements and the Category I 3-point hitch, which offers a lift capacity of roughly 1,433 lbs. The T3020 was commonly used in applications such as row crop cultivation, hay production, livestock management (feeding and cleaning), and light tillage work. What sets it apart from larger tractors in the Ford New Holland lineup is its compact size and ease of maneuverability, making it ideal for tight spaces and smaller farms.

Specifications

Engine	Shibaura N844L 33 HP Diesel
PTO HP	27 HP @ 540 RPM
Transmission	Gear 8F/8R
Hydraulics	6.6 GPM, 1 remotes
3-Point Hitch	Category I, 1433 lbs
Fuel Capacity	7.9 gallons
Weight	2425 lbs
Years Produced	2004-2007

Maintenance Tips

Engine Oil and Filter: Change the engine oil and filter every 200-250 hours of operation using the recommended oil type (refer to the operator's manual). A clean oil filter ensures optimal engine lubrication.
Hydraulic System Maintenance: Inspect hydraulic fluid levels regularly and change the hydraulic fluid and filter every 500 hours or annually, whichever comes first. This prevents contamination and ensures smooth operation of hydraulic implements.
Fuel System Care: Use clean, high-quality diesel fuel and add a fuel stabilizer during periods of inactivity (e.g., winter storage) to prevent fuel degradation and injector clogging. Drain the fuel/water separator regularly to remove water from the fuel system.
Seasonal Storage: Before storing the tractor for an extended period, fully service it, including changing all fluids and filters. Disconnect the battery, store it in a cool, dry place, and consider using a battery maintainer. Protect the tires from direct sunlight.

History & Background

The Ford New Holland T3020 emerged in 2004 as a valuable addition to the T3000 series, targeting the compact utility tractor market. While there were no major redesigns during its production run from 2004-2007, this model represents a significant effort by Ford New Holland to offer a reliable and versatile machine for smaller farming operations, effectively filling a niche in the agricultural equipment landscape.

Frequently Asked Questions

What engine is in the Ford New Holland T3020?

The Ford New Holland T3020 is equipped with a Shibaura N844L 4-cylinder diesel engine, producing approximately 33 horsepower.

What is the PTO horsepower on a T3020?

The Ford New Holland T3020 delivers approximately 27 PTO horsepower at the standard 540 RPM.

What oil filter fits the T3020?

The oil filter for the T3020 is commonly cross-referenced as a Wix 51365, a Fram PH3593A, or a Ford SBA390320570. Always verify the correct part number with your specific tractor's manual or parts dealer.

What are common parts needed for the T3020?

Common wear parts for the T3020 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic cylinder seals, tie rod ends, steering drag links, and clutch components (if applicable).
