Ford New Holland 7530 Tractor Parts
Ford New Holland 7530 Tractor parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The Ford New Holland 7530, manufactured from 1992 to 1996, was a popular utility tractor known for its reliability and versatility on the farm. Powered by a robust 85 HP diesel engine, the 7530 delivered a respectable 74 PTO horsepower, making it well-suited for a variety of tasks. Farmers appreciated its comfortable cab and straightforward operation, which contributed to its widespread adoption.
About the 7530
The Ford New Holland 7530 was introduced in 1992 as part of the 30 series tractor lineup, replacing the earlier Ford models. Production continued until 1996. It featured a naturally aspirated Ford 4.0L 4-cylinder diesel engine producing approximately 85 horsepower. The engine had a displacement of 242 cubic inches (4.0L). Transmission options included a mechanical 12-speed forward, 12-speed reverse transmission and a Dual Power transmission, providing a wider range of speeds for different tasks. The PTO delivers around 74 horsepower with a standard 540 RPM PTO. A 1000 RPM PTO was optional. Its hydraulic system boasts a capacity of around 17.2 GPM, powering two standard remote valves for implements. The 3-point hitch is a Category II, capable of lifting approximately 5,732 lbs. The 7530 was commonly used in row crop operations, hay production, livestock management, and light tillage. Its larger size and increased horsepower distinguished it from smaller utility tractors in the Ford New Holland range, while offering a more economical option compared to the larger frame models.
7530 Specifications
| Engine | Ford 4.0L 85 HP Diesel |
|---|---|
| PTO HP | 74 HP @ 540 RPM |
| Transmission | Synchro 12x12 |
| Hydraulics | 17.2 GPM, 2 remotes |
| 3-Point Hitch | Category II, 5732 lbs |
| Fuel Capacity | 27.7 gallons |
| Weight | 7,991 lbs |
| Years Produced | 1992-1996 |
7530 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours using a high-quality diesel engine oil and a filter meeting OEM specifications.
- Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and maintain optimal performance.
- Fuel System: Use clean, quality diesel fuel and check/drain the fuel sediment bowl regularly to prevent fuel system issues and injector problems. Consider a fuel additive for winter storage.
- Seasonal Storage: Before storing the tractor for extended periods, stabilize the fuel, grease all fittings, and disconnect the battery to prevent corrosion and ensure a smooth start-up in the spring.
7530 History & Background
The Ford New Holland 7530 was launched in 1992 as a modern utility tractor aimed at meeting the evolving needs of farmers. While it didn't undergo major redesigns during its production run, it remained a popular choice due to its blend of power, reliability, and ease of use. The 7530 represents a key model in the transition from Ford to Ford New Holland tractors.
Frequently Asked Questions
What replacement starter is recommended for the Ford New Holland 7530?
For the Ford New Holland 7530, we recommend the 504059251 - starter, MM/DD, New to ensure reliable engine starting.
Which PTO shaft fits the Ford New Holland 7530 with a 540 RPM PTO?
The recommended PTO shaft for the 540 RPM option on the Ford New Holland 7530 is the 5185602 - Shaft, PTO (540 RPM).
What oil filter fits the Ford New Holland 7530?
For the Ford New Holland 7530, the LF682 - Filter, Lube, Spin-On is a suitable replacement.
What are common replacement parts for the Ford New Holland 7530?
Common wear and replacement parts for the Ford New Holland 7530 include the 1930581 - Filter, Fuel; Spin On, 1909130 - Filter, Hydraulic, AF25557 - Filter, Air, Primary Magnum RS, 5117314 - Tie Rod, and the 87345759 - Bearing, Clutch Release.

87395648 - MFWD Ball Joint
SKU: 87395648
52 in stock

587302 - Tie Rod Jam Nut
SKU: 587302
96 in stock

5117314 - Tie Rod
SKU: 5117314
55 in stock

5109553 - MFWD Tie Rod
SKU: 5109553
84 in stock

710754 - Gearbox Drive Belt
SKU: 710754
89 in stock

6009-2RS-I - Flat Edge Ball; 6000 Series Bearing
SKU: 6009-2RS-I
166 in stock

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED
SKU: 9703399-LED
288 in stock

87283179-LED - Replacement For H4 Bulb 600 Lumens Bulb; LED
SKU: 87283179-LED
190 in stock

87283179 - Inner H4-12V Bulb
SKU: 87283179
73 in stock

529068 - Bulb
SKU: 529068
115 in stock

1156L24 - Replaces Bulb #1156 (2 Pack) 2400 Lumens LED Bulb
SKU: 1156L24
56 in stock

1156-LED - Replaces Bulb #1156 (2 Pack) LED; 600 Lumens Bulb
SKU: 1156-LED
127 in stock

5152194 - Quick Release Coupling
SKU: 5152194
142 in stock

5129488 - Hydraulic (42 Litres/Min.) Pump
SKU: 5129488
54 in stock

5129483 - Hydraulic (31 Litres/Min.) Pump
SKU: 5129483
24 in stock

87688301 - Cab Isolator
SKU: 87688301
167 in stock

5185602 - PTO (540 RPM) Shaft
SKU: 5185602
37 in stock

5185601 - PTO; 1000 RPM Shaft
SKU: 5185601
6 in stock

86629543 - O-Ring
SKU: 86629543
319 in stock

B9NN7A381B - Transmission (2nd) Gear
SKU: B9NN7A381B
8 in stock

86502678 - Parking Brake (2 Sides Lined) Brake Pad
SKU: 86502678
29 in stock

86502677 - Parking Brake (1 Side Lined) Brake Pad
SKU: 86502677
48 in stock

99432717 - EXHAUST VALVE
SKU: 99432717
31 in stock

98461751 - Connecting Rod
SKU: 98461751
45 in stock
