Ford New Holland 640 Tractor Parts

640 parts and accessories

The Ford New Holland 640 tractor, produced from 1955 to 1957, was a popular choice for farmers due to its reliable performance and versatility. Powered by a 31 HP gasoline engine, its sturdy build and ease of use made it suitable for a variety of farm tasks. With a PTO horsepower of approximately 27, it was particularly well-suited for light to medium-duty applications.

The Ford 640 tractor was part of the "Hundred Series" introduced by Ford in the mid-1950s, marking a significant update in tractor design and functionality. It was produced from 1955 to 1957. The 640 was equipped with a Ford 134 cubic inch (2.2L) gasoline engine producing around 31 horsepower. This engine was known for its reliability and ease of maintenance. The transmission was typically a 4-speed manual gearbox, providing adequate gearing for a variety of tasks. The PTO delivered around 27 horsepower at 540 RPM. The hydraulic system had a capacity of approximately 5 gallons per minute, powering the 3-point hitch which was a Category I, making it compatible with a wide range of implements. The 640 was commonly used for row crop cultivation, hay making, and general farm maintenance. It differed from other models in the Hundred Series primarily in its features and intended use; for example, the 700 series offered live PTO and hydraulics, features the 640 typically lacked.

Specifications

Engine	Ford 134 ci (2.2L) 31 HP Gasoline
PTO HP	27 HP @ 540 RPM
Transmission	4-speed manual
Hydraulics	5 GPM, 0 remotes
3-Point Hitch	Category I, 1500 lbs lift capacity
Fuel Capacity	15 gallons
Weight	2840 lbs
Years Produced	1955-1957

Maintenance Tips

Change the engine oil and filter every 100-150 hours of operation, using a high-quality oil appropriate for gasoline engines of this era.
Regularly inspect and maintain the hydraulic system, checking for leaks and ensuring proper fluid levels. Replace hydraulic filters as needed.
Keep the fuel system clean by using a fuel stabilizer, especially during periods of inactivity. Drain the fuel tank and carburetor bowl before long-term storage.
Before winter storage, drain all fluids, grease all fittings, and store the tractor in a dry place to prevent rust and corrosion.

History & Background

The Ford 640 was introduced as a part of Ford's effort to modernize its tractor lineup in the mid-1950s. It was a key model in the popular "Hundred Series," and while it didn't receive major redesigns during its production run, it represented Ford's commitment to providing affordable and reliable tractors for the American farmer. It contributed significantly to the mechanization of smaller farms.

Frequently Asked Questions

What engine is in the Ford New Holland 640?

The Ford New Holland 640 is equipped with a Ford 134 cubic inch (2.2L) gasoline engine, producing approximately 31 horsepower.

What is the PTO horsepower on a 640?

The PTO horsepower on a Ford New Holland 640 is approximately 27 horsepower at 540 RPM.

What oil filter fits the 640?

The Ford 640 typically uses a Fram C3 or equivalent oil filter. Cross-references include Wix 51010 and NAPA 1010.

What are common parts needed for the 640?

Common parts needed for the Ford New Holland 640 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic seals, steering linkage components, clutch disc and pressure plate, and spark plugs.
