Ford New Holland 4635 Tractor Parts
4635 parts and accessories
The Ford New Holland 4635, manufactured from 1993 to 1999, was a popular utility tractor known for its reliability and versatility. Powered by a Shibaura 53 HP diesel engine, the 4635 delivered approximately 47 PTO horsepower, making it well-suited for a variety of farm tasks. Farmers appreciated its robust design and ease of operation in diverse agricultural applications.
The Ford New Holland 4635 was part of the PowerStar series and was produced from 1993 to 1999. Its lineage can be traced back to earlier Ford tractor models, inheriting a reputation for durability. The 4635 features a Shibaura N844L 2.2L 4-cylinder diesel engine, producing around 53 engine horsepower. It was offered primarily with a mechanical gear transmission, typically an 8-speed forward/2-reverse gearbox, providing a range of speeds for different operations. The PTO horsepower is approximately 47 HP, available at a standard 540 RPM. The hydraulic system delivers around 8.5 GPM, typically with one or two remote valves for operating implements. This model features a Category II 3-point hitch with a lift capacity of approximately 3,300 lbs, making it suitable for various tasks. The 4635 was commonly used for hay production, livestock management, and light tillage operations. While its horsepower and features positioned it as a mid-size utility tractor, the 4635 distinguished itself through its straightforward mechanical design, making it easy to maintain and repair. It offered a balance of power and simplicity that appealed to many farmers.
Specifications
| Engine | Shibaura N844L 53 HP Diesel |
|---|---|
| PTO HP | 47 HP @ 540 RPM |
| Transmission | Gear, 8 Forward / 2 Reverse |
| Hydraulics | 8.5 GPM, 1-2 remotes |
| 3-Point Hitch | Category II, 3300 lbs |
| Fuel Capacity | 17 gallons |
| Weight | 5300 lbs |
| Years Produced | 1993-1999 |
Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation. Use a high-quality oil meeting Ford New Holland specifications and ensure the correct oil filter is used.
- Hydraulic System: Check the hydraulic fluid level regularly and change the hydraulic filter every 500 hours. Inspect hydraulic hoses and fittings for leaks to prevent contamination.
- Fuel System: Use clean, fresh diesel fuel and replace the fuel filter annually or every 500 hours, whichever comes first. Drain any water from the fuel sediment bowl regularly to prevent fuel system issues.
- Seasonal Storage: Before storing the tractor for the off-season, fill the fuel tank to prevent condensation, change the engine oil and filter, grease all fittings, and disconnect the battery. Store the tractor in a dry location if possible.
History & Background
Introduced in 1993, the Ford New Holland 4635 replaced earlier models in the Ford lineup, offering improved engine efficiency and operator comfort. While there were no major redesigns during its production run, the 4635 remained a popular choice among farmers due to its reliability and versatility, contributing to the legacy of Ford New Holland tractors in agricultural history.
Frequently Asked Questions
What engine is in the Ford New Holland 4635?
The Ford New Holland 4635 is equipped with a Shibaura N844L 2.2L 4-cylinder diesel engine producing approximately 53 horsepower.
What is the PTO horsepower on a 4635?
The PTO horsepower on the Ford New Holland 4635 is approximately 47 HP. It operates at a standard 540 RPM.
What oil filter fits the 4635?
Common oil filters for the Ford New Holland 4635 include Fram PH3600, Wix 51348, and Ford/New Holland 86546616. Always verify compatibility with your specific tractor's manual.
What are common parts needed for the 4635?
Common wear parts for the Ford New Holland 4635 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic seals, steering components like tie rod ends, clutch discs, and pressure plates.

SK179 - Piston Liner Kit
SKU: SK179
12 in stock

5129486 - Hydraulic Pump
SKU: 5129486
Out of stock

D5NN6N609A - Oil Filler Cap
SKU: D5NN6N609A
206 in stock

99432717 - EXHAUST VALVE
SKU: 99432717
5 in stock

99432652 - Intake Valve
SKU: 99432652
Out of stock

98461686 - Oil Rear Seal
SKU: 98461686
27 in stock

4780627 - Connecting Rod Bolt
SKU: 4780627
1 in stock

4770623 - Cylinder (Semi-Finished) Liner
SKU: 4770623
40 in stock

4766404 - Connecting Rod Bushing
SKU: 4766404
75 in stock

4757883 - Fuel Lift Transfer Pump
SKU: 4757883
99 in stock

1930191 - PISTON RINGS
SKU: 1930191
15 in stock

1930186 - PISTON
SKU: 1930186
11 in stock

1930183 - Connecting Rod (.020") Bearing
SKU: 1930183
12 in stock

1930181 - Connecting Rod (Std) Bearing
SKU: 1930181
Out of stock

1930177 - Main (.010") Bearing
SKU: 1930177
8 in stock

1930176 - Main (Std) Bearing
SKU: 1930176
87 in stock

1901385 - Thrust (Std) Washer Set
SKU: 1901385
47 in stock

14196670 - Valve (10 Pair Set) Collet Half
SKU: 14196670
60 in stock

83989947 - Starter Relay
SKU: 83989947
23 in stock

500322763 - Marelli Alternator; IR/EF
SKU: 500322763
22 in stock

4728682 - Bosch Starter
SKU: 4728682
27 in stock

20A829 - Ignition Key
SKU: 20A829
70 in stock

5172480 - Cat II Replacement Ball
SKU: 5172480
49 in stock

47129342 - Lower Link Sensor Shaft Seal
SKU: 47129342
6 in stock
