Ford New Holland 4040 Tractor Parts

4040 parts and accessories

The Ford New Holland 4040 tractor, manufactured between 1983 and 1986, provided reliable performance for farmers. Typically equipped with a diesel engine producing around 52 PTO horsepower, the 4040 was a popular choice due to its versatility in handling a wide range of farm tasks. Farmers appreciated its balance of power, economy, and ease of use.

The Ford New Holland 4040 was produced from 1983 to 1986 as part of the Ford 40 Series tractors. It was designed as a utility tractor capable of handling various agricultural tasks. The engine was typically a Shibaura 2.7L 3-cylinder diesel engine producing approximately 52 PTO horsepower. This engine provided a good balance of power and fuel efficiency for farm work. Transmission options included a gear-type transmission with multiple speeds, allowing the operator to choose the optimal gear for the task at hand. The PTO operated at 540 RPM, suitable for powering a variety of implements like rotary cutters, balers, and tillers. The hydraulic system had a capacity sufficient for operating loaders and other hydraulically powered equipment. The 3-point hitch was a Category II, capable of lifting implements of moderate weight. Common farming applications included row crop cultivation, hay production, livestock operations, and light tillage. The 4040 distinguished itself from other models in the lineup by offering a solid mid-range option that was more powerful than smaller utility tractors but more economical than larger row crop tractors.

Specifications

Engine	Shibaura 2.7L 57 HP Diesel
PTO HP	52 HP @ 540 RPM
Transmission	Gear, 8 forward and 2 reverse speeds
Hydraulics	8 GPM, 2 remotes
3-Point Hitch	Category II, 2500 lbs lift capacity
Fuel Capacity	16 gallons
Weight	5300 lbs
Years Produced	1983-1986

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours using a high-quality oil that meets Ford New Holland specifications. Regularly check the oil level.
Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Use only approved hydraulic fluid to prevent damage to seals and components.
Fuel System: Use clean, high-quality fuel and replace the fuel filter annually to prevent fuel system issues. Inspect fuel lines for cracks or leaks.
Seasonal Storage: Before storing the tractor for an extended period, drain the fuel tank or add a fuel stabilizer to prevent fuel degradation. Disconnect the battery and store it in a cool, dry place.

History & Background

The Ford New Holland 4040 was introduced in 1983 as part of the updated Ford tractor lineup. It aimed to provide a dependable utility tractor for diverse farming needs. The 4040 became a popular choice during its production run, solidifying its place as a reliable workhorse on many farms.

Frequently Asked Questions

What engine is in the Ford New Holland 4040?

The Ford New Holland 4040 typically uses a Shibaura 2.7L 3-cylinder diesel engine, producing approximately 57 horsepower.

What is the PTO horsepower on a 4040?

The PTO horsepower on a Ford New Holland 4040 is around 52 HP at 540 RPM.

What oil filter fits the 4040?

Common oil filter cross-references for the Ford New Holland 4040 include Fram PH3614, Wix 51348, and Motorcraft FL-400S. Always verify compatibility with your specific tractor model.

What are common parts needed for the 4040?

Common parts needed for the Ford New Holland 4040 include engine oil filters, fuel filters, air filters, hydraulic filters, belts, hydraulic seals, steering components, and clutch parts. Regular replacement of these wear parts ensures optimal performance.
