Case IH 9120 Combine Parts

9120 parts and accessories

The Case IH 9120 combine, part of the Axial-Flow series, was manufactured from 2008 to 2011. Powered by a 350 HP engine, it could be equipped with headers up to 40 feet wide. Its single rotor design allowed for excellent grain quality and reduced grain loss, making it a popular choice for farmers harvesting various crops efficiently.

The Case IH 9120 combine was a key model in the Axial-Flow series, produced from 2008 to 2011. It features a Case IH FPT engine rated at 350 horsepower with a displacement of 8.7 liters. The single axial-flow rotor technology, specifically designed for gentle grain handling, ensures minimal damage. The grain tank capacity is 350 bushels, and it boasts an unloading auger speed of 3.2 bushels per second (192 bu/min). Available header widths ranged from 30 to 40 feet, allowing for optimal harvesting efficiency across various field sizes. Options included a fine cut chopper and adjustable spreaders for residue management. The cab features included advanced monitoring systems and enhanced operator comfort, contributing to a more productive and less fatiguing harvesting experience. The 9120 excels at harvesting crops like corn, soybeans, and wheat, offering reliable performance and efficient grain separation.

Specifications

Engine	Case IH FPT 350 HP 8.7L Diesel
Separator Type	Single Axial-Flow Rotor - 30 inch diameter
Grain Tank	350 bushels
Unloading Rate	192 bu/min
Header Widths	30-40 ft
Fuel Capacity	250 gallons
Weight	35,000 lbs
Years Produced	2008-2011

Maintenance Tips

Regularly inspect and adjust the concave clearance to optimize threshing performance and minimize grain damage.
Check and maintain proper tension on belts and chains to ensure efficient power transmission and prevent premature wear.
Clean the sieve and chaffer screens frequently to remove debris and maintain optimal airflow for effective grain cleaning.
Grease bearings regularly according to the manufacturer's recommendations to prevent friction and extend their lifespan.
Before each harvest season, thoroughly inspect all components, including belts, chains, bearings, and cutting parts, to identify and address any potential issues.

History & Background

The Case IH 9120 was introduced in 2008 as part of the Axial-Flow series, replacing older models with improved engine technology and grain handling capabilities. It represented a significant step forward in combine performance and efficiency within the Case IH lineup. The 9120 made way for the 9130 series soon after.
