Case IH 5140 Combine Parts
Replacement parts for the Case IH 5140 Combine. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The Case IH 5140 combine, produced from 2012-2016, offered a blend of reliable performance and innovative technology for mid-sized farming operations. Powered by a 265 HP engine, this combine delivered efficient harvesting. Available with header widths up to 30 feet and a rotary separator, the 5140 was popular for its versatility in harvesting wheat, corn, and soybeans.
About the 5140
The Case IH 5140 was part of the Axial-Flow series, introduced in 2012 and manufactured until 2016. It's powered by a Case IH FPT 6.7L Tier 4A diesel engine producing 265 horsepower (rated). The 5140 utilizes a single rotor Axial-Flow system for efficient threshing and separation. Its grain tank holds approximately 250 bushels, and it boasts an unloading auger speed of around 2.5 bushels per second (150 bu/min). Header widths ranged from 20 to 30 feet, accommodating various field sizes and crop types. The combine offered options for both fine cut chopper or standard spreaders. The cab featured enhanced comfort and user-friendly controls with integrated AFS (Advanced Farming Systems) technology for yield monitoring and data logging. The Case IH 5140 excels in harvesting corn, soybeans, wheat, and other small grains, providing a balance of performance and affordability.
5140 Specifications
| Engine | Case IH FPT 6.7L 265 HP Tier 4A Diesel |
|---|---|
| Separator Type | Single Rotor Axial-Flow - 30 inch rotor diameter |
| Grain Tank | 250 bushels |
| Unloading Rate | 150 bu/min |
| Header Widths | 20-30 ft |
| Fuel Capacity | 150 gallons |
| Weight | 25,000 lbs (approximate) |
| Years Produced | 2012-2016 |
5140 Maintenance Tips
- Concave Adjustment: Regularly inspect and adjust concave clearance based on the crop being harvested to ensure optimal threshing and minimize grain loss.
- Belt and Chain Tension: Check belt and chain tension throughout the combine regularly, especially before and during harvest, to prevent slippage and breakdowns. Properly tensioned belts and chains ensure smooth power transmission and optimal machine performance.
- Sieve and Chaffer Cleaning: Routinely clean the sieves and chaffer to remove debris and chaff, ensuring proper airflow and efficient grain cleaning. Clogged sieves can lead to increased grain loss and reduced harvesting efficiency.
- Bearing Greasing: Follow the manufacturer's recommended greasing schedule for all bearings, particularly those in high-wear areas like the header, feeder house, and rotor. Proper lubrication prevents premature bearing failure and extends component life.
5140 History & Background
The Case IH 5140 was introduced in 2012 as part of the Axial-Flow combine lineup, offering a mid-sized option for farmers. It incorporated updates to the cab and controls, building upon the reliability of previous Axial-Flow models. The 5140 played a significant role in providing efficient and versatile harvesting solutions for a broad range of farming operations.
Frequently Asked Questions
Which rotor bar is recommended for the Case IH 5140?
For optimal performance in your 5140 combine, consider the 1309336C2 - Rotor Bar, w/o Spike.
Which main drive belt fits the Case IH 5140 combine?
The 87476486 - Belt, Main, RH Drive w/ Chopper / Elevator Drive is a suitable replacement for the 5140.
Which front concave is suitable for the Case IH 5140?
For the front section of the separator, the 386188A1 - Concave, Front (Corn & Soybean) is designed to fit the 5140.
What are some essential wear parts for the Case IH 5140 combine?
To maintain the Case IH 5140, essential wear parts include the 386189A1 - Concave, Middle/Rear (Corn & Soybean), 87368807 - Rasp Bar, 87330903 - Belt, Straw Chopper Drive, 84163936 - Chain, Drive, Clean Grain, and 84330031 - Bearing.

87674051 - Steering Cylinder
SKU: 87674051
24 in stock

248600A1 - Axle Drive Shaft Coupling
SKU: 248600A1
42 in stock

87697371 - Outer Tie Rod
SKU: 87697371
39 in stock

87714971 - Rotor Gearbox Belt
SKU: 87714971
13 in stock

87629602 - Feeder Jackshaft Drive Belt
SKU: 87629602
Out of stock

87629601 - Feeder Drive w/ Rock Trap Belt
SKU: 87629601
11 in stock

87583785 - Air Screen Drive Belt
SKU: 87583785
28 in stock

87549557 - Unloading Drive Belt
SKU: 87549557
9 in stock

87476486 - RH Drive w/ Chopper / Elevator Drive Main Belt
SKU: 87476486
21 in stock

87330903 - Straw Chopper Drive Belt
SKU: 87330903
9 in stock

84586129 - Separator Drive Belt
SKU: 84586129
4 in stock

84548651 - Unloader Jackshaft Belt
SKU: 84548651
3 in stock

84406044 - PTO / Separator Drive sub to 84586129 Belt
SKU: 84406044
4 in stock

84312027 - Alternator Belt
SKU: 84312027
26 in stock

84292913 - AC Compressor Belt
SKU: 84292913
35 in stock

84238446 - Variable Cleaning Fan Belt
SKU: 84238446
12 in stock

84230076 - Cleaning System Drive Belt
SKU: 84230076
Out of stock

84230075 - Cleaning Fan/Elevator Jackshaft Belt
SKU: 84230075
6 in stock

84194650 - Rotor Drive; Seamless Belt
SKU: 84194650
10 in stock

84163222 - Spreader Drive Belt
SKU: 84163222
23 in stock

84150266 - Fan Drive Belt
SKU: 84150266
21 in stock

47655498 - Beater Drive Belt
SKU: 47655498
Out of stock

47616842 - Header Drive w/o Rock Trap Belt
SKU: 47616842
9 in stock

47597575 - Chopper Frail High Belt
SKU: 47597575
Out of stock
