Case IH 1440 Combine Parts
Browse Case IH 1440 Combine replacement parts. Everything from routine maintenance items to hard-to-find components.
The Case IH 1440 combine, produced from 1979-1984, was a popular choice for farmers seeking a reliable and efficient conventional combine. Powered by an engine producing around 155 horsepower, it handled a variety of crops with ease. It was typically equipped with header widths ranging from 13-20 feet, offering flexibility for different field sizes and crop conditions.
About the 1440
The Case IH 1440 combine, manufactured from 1979 to 1984, quickly earned a reputation for its robust design and straightforward operation. It was powered by an International Harvester DT-402 six-cylinder diesel engine, delivering approximately 155 horsepower with a displacement of 402 cubic inches. The 1440 utilized a conventional threshing system with a 43-inch wide cylinder, featuring rasp bars and a concave to separate grain from the crop material. It featured a grain tank capacity of around 165 bushels and an unloading rate of approximately 70 bushels per minute. Header widths available ranged from 13 to 20 feet, allowing farmers to tailor the combine to their specific needs. Options included a straw chopper or spreader for residue management. The cab provided operators with basic controls and monitoring capabilities, focusing on functionality and ease of use. The Case IH 1440 excelled in harvesting wheat, soybeans, and corn, proving to be a versatile and dependable machine.
1440 Specifications
| Engine | International Harvester DT-402 155 HP 402 CID Diesel |
|---|---|
| Separator Type | Conventional - 43-inch Cylinder |
| Grain Tank | 165 bushels |
| Unloading Rate | 70 bu/min |
| Header Widths | 13-20 ft |
| Fuel Capacity | 75 gallons |
| Weight | 15,800 lbs |
| Years Produced | 1979-1984 |
1440 Maintenance Tips
- Concave Adjustment: Regularly inspect and adjust concave clearance based on the crop being harvested. Proper adjustment minimizes grain loss and maximizes threshing efficiency.
- Belt and Chain Tension: Routinely check belt and chain tension throughout the combine, particularly on the header, feeder house, and threshing mechanism. Loose belts and chains can cause slippage and damage.
- Sieve and Chaffer Cleaning: Clean the sieves and chaffer regularly to remove debris and ensure proper air flow. Clogged sieves can lead to excessive grain loss over the back.
- Bearing Greasing: Follow the recommended greasing schedule for all bearings on the combine, paying close attention to bearings on rotating components like the cylinder, augers, and cleaning fan.
1440 History & Background
Introduced in 1979, the Case IH 1440 was a significant model in the Case IH lineup, offering a mid-sized conventional combine option. While there weren't major redesigns during its production run, it represented a solid design that built upon the success of previous IH combines. It served as a reliable and affordable option for many farmers during its time.
Frequently Asked Questions
Which lube filter is recommended for the Case IH 1440 combine?
The recommended full-flow spin-on lube filter for this model is LF3316 - Filter, Lube, Full-Flow Spin-On.
What bearing is used in the grain tank / delivery auger for the Case IH 1440?
For the grain tank and delivery auger, you'll need the 204807C91 - Bearing, Grain Tank / Delivery Auger.
What rotor bar fits the Case IH 1440 combine's threshing system?
The threshing system on the Case IH 1440 can use the 1309336C2 - Rotor Bar, w/o Spike.
What are common wear and replacement parts for the Case IH 1440 combine?
Common wear parts for the Case IH 1440 combine include replacement 1309336C2 - Rotor Bar, w/o Spike for the threshing system, 195293C91 - Bearing, Auger Bed & Straw Spreader for auger systems, and 186597C1 - Bushing, Chaffer Drive Hanger Arm. Other frequently needed items include various 128825 - O-Ring seals, and electrical components like the 87271837 - Switch, Flasher Control.

87337229 - Steering Cylinder Assy
SKU: 87337229
5 in stock

548247R91 - w/o Power Guide Axle Steering Hydraulic Cylinder
SKU: 548247R91
8 in stock

193912C3 - Steering (RH) Arm
SKU: 193912C3
41 in stock

193911C4 - Steering (LH) Arm
SKU: 193911C4
41 in stock

186796C1 - Cylinder End
SKU: 186796C1
20 in stock

186140C91 - Steering Cylinder End
SKU: 186140C91
20 in stock

182795C1 - Steering Axle Support Bushing
SKU: 182795C1
34 in stock

182794C1 - Pivot; Rear Axle Bushing
SKU: 182794C1
169 in stock

177751C1 - Axle Pivot Bushing
SKU: 177751C1
9 in stock

169293C11 - Steering Axle Hub
SKU: 169293C11
28 in stock

168385C2 - Axle Pivot Washer
SKU: 168385C2
103 in stock

1315374C2 - Spindle (RH/LH)
SKU: 1315374C2
19 in stock

1302687C1 - Tie Rod (RH)
SKU: 1302687C1
7 in stock

1302686C1 - Tie Rod (LH)
SKU: 1302686C1
5 in stock

184342C1 - Final Drive Coupler
SKU: 184342C1
20 in stock

184341C2 - Axle Drive Shaft Coupling
SKU: 184341C2
74 in stock

A145857 - Tie Rod Wedge
SKU: A145857
27 in stock

44995098 - Wheel Seal
SKU: 44995098
198 in stock

379551R92 - Short Tie Rod
SKU: 379551R92
20 in stock

374062R1 - Jam Nut
SKU: 374062R1
350 in stock

BC108 - Bearing (Import) Collar
SKU: BC108
90 in stock

BC102 - Bearing (Import) Collar
SKU: BC102
61 in stock

BC100 - Bearing (Import) Collar
SKU: BC100
392 in stock

167269 - O-Ring
SKU: 167269
9 in stock
