Case IH 2344 Combine Parts
Case IH 2344 Combine parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The Case IH 2344 combine, manufactured from 1996 to 2001, was a popular choice for farmers seeking reliable performance. Powered by a 165 HP engine and capable of handling header widths up to 30 feet, the 2344 featured a conventional separator. Its affordability and ability to efficiently harvest a variety of crops made it a staple in many fields.
About the 2344
The Case IH 2344 combine was introduced in 1996 as part of the 2300 series, succeeding earlier models and offering enhanced harvesting capabilities. Production continued until 2001. It's powered by a Case IH 8.3L 6-cylinder diesel engine producing 165 horsepower. The 2344 utilizes a conventional threshing system with a 31.5-inch wide cylinder, renowned for its gentler handling of grain. Grain tank capacity is approximately 172 bushels, and unloading is achieved at a rate of around 2.0 bushels per second (120 bu/min). Available header widths range from 15 to 30 feet, accommodating various field sizes and crop types. Options included straw chopper and spreader attachments for residue management. The cab offered basic operator comfort and controls, providing essential functions for harvesting. The Case IH 2344 excels at harvesting wheat, soybeans, corn, and other small grains, making it a versatile machine for diverse farming operations.
2344 Specifications
| Engine | Case IH 8.3L 165 HP Diesel |
|---|---|
| Separator Type | Conventional - 31.5" Cylinder |
| Grain Tank | 172 bushels |
| Unloading Rate | 120 bu/min |
| Header Widths | 15-30 ft |
| Fuel Capacity | 75 gallons |
| Weight | Approx. 18,000 lbs |
| Years Produced | 1996-2001 |
2344 Maintenance Tips
- Concave Adjustment: Regularly inspect and adjust concave clearance according to the crop being harvested to optimize threshing performance and minimize grain damage.
- Belt and Chain Tension: Check belt and chain tension frequently and adjust as needed to prevent slippage and ensure proper power transmission to all components.
- Sieve and Chaffer Cleaning: Regularly clean the sieves and chaffers to remove debris and ensure proper separation of grain from chaff, preventing losses and improving sample quality.
- Bearing Greasing: Grease all bearings according to the manufacturer's recommendations to prevent premature wear and ensure smooth operation of all moving parts.
2344 History & Background
The Case IH 2344 was introduced in 1996 as an upgrade to previous Case IH combine models, offering improvements in efficiency and reliability. While it didn't undergo major redesigns during its production run, it solidified Case IH's position in the mid-sized combine market, providing a cost-effective solution for many farmers.
Frequently Asked Questions
Which rotor bar is suitable for the Case IH 2344 combine?
The 1309336C2 - Rotor Bar, w/o Spike is an excellent choice for replacement on your Case IH 2344.
What bearing is recommended for the elevator drive on a Case IH 2344?
For the elevator drive on your 2344, the 156010C92 - Bearing, Elevator Drive/ Auger Trough is a suitable replacement part.
Which bushing fits the shaker shaft on a Case IH 2344?
The 87376924 - Bushing, Shaker Shaft / Chaffer Drive Arm is designed for the shaker shaft and chaffer drive arm on your 2344 combine.
What are common replacement parts for the Case IH 2344?
Many owners frequently replace items like the 1309336C2 - Rotor Bar, w/o Spike, 1200-90 - Rotor Bar Hardware Kit, Standard Bolts and Nuts, RA100RRB-I - Bearing, Ball; Spherical W/ Collar, Non-Relubricatable, 87538600 - Rubber Bushing, 87283349 - Link, Connecting; A557 Chain, and various 128825 - O-Ring seals.

9512162 - King Pin (Bronze) Bushing
SKU: 9512162
36 in stock

87337229 - Steering Cylinder Assy
SKU: 87337229
5 in stock

87012417 - Tie Rod; Inner Tube
SKU: 87012417
Out of stock

548247R91 - w/o Power Guide Axle Steering Hydraulic Cylinder
SKU: 548247R91
8 in stock

437222A1 - Steering Cylinder Ball Joint
SKU: 437222A1
16 in stock

359774A1 - Tie Rod (LH)
SKU: 359774A1
7 in stock

316945A1 - Steering Cyl Support
SKU: 316945A1
8 in stock

1970143C1 - King Pin
SKU: 1970143C1
9 in stock

1968998C1 - Tie Rod End Assembly
SKU: 1968998C1
17 in stock

193912C3 - Steering (RH) Arm
SKU: 193912C3
41 in stock

193911C4 - Steering (LH) Arm
SKU: 193911C4
41 in stock

186796C1 - Cylinder End
SKU: 186796C1
20 in stock

186680C1 - Spindle Bushing
SKU: 186680C1
14 in stock

186140C91 - Steering Cylinder End
SKU: 186140C91
20 in stock

186052C1 - Steering Knuckle King Pin
SKU: 186052C1
4 in stock

182795C1 - Steering Axle Support Bushing
SKU: 182795C1
34 in stock

182794C1 - Pivot; Rear Axle Bushing
SKU: 182794C1
169 in stock

177751C1 - Axle Pivot Bushing
SKU: 177751C1
9 in stock

169293C11 - Steering Axle Hub
SKU: 169293C11
28 in stock

168385C2 - Axle Pivot Washer
SKU: 168385C2
103 in stock

1315374C2 - Spindle (RH/LH)
SKU: 1315374C2
19 in stock

1302687C1 - Tie Rod (RH)
SKU: 1302687C1
7 in stock

1302686C1 - Tie Rod (LH)
SKU: 1302686C1
5 in stock

663557R1 - Bearing (LM501349)
SKU: 663557R1
258 in stock
