Case IH 5140 Combine Parts

5140 parts and accessories

The Case IH 5140 combine, produced from 2012-2016, offered a blend of reliable performance and innovative technology for mid-sized farming operations. Powered by a 265 HP engine, this combine delivered efficient harvesting. Available with header widths up to 30 feet and a rotary separator, the 5140 was popular for its versatility in harvesting wheat, corn, and soybeans.

The Case IH 5140 was part of the Axial-Flow series, introduced in 2012 and manufactured until 2016. It's powered by a Case IH FPT 6.7L Tier 4A diesel engine producing 265 horsepower (rated). The 5140 utilizes a single rotor Axial-Flow system for efficient threshing and separation. Its grain tank holds approximately 250 bushels, and it boasts an unloading auger speed of around 2.5 bushels per second (150 bu/min). Header widths ranged from 20 to 30 feet, accommodating various field sizes and crop types. The combine offered options for both fine cut chopper or standard spreaders. The cab featured enhanced comfort and user-friendly controls with integrated AFS (Advanced Farming Systems) technology for yield monitoring and data logging. The Case IH 5140 excels in harvesting corn, soybeans, wheat, and other small grains, providing a balance of performance and affordability.

Specifications

Engine	Case IH FPT 6.7L 265 HP Tier 4A Diesel
Separator Type	Single Rotor Axial-Flow - 30 inch rotor diameter
Grain Tank	250 bushels
Unloading Rate	150 bu/min
Header Widths	20-30 ft
Fuel Capacity	150 gallons
Weight	25,000 lbs (approximate)
Years Produced	2012-2016

Maintenance Tips

Concave Adjustment: Regularly inspect and adjust concave clearance based on the crop being harvested to ensure optimal threshing and minimize grain loss.
Belt and Chain Tension: Check belt and chain tension throughout the combine regularly, especially before and during harvest, to prevent slippage and breakdowns. Properly tensioned belts and chains ensure smooth power transmission and optimal machine performance.
Sieve and Chaffer Cleaning: Routinely clean the sieves and chaffer to remove debris and chaff, ensuring proper airflow and efficient grain cleaning. Clogged sieves can lead to increased grain loss and reduced harvesting efficiency.
Bearing Greasing: Follow the manufacturer's recommended greasing schedule for all bearings, particularly those in high-wear areas like the header, feeder house, and rotor. Proper lubrication prevents premature bearing failure and extends component life.

History & Background

The Case IH 5140 was introduced in 2012 as part of the Axial-Flow combine lineup, offering a mid-sized option for farmers. It incorporated updates to the cab and controls, building upon the reliability of previous Axial-Flow models. The 5140 played a significant role in providing efficient and versatile harvesting solutions for a broad range of farming operations.

Frequently Asked Questions

What engine is in the Case Ih 5140?

The Case IH 5140 is equipped with a Case IH FPT 6.7L Tier 4A diesel engine, rated at 265 horsepower.

What is the grain tank capacity on a 5140?

The grain tank capacity on the Case IH 5140 is approximately 250 bushels with an unloading rate of 150 bushels per minute (2.5 bushels per second).

What type of separator does the 5140 have?

The Case IH 5140 features a single rotor Axial-Flow separator, a rotary system known for its efficient threshing and separation capabilities.

What are common parts needed for the 5140?

Common parts needed for the Case IH 5140 include concaves, rasp bars, belts, chains, bearings, auger fingers, and sickle sections. Regular replacement of these wear parts ensures optimal combine performance.
