Case IH MXU135 Tractor Parts

Case IH MXU135 Tractor parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.

The Case IH MXU135, manufactured from 2003 to 2007, is a reliable workhorse powered by a robust 6.7L Cummins diesel engine producing approximately 135 engine horsepower. With a PTO horsepower around 115, the MXU135 quickly became a favorite among farmers for its versatility and ability to handle a wide range of tasks, from tillage to haying.

About the MXU135

The Case IH MXU135 tractor was introduced as part of the MXU series, filling a crucial role in the mid-size utility tractor segment from 2003 to 2007. This model features a 6.7L Cummins diesel engine, delivering around 135 engine horsepower. The engine's displacement ensures sufficient torque for demanding agricultural applications. Transmission options primarily included a partial powershift transmission offering multiple speeds forward and reverse, providing flexibility for various field conditions. The MXU135 boasts a PTO horsepower rating of approximately 115, offering both 540 and 1000 RPM PTO speeds, making it compatible with a wide range of implements. Its hydraulic system has a capacity of around 27 GPM, powering multiple remotes for hydraulic implements. The tractor is equipped with a Category II 3-point hitch, capable of lifting around 8,157 lbs. Common farming applications included row crop work, hay production, livestock operations, and light tillage. The MXU135 distinguishes itself through its comfortable cab, reliable engine, and versatile functionality, offering a balance of power and maneuverability compared to larger models in the Case IH lineup.

MXU135 Specifications

EngineCummins 6.7L 135 HP Diesel
PTO HP115 HP @ 540/1000 RPM
TransmissionPartial Powershift, 16x16
Hydraulics27 GPM, 2-3 remotes
3-Point HitchCategory II, 8,157 lbs
Fuel Capacity44 gallons
Weight12,786 lbs
Years Produced2003-2007

MXU135 Maintenance Tips

  • Check engine oil level and condition regularly, replacing oil and filter every 250 hours, or as recommended in the operator's manual. Use the correct type of oil specified for the Cummins engine.
  • Inspect and clean or replace hydraulic filters every 500 hours to maintain proper hydraulic system performance. Check hydraulic oil levels and for any leaks in hoses and fittings.
  • Regularly inspect the fuel system for leaks and ensure the fuel filter is clean. Drain water from the fuel tank to prevent fuel contamination and injector issues.
  • Before seasonal storage, completely fill the fuel tank to minimize condensation, change engine oil and filters, grease all fittings, and disconnect the battery to prevent drainage. Store the tractor in a dry, covered location.

MXU135 History & Background

The Case IH MXU135 was part of the MXU series introduced in the early 2000s, representing a modern update to Case IH's utility tractor offerings. While not subject to major redesigns during its production run, it solidified Case IH's position in the mid-range agricultural tractor market, offering a blend of power and efficiency.

Frequently Asked Questions

Which fuel filter fits the Case IH MXU135?

The 87329736 - Filter, Fuel; In-Line is a direct fit for the MXU135.

Which PTO shaft is used on the Case IH MXU135?

The 87308746 - Shaft, PTO is a suitable replacement component for the MXU135.

Which cab air filter is suitable for the Case IH MXU135?

The 87726675 - Filter; Cab Air ensures clean air inside the cab of your MXU135.

What are some common replacement parts for the Case IH MXU135?

Showing 1-24 of 239 products
