Case IH 1026 Tractor Parts

Shop Case IH 1026 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.

The Case IH 1026 was a popular tractor manufactured from 1971 to 1976, known for its reliable power and versatility on the farm. Powered by a 404 cubic inch diesel engine producing around 121 horsepower, with approximately 105 PTO horsepower, this model provided a significant upgrade in power for farmers tackling demanding tasks. Its robust construction and straightforward design made it a favorite for row crop work, haying operations, and general farm duties.

About the 1026

The Case IH 1026 tractor was introduced in 1971 and produced until 1976, succeeding earlier International Harvester models in the lineup. This tractor features a reliable International Harvester DT-404 diesel engine, delivering approximately 121 engine horsepower and 105 PTO horsepower. The DT-404 is a 404 cubic inch, 6-cylinder, direct-injection diesel engine known for its durability and fuel efficiency. Transmission options included a gear-drive transmission with varying speeds depending on the configuration, typically offering multiple forward and reverse speeds. The 1026 featured a standard 540 RPM PTO, providing power for a wide range of implements. The hydraulic system delivered around 16 GPM of flow, powering multiple remote valves for implements such as planters and cultivators. The 3-point hitch was typically a Category II hitch, capable of lifting several thousand pounds, depending on the specific configuration. The 1026 found applications in row crop farming, hay production, livestock operations for tasks like baling and feeding, and tillage work. Its higher horsepower set it apart from smaller utility tractors in the IH lineup, while its sturdy build distinguished it from lighter row crop tractors.

1026 Specifications

EngineInternational Harvester DT-404 121 HP Diesel
PTO HP105 HP @ 540 RPM
TransmissionGear Drive, 8/4 speeds
Hydraulics16 GPM, 2 remotes
3-Point HitchCategory II, 5500 lbs lift capacity
Fuel Capacity37 gallons
Weight11,285 lbs
Years Produced1971-1976

1026 Maintenance Tips

  • Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using a high-quality diesel engine oil and a filter designed for the IH DT-404 engine. Regularly check the oil level and condition.
  • Hydraulic System: Inspect hydraulic fluid levels and check for leaks regularly. Change hydraulic fluid and filter every 500 hours or annually, using only fluids that meet IH specifications to protect the hydraulic pump and components.
  • Fuel System: Use clean, high-quality diesel fuel. Replace fuel filters at recommended intervals to prevent fuel system issues. Consider using a fuel additive during cold weather to prevent gelling.
  • Seasonal Storage: Before storing your 1026 for the off-season, drain the fuel tank or add a fuel stabilizer. Grease all lubrication points, disconnect the battery, and store the tractor in a dry place.

1026 History & Background

The Case IH 1026 was part of International Harvester's (later Case IH) line of powerful row-crop tractors introduced in the early 1970s. It offered a significant step up in horsepower and capabilities compared to previous models. The 1026 played a crucial role in helping farmers increase their productivity during a period of agricultural expansion and technological advancements.

Frequently Asked Questions

Which flywheel ring gear is compatible with the Case IH 1026?

For the Case IH 1026, the recommended flywheel ring gear is 341604R1 - Ring Gear, Flywheel.

What PTO clutch disc kit is recommended for the 1026?

A suitable PTO clutch disc kit for the Case IH 1026 is 68803C91 - PTO Clutch Disc Kit, Consist Of:.

Which brake disc fits the Case IH 1026?

The 104712C21 - Brake Disc is designed for the Case IH 1026.

What are some common replacement parts for the Case IH 1026?

Showing 1-24 of 291 products
SK413 - Piston Liner Kit

SK413 - Piston Liner Kit

SKU: SK413

$325.94

69 in stock

531851R1 - Front Axle Clamp Pin
Out of Stock

531851R1 - Front Axle Clamp Pin

SKU: 531851R1

$30.94

Out of stock

39-5698 - Pivot Pin Retaining Pin
Out of Stock

39-5698 - Pivot Pin Retaining Pin

SKU: 39-5698

$3.72

Out of stock

384006R1 - inner Ref 12 - Tie rod

384006R1 - inner Ref 12 - Tie rod

SKU: 384006R1

$21.51

499 in stock

383917R1 - Tube

383917R1 - Tube

SKU: 383917R1

$49.47

238 in stock

374062R1 - Jam Nut

374062R1 - Jam Nut

SKU: 374062R1

$9.51

350 in stock

370689R21 - w/ Bushings Knee

370689R21 - w/ Bushings Knee

SKU: 370689R21

$372.01

59 in stock

359986R1 - Clamp

359986R1 - Clamp

SKU: 359986R1

$3.90

340 in stock

359984R1 - outer Ref 13 - Tie rod

359984R1 - outer Ref 13 - Tie rod

SKU: 359984R1

$41.01

415 in stock

223313 - Complete Tie Rod Assembly

223313 - Complete Tie Rod Assembly

SKU: 223313

$95.46

349 in stock

LM603049-I - Tapered Roller Bearing Cone

LM603049-I - Tapered Roller Bearing Cone

SKU: LM603049-I

$11.19

336 in stock

LM603011-I - Tapered Bearing Cup

LM603011-I - Tapered Bearing Cup

SKU: LM603011-I

$6.03

94 in stock

LM48548-I - Tapered Roller Bearing Cone

LM48548-I - Tapered Roller Bearing Cone

SKU: LM48548-I

$7.90

794 in stock

LM48510-I - Tapered Bearing Cup

LM48510-I - Tapered Bearing Cup

SKU: LM48510-I

$3.38

340 in stock

WL7610 - Trapezoid LED Light Assembly

WL7610 - Trapezoid LED Light Assembly

SKU: WL7610

$102.38

98 in stock

WL7606 - Flood LED Light Assembly

WL7606 - Flood LED Light Assembly

SKU: WL7606

$102.38

92 in stock

WL2116 - 4 1/2" Diameter Trapezoid LED Sealed Beam

WL2116 - 4 1/2" Diameter Trapezoid LED Sealed Beam

SKU: WL2116

$83.35

341 in stock

WL1116 - 4 1/2" Diameter Flood LED Sealed Beam

WL1116 - 4 1/2" Diameter Flood LED Sealed Beam

SKU: WL1116

$70.46

1157 in stock

C5NN13N359E - Warning Lamp / Turn Signal (12 Volt)

C5NN13N359E - Warning Lamp / Turn Signal (12 Volt)

SKU: C5NN13N359E

$32.92

96 in stock

A42294 - Sealed Beam Bulb (12 Volt)

A42294 - Sealed Beam Bulb (12 Volt)

SKU: A42294

$14.49

340 in stock

388947R1 - Lamp Retainer

388947R1 - Lamp Retainer

SKU: 388947R1

$5.36

178 in stock

373662R1 - Sealed Beam Bulb (12 Volt)

373662R1 - Sealed Beam Bulb (12 Volt)

SKU: 373662R1

$11.28

246 in stock

28A157 - H7606 Halogen Sealed Beam Lamps

28A157 - H7606 Halogen Sealed Beam Lamps

SKU: 28A157

$20.07

53 in stock

130609 - AMBER FL LIGHT

130609 - AMBER FL LIGHT

SKU: 130609

$33.86

96 in stock
