Case IH 1370 Tractor Parts

1370 parts and accessories

The Case IH 1370 was a popular agricultural tractor produced from 1972 to 1978, known for its reliable performance in various farming applications. Powered by a 401 cubic inch diesel engine producing approximately 130 horsepower, and with a PTO horsepower rating around 110, the 1370 offered farmers a balance of power and versatility for tasks like plowing, planting, and haying.

The Case IH 1370 was introduced in 1972 as part of the 70 series, replacing earlier models in the Case lineup. Production continued until 1978. It's equipped with a Case-built 401 cubic inch (6.6L) diesel engine, delivering around 130 engine horsepower. The transmission is typically a gear-type, offering 8 forward and 2 reverse speeds, providing a good range for field work. The PTO delivers approximately 110 horsepower, available in both 540 and 1000 RPM configurations, catering to various implement requirements. Hydraulic capacity is around 25 gallons per minute, with 2-3 remote valves, suitable for operating hydraulic implements. The 3-point hitch is a Category II, with a lift capacity of around 6,000 lbs, allowing it to handle a wide array of implements. Common applications included row crop work, hay production, livestock operations, and general tillage. Distinguishing it from other models in the Case lineup, the 1370 offered a higher horsepower option compared to the smaller models but was more compact and agile than the larger frame machines.

Specifications

Engine	Case 401 CI Diesel
PTO HP	110 HP @ 540/1000 RPM
Transmission	Gear, 8 Forward/2 Reverse
Hydraulics	25 GPM, 2-3 remotes
3-Point Hitch	Category II, 6000 lbs lift
Fuel Capacity	37 gallons
Weight	11,500 lbs
Years Produced	1972-1978

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using a high-quality oil meeting Case IH specifications. Keep the air filter clean, replacing it as needed based on dusty conditions.
Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and maintain optimal performance.
Fuel System: Use clean, high-quality diesel fuel and regularly check the fuel filter, replacing it annually or more frequently if signs of contamination are present.
Seasonal Storage: Before storing the tractor for the off-season, fill the fuel tank to prevent condensation, change the engine oil and filter, grease all fittings, and disconnect the battery.

History & Background

The Case IH 1370 was launched in 1972 as part of Case's updated tractor series, offering improved operator comfort and performance. While there were no major redesigns during its production run, the 1370 played a significant role in helping farmers transition to larger-scale operations, providing a reliable and capable machine for various agricultural tasks.

Frequently Asked Questions

What engine is in the Case Ih 1370?

The Case IH 1370 is equipped with a Case-built 401 cubic inch (6.6L) diesel engine producing approximately 130 horsepower.

What is the PTO horsepower on a 1370?

The Case IH 1370 has a PTO horsepower rating of approximately 110 HP, available at both 540 and 1000 RPM.

What oil filter fits the 1370?

The Case IH 1370 typically uses a Case IH oil filter part number SE0304, or equivalent cross-references such as Wix 51794 or Fram PH3754.

What are common parts needed for the 1370?

Commonly needed parts for the Case IH 1370 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic cylinder seal kits, tie rod ends, clutch disc and pressure plate, and various gaskets and O-rings.
