Case IH 1594 Tractor Parts

Shop Case IH 1594 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.

The Case IH 1594 was a popular agricultural tractor produced in the late 1980s and early 1990s. Known for its robust design and reliability, the 1594 was powered by a diesel engine producing around 86 horsepower, offering a PTO horsepower of approximately 75. Its versatility and performance made it a favorite among farmers for various tasks, contributing to its lasting reputation.

About the 1594

The Case IH 1594 was manufactured from 1986 to 1991, building upon the legacy of its predecessors while incorporating improvements for enhanced performance. It was equipped with a Perkins A4.248 diesel engine, a naturally aspirated four-cylinder engine with a displacement of 248 cubic inches and rated for approximately 86 horsepower. The tractor typically featured a manual transmission with multiple gear options, providing a range of speeds suitable for different field operations. The PTO delivered around 75 horsepower, available in both 540 and 1000 RPM configurations. The hydraulic system had a capacity of around 12 GPM, supporting various implements with two or more remote valves. A Category II 3-point hitch allowed for the use of a wide range of implements. Farmers commonly used the 1594 for tasks like plowing, disking, planting row crops, baling hay, and general livestock operations. Distinguishing it from other models in the Case IH lineup of the time, the 1594 struck a balance between power, size, and affordability, making it a workhorse for diverse farming needs.

1594 Specifications

EnginePerkins A4.248 86 HP Diesel
PTO HP75 HP @ 540/1000 RPM
TransmissionManual, 12 forward / 4 reverse
Hydraulics12 GPM, 2 remotes
3-Point HitchCategory II, 4400 lbs lift capacity
Fuel Capacity25 gallons
Weight7400 lbs
Years Produced1986-1991

1594 Maintenance Tips

  • Engine Oil & Filter: Change engine oil and filter every 250 hours using the recommended oil type for the Perkins A4.248 diesel.
  • Hydraulic System: Inspect hydraulic fluid levels regularly and change hydraulic filters every 500 hours to prevent contamination and maintain optimal performance.
  • Fuel System: Use clean fuel and replace fuel filters every 300 hours. Treat fuel with stabilizer during seasonal storage to prevent fuel degradation.

1594 History & Background

Introduced in 1986, the Case IH 1594 was part of a series of tractors designed to provide reliable performance and versatility. There were no significant redesigns during its production run, which spanned until 1991. The 1594 played a vital role in helping farmers improve their efficiency and productivity during a period of agricultural change.

Frequently Asked Questions

Which fuel filter is suitable for the Case IH 1594?

The 500625 - FUEL FILTER is a suitable replacement fuel filter for the Case IH 1594.

What replacement starter is recommended for the Case IH 1594?

The K953785 - Starter, Lucas is a recommended starter for the Case IH 1594.

Which 180° thermostat is suitable for the Case IH 1594?

The 3042303R1 - Thermostat (180°) is a suitable replacement 180° thermostat for the Case IH 1594.

What are common replacement parts for the Case IH 1594?

Showing 1-24 of 185 products
SK483 - Piston Liner Kit

SK483 - Piston Liner Kit

SKU: SK483

$109.82

5 in stock

SC200 - Cylinder (Semi-Finished) Liner

SC200 - Cylinder (Semi-Finished) Liner

SKU: SC200

$62.65

30 in stock

K260254 - Tie Rod End

K260254 - Tie Rod End

SKU: K260254

$49.26

42 in stock

K260250 - Tie Rod End

K260250 - Tie Rod End

SKU: K260250

$49.26

46 in stock

K207722 - Drag Link

K207722 - Drag Link

SKU: K207722

$38.58

66 in stock

9967993 - 4WD Front Axle Bushing

9967993 - 4WD Front Axle Bushing

SKU: 9967993

$181.56

43 in stock

WL1300 - Rectangle Hi / Low Flood / Spot Combo LED Work Lamp

WL1300 - Rectangle Hi / Low Flood / Spot Combo LED Work Lamp

SKU: WL1300

$108.57

243 in stock

WL1295 - Rectangle Flood / Spot Combo LED Work Lamp
Out of Stock

WL1295 - Rectangle Flood / Spot Combo LED Work Lamp

SKU: WL1295

$108.57

Out of stock

E35556 - 10 Watt Dome Lamp; 12V Bulb

E35556 - 10 Watt Dome Lamp; 12V Bulb

SKU: E35556

$4.28

354 in stock

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED

SKU: 9703399-LED

$19.84

288 in stock

87283179-LED - Replacement For H4 Bulb 600 Lumens Bulb; LED

87283179-LED - Replacement For H4 Bulb 600 Lumens Bulb; LED

SKU: 87283179-LED

$19.90

190 in stock

87283179 - Inner H4-12V Bulb

87283179 - Inner H4-12V Bulb

SKU: 87283179

$8.50

73 in stock

1333295C1 - LH Dip Headlamp (RH/LH)

1333295C1 - LH Dip Headlamp (RH/LH)

SKU: 1333295C1

$51.76

7 in stock

1312210C2 - Side Headlight/Worklight Lamp Bulb H3 12V 55W

1312210C2 - Side Headlight/Worklight Lamp Bulb H3 12V 55W

SKU: 1312210C2

$6.71

19 in stock

K946083 - Power Steering Motor

K946083 - Power Steering Motor

SKU: K946083

$556.94

27 in stock

K944947 - Hydraulic Pump Drive Shaft Coupler

K944947 - Hydraulic Pump Drive Shaft Coupler

SKU: K944947

$121.22

41 in stock

K201984 - Hydraulic Pump Drive w/ A/C Coupler

K201984 - Hydraulic Pump Drive w/ A/C Coupler

SKU: K201984

$189.60

14 in stock

K200465 - Hydraulic Pump Drive w/o A/C Coupler

K200465 - Hydraulic Pump Drive w/o A/C Coupler

SKU: K200465

$164.94

8 in stock

K200464 - Hydraulic Pump Drive Shaft

K200464 - Hydraulic Pump Drive Shaft

SKU: K200464

$121.46

34 in stock

K914312 - Front Wheel 5.5" X 16" Rim

K914312 - Front Wheel 5.5" X 16" Rim

SKU: K914312

$115.92

260 in stock

E1ADKN1015A - Front Wheel 5.5" X 16" Rim

E1ADKN1015A - Front Wheel 5.5" X 16" Rim

SKU: E1ADKN1015A

$115.92

260 in stock

E1ADDN1015B - Front Wheel 5.5" X 16" Rim

E1ADDN1015B - Front Wheel 5.5" X 16" Rim

SKU: E1ADDN1015B

$115.92

260 in stock

D8NN1007BA - Front Wheel 5.5" X 16" Rim

D8NN1007BA - Front Wheel 5.5" X 16" Rim

SKU: D8NN1007BA

$115.92

260 in stock

D2NN1007S - Front Wheel 5.5" X 16" Rim

D2NN1007S - Front Wheel 5.5" X 16" Rim

SKU: D2NN1007S

$115.92

260 in stock
