Case IH MXU135 Tractor Parts
Case IH MXU135 Tractor parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.
The Case IH MXU135, manufactured from 2003 to 2007, is a reliable workhorse powered by a robust 6.7L Cummins diesel engine producing approximately 135 engine horsepower. With a PTO horsepower around 115, the MXU135 quickly became a favorite among farmers for its versatility and ability to handle a wide range of tasks, from tillage to haying.
About the MXU135
The Case IH MXU135 tractor was introduced as part of the MXU series, filling a crucial role in the mid-size utility tractor segment from 2003 to 2007. This model features a 6.7L Cummins diesel engine, delivering around 135 engine horsepower. The engine's displacement ensures sufficient torque for demanding agricultural applications. Transmission options primarily included a partial powershift transmission offering multiple speeds forward and reverse, providing flexibility for various field conditions. The MXU135 boasts a PTO horsepower rating of approximately 115, offering both 540 and 1000 RPM PTO speeds, making it compatible with a wide range of implements. Its hydraulic system has a capacity of around 27 GPM, powering multiple remotes for hydraulic implements. The tractor is equipped with a Category II 3-point hitch, capable of lifting around 8,157 lbs. Common farming applications included row crop work, hay production, livestock operations, and light tillage. The MXU135 distinguishes itself through its comfortable cab, reliable engine, and versatile functionality, offering a balance of power and maneuverability compared to larger models in the Case IH lineup.
MXU135 Specifications
| Engine | Cummins 6.7L 135 HP Diesel |
|---|---|
| PTO HP | 115 HP @ 540/1000 RPM |
| Transmission | Partial Powershift, 16x16 |
| Hydraulics | 27 GPM, 2-3 remotes |
| 3-Point Hitch | Category II, 8,157 lbs |
| Fuel Capacity | 44 gallons |
| Weight | 12,786 lbs |
| Years Produced | 2003-2007 |
MXU135 Maintenance Tips
- Check engine oil level and condition regularly, replacing oil and filter every 250 hours, or as recommended in the operator's manual. Use the correct type of oil specified for the Cummins engine.
- Inspect and clean or replace hydraulic filters every 500 hours to maintain proper hydraulic system performance. Check hydraulic oil levels and for any leaks in hoses and fittings.
- Regularly inspect the fuel system for leaks and ensure the fuel filter is clean. Drain water from the fuel tank to prevent fuel contamination and injector issues.
- Before seasonal storage, completely fill the fuel tank to minimize condensation, change engine oil and filters, grease all fittings, and disconnect the battery to prevent drainage. Store the tractor in a dry, covered location.
MXU135 History & Background
The Case IH MXU135 was part of the MXU series introduced in the early 2000s, representing a modern update to Case IH's utility tractor offerings. While not subject to major redesigns during its production run, it solidified Case IH's position in the mid-range agricultural tractor market, offering a blend of power and efficiency.
Frequently Asked Questions
Which fuel filter fits the Case IH MXU135?
The 87329736 - Filter, Fuel; In-Line is a direct fit for the MXU135.
Which PTO shaft is used on the Case IH MXU135?
The 87308746 - Shaft, PTO is a suitable replacement component for the MXU135.
Which cab air filter is suitable for the Case IH MXU135?
The 87726675 - Filter; Cab Air ensures clean air inside the cab of your MXU135.
What are some common replacement parts for the Case IH MXU135?
Commonly replaced parts for the MXU135 include the J911572 - Belt, Fan, Alt, WP, 235760 - O-Ring, Hydraulic Lift Piston, 83903309 - Bushing, Spindle, E0NNB726AB - Brake Band, PTO, and the WL2448R - Headlight, LED, RH, Hi / Low.

87395648 - MFWD Ball Joint
SKU: 87395648
52 in stock

81864106 - Long Tie Rod
SKU: 81864106
5 in stock

81864100 - Tie Rod End
SKU: 81864100
43 in stock

81863815 - Barrel End Steering Cylinder Ball Joint
SKU: 81863815
11 in stock

81863813 - Tie Rod
SKU: 81863813
31 in stock

81812303 - SUB TO WBKFD6
SKU: 81812303
369 in stock

80512725 - SUB TO WBKFD6
SKU: 80512725
369 in stock

5197798 - Tie Rod Assembly
SKU: 5197798
44 in stock

5168941 - Tie Rod Assembly (4WD)
SKU: 5168941
9 in stock

5117314 - Tie Rod
SKU: 5117314
55 in stock

2852114 - Water Pump
SKU: 2852114
53 in stock

167269 - O-Ring
SKU: 167269
9 in stock

128825 - O-Ring
SKU: 128825
2750 in stock

WL7541L - Warning Light (LH)
SKU: WL7541L
294 in stock

WL7540R - Warning Light (RH)
SKU: WL7540R
293 in stock

WL2449L - Hi / Low LH LED Headlight
SKU: WL2449L
184 in stock

WL2448R - Hi / Low RH LED Headlight
SKU: WL2448R
187 in stock

WL1078 - Rectangle Flood LED Work Lamp
SKU: WL1078
161 in stock

9847313-LED - Replacement For #894 Bulb 1000 Lumens Bulb; LED
SKU: 9847313-LED
11 in stock

9847313 - 12V 37.5W #894 Bulb
SKU: 9847313
50 in stock

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED
SKU: 9703399-LED
288 in stock

87283179-LED - Replacement For H4 Bulb 600 Lumens Bulb; LED
SKU: 87283179-LED
190 in stock

87283179 - Inner H4-12V Bulb
SKU: 87283179
73 in stock

82018390 - Pipe Type Amber Rotating Beacon
SKU: 82018390
651 in stock
