Case IH 884 Tractor Parts
Replacement parts for the Case IH 884 Tractor. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The Case IH 884 tractor, manufactured from 1981 to 1984, was a popular choice for farmers needing a reliable utility tractor. Powered by a 55 horsepower diesel engine, the 884 delivered ample power for various farm tasks. Its robust design and 47 PTO horsepower made it a versatile workhorse for row crop operations, hay baling, and livestock management.
About the 884
The Case IH 884 was produced between 1981 and 1984, filling a crucial role in the Case IH tractor lineup. The 884 is equipped with a 239 cubic inch (3.9L) International Harvester D-239 diesel engine, producing approximately 55 engine horsepower. This tractor features a gear transmission offering either 8 forward and 4 reverse speeds, or optionally a 16 forward and 8 reverse speed transmission with a creeper gear. The PTO delivers around 47 horsepower and operates at 540 RPM. Hydraulic capacity is rated at approximately 7.5 GPM, with availability for one or two remote valves. It boasts a Category II 3-point hitch, providing a lift capacity of around 3,600 lbs. The 884 was commonly used in row crop applications, hay baling, livestock feeding operations, and light tillage work. What set the 884 apart from other models in the lineup was its blend of power and maneuverability, making it suitable for both small and medium-sized farms.
884 Specifications
| Engine | International Harvester D-239 55 HP 239 ci Diesel |
|---|---|
| PTO HP | 47 HP @ 540 RPM |
| Transmission | Gear 8F/4R or 16F/8R (with creeper) |
| Hydraulics | 7.5 GPM, 1-2 remotes |
| 3-Point Hitch | Category II, 3600 lbs |
| Fuel Capacity | 20 gallons |
| Weight | 5,625 lbs |
| Years Produced | 1981-1984 |
884 Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using a high-quality diesel engine oil and a Case IH specified or equivalent oil filter.
- Hydraulic System Maintenance: Check hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to ensure optimal performance and prevent contamination.
- Fuel System Care: Use clean, fresh diesel fuel and replace the fuel filter annually or every 500 hours to prevent fuel system issues. Consider using a fuel additive to prevent gelling during cold weather.
- Seasonal Storage: Before storing the tractor for an extended period, fill the fuel tank to prevent condensation, change the engine oil, and grease all lubrication points to protect against corrosion. Disconnect the battery and store it in a cool, dry place.
884 History & Background
The Case IH 884 was introduced in 1981 as part of the International Harvester (later Case IH) utility tractor series. It offered farmers a dependable and versatile tractor for a wide range of tasks. While there were no major redesigns during its production run, the 884 remains a popular choice for those seeking an affordable and capable machine.
Frequently Asked Questions
Which flasher control switch fits the Case IH 884?
The 87271837 - Switch, Flasher Control is a suitable replacement for the Case IH 884.
What thrust bearing is recommended for the Case IH 884?
For the Case IH 884, the 185106C1 - Bearing, Thrust is a recommended replacement part.
Which pilot bearing is suitable for the Case IH 884?
The ST553 - Bearing, Pilot (sealed) is a suitable pilot bearing for the Case IH 884.
What are common replacement parts for the Case IH 884?
For routine maintenance and common replacements on the Case IH 884, consider parts like the 3044506R1 - Filter, Fuel, 3125322R2 - Disc, Clutch Driven, 65079C91 - Tie Rod, Long, 1500626C92 - Cap, Radiator w/ Cover (10 lb.), 3110259R1 - Key, Ignition, and 358958R2 - Bushing, Upright Spindle.

A173180 - Muffler
SKU: A173180
11 in stock

SK165 - Piston Liner Kit
SKU: SK165
39 in stock

651818R91 - BEARING
SKU: 651818R91
457 in stock

FF214J - Spin-On (QTY 1) Fuel Filter
SKU: FF214J
Out of stock

C5NN3A300C - Front Drag Link End
SKU: C5NN3A300C
113 in stock

67529C1 - Tie Rod Tube
SKU: 67529C1
248 in stock

652080R91 - Inner Cone
SKU: 652080R91
457 in stock

65082C91 - Long Tie Rod
SKU: 65082C91
22 in stock

65079C91 - Long Tie Rod
SKU: 65079C91
213 in stock

65077C91 - Long Tie Rod
SKU: 65077C91
36 in stock

612884R1 - Hub Cap
SKU: 612884R1
46 in stock

527658R91 - Short Tie Rod
SKU: 527658R91
237 in stock

43747D - Tie Rod Clamp
SKU: 43747D
403 in stock

390686R1 - Jam Nut
SKU: 390686R1
295 in stock

379327R91 - Tie Rod End
SKU: 379327R91
19 in stock

379326R91 - Tie Rod End
SKU: 379326R91
113 in stock

3216599R91 - Short Axle Shaft
SKU: 3216599R91
13 in stock

3129380R2 - Long Tie Rod
SKU: 3129380R2
9 in stock

3125172R1 - Tie Rod Tube
SKU: 3125172R1
20 in stock

3125171R2 - Long Tie Rod
SKU: 3125171R2
Out of stock

3121257R91 - Knee Extension (RH)
SKU: 3121257R91
12 in stock

3121256R91 - Knee Extension (LH)
SKU: 3121256R91
12 in stock

3116408R1 - Tie Rod Tube
SKU: 3116408R1
29 in stock

3057055R91 - Inner Cone
SKU: 3057055R91
457 in stock
