Case IH 7220 Tractor Parts

7220 parts and accessories

The Case IH 7220 tractor, manufactured from 1994 to 1997, was a popular choice for farmers needing a reliable workhorse. Powered by an 8.3L Cummins diesel engine producing approximately 160 horsepower, the 7220 delivered ample power for a variety of tasks. Its robust PTO horsepower made it well-suited for operating implements like balers and rotary cutters, establishing its reputation for dependable performance in the field.

The Case IH 7220 was part of the 7200 series tractors produced from 1994 to 1997, succeeding earlier models and offering improved features and performance. Under the hood lies a Cummins 8.3L inline 6-cylinder diesel engine, rated around 160 engine horsepower. This engine provided plenty of torque for demanding agricultural tasks. The transmission was typically a full powershift, offering smooth and efficient gear changes without clutching. The PTO delivered around 135 horsepower, available in both 540 and 1000 RPM configurations to accommodate various implements. Hydraulic capacity was substantial, with a flow rate around 29 GPM powering multiple remote valves for implements requiring hydraulic power. The 3-point hitch was Category II, offering significant lift capacity for attaching and operating a wide range of implements. The 7220 found its niche in row crop operations, hay production, livestock farming, and tillage applications. Compared to smaller models in the lineup, it offered more power and hydraulic capacity, while larger models provided even greater capabilities for large-scale farming.

Specifications

Engine	Cummins 8.3L 160 HP Diesel
PTO HP	135 HP @ 540/1000 RPM
Transmission	Full Powershift, 18F/6R
Hydraulics	29 GPM, 3 remotes
3-Point Hitch	Category II, 6900 lbs
Fuel Capacity	71 gallons
Weight	16,500 lbs
Years Produced	1994-1997

Maintenance Tips

Change engine oil and filter every 250-300 hours using the recommended oil type for Cummins engines.
Inspect and maintain hydraulic fluid levels regularly, changing the hydraulic filter according to the manufacturer's recommendations.
Keep the fuel system clean by using high-quality fuel and replacing the fuel filter at recommended intervals to prevent fuel injector issues.
Before seasonal storage, properly prepare the tractor by draining fluids, lubricating moving parts, and protecting it from the elements to prevent corrosion and ensure optimal performance when brought back into service.

History & Background

The Case IH 7220 was introduced in 1994 as part of the 7200 series, which aimed to update and improve upon previous tractor models. No major redesigns occurred during its production run. The 7220 became a respected tractor in the agricultural community for its blend of power, reliability, and modern features.

Frequently Asked Questions

What engine is in the Case Ih 7220?

The Case IH 7220 is equipped with a Cummins 8.3L inline 6-cylinder diesel engine producing approximately 160 horsepower.

What is the PTO horsepower on a 7220?

The PTO horsepower on the Case IH 7220 is around 135 HP and offers both 540 and 1000 RPM options.

What oil filter fits the 7220?

The typical oil filter cross-reference for the Case IH 7220's Cummins 8.3L engine includes Fleetguard LF3349, Baldwin B1441, and Wix 51791. Always verify the correct part number for your specific tractor's configuration.

What are common parts needed for the 7220?

Common wear parts for the Case IH 7220 include engine oil filters, fuel filters, hydraulic filters, belts, hydraulic cylinder seals, steering components (tie rod ends, ball joints), and clutch components (if applicable).

Showing 1-24 of 357 products

Sort by:
