Case IH 574 Tractor Parts

Find parts for your Case IH 574 Tractor. We stock OEM and quality aftermarket replacements ready to ship.

The Case IH 574, manufactured from 1971 to 1978, was a popular utility tractor known for its reliability and versatility on farms. Powered by a diesel or gasoline engine producing around 54 horsepower, the 574 offered a practical solution for various agricultural tasks. Its robust design and efficient PTO horsepower made it a favorite for haying, livestock operations, and general farm work.

About the 574

Introduced in 1971, the Case IH 574 replaced earlier models and quickly gained a reputation for dependability. Engine options included an International Harvester 236 cubic inch diesel engine, producing approximately 54 horsepower, or a gasoline engine of similar displacement and horsepower. The transmission was typically a gear-driven, 8-speed forward and 2-speed reverse transmission, providing a good range of speeds for different applications. The independent PTO delivered around 48 horsepower at 540 RPM, suitable for operating implements like mowers, balers, and rotary cutters. The hydraulic system had a capacity of around 9 gallons per minute, powering the 3-point hitch, which was a Category I or II, depending on the hitch configuration, with a lift capacity of approximately 2,800 lbs. Common uses included row crop operations, hay production, livestock feeding, and light tillage. The 574 distinguished itself from larger Case IH models with its compact size and maneuverability, while offering more power and capabilities than smaller utility tractors, making it a balanced and practical choice for many farmers.

574 Specifications

EngineInternational Harvester 236 CID 54 HP Diesel or Gasoline
PTO HP48 HP @ 540 RPM
TransmissionGear, 8 forward and 2 reverse speeds
Hydraulics9 GPM, 2 remotes (optional)
3-Point HitchCategory I/II, 2800 lbs lift capacity
Fuel Capacity17 gallons
Weight5300 lbs
Years Produced1971-1978

574 Maintenance Tips

  • Change the engine oil and filter every 100-150 hours of operation, using a high-quality oil formulated for diesel or gasoline engines, depending on your model.
  • Inspect and maintain the hydraulic system regularly, checking fluid levels, replacing filters every 250 hours, and repairing any leaks to ensure proper operation of the 3-point hitch and other hydraulic implements.
  • Periodically check the fuel system for water or sediment contamination, drain the fuel filter, and use a fuel stabilizer during seasonal storage to prevent fuel degradation.
  • Before storing the tractor for extended periods, grease all lubrication points, disconnect the battery, and protect the tires from direct sunlight.

574 History & Background

The Case IH 574 was launched in 1971 as part of the '74 series, offering a modern design and improved performance over its predecessors. It represented a significant step forward in utility tractor technology and played a crucial role in mechanizing smaller farms and supplementing larger operations during the 1970s.

Frequently Asked Questions

Which ignition coil is suitable for the Case IH 574?

For the Case IH 574, consider the 396546R93. It is designed to fit your tractor's electrical system, offering reliable performance.

Which PTO clutch plate fits the Case IH 574?

The 401717R1 - Plate, PTO Clutch is an appropriate replacement for the Case IH 574. This component ensures proper power transfer for your PTO operations.

Which flasher control switch is recommended for the Case IH 574?

A recommended flasher control switch for the Case IH 574 is the 87271837 - Switch, Flasher Control. This switch helps maintain the proper function of your tractor's signaling lights.

What are common parts needed for the 574?

Showing 1-24 of 336 products
