Case IH 5240 Tractor Parts
Browse Case IH 5240 Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The Case IH 5240 tractor, manufactured from 1990 to 1996, was a popular choice for farmers needing a reliable and versatile machine. Powered by a 95 horsepower International Harvester diesel engine, this tractor offered a robust PTO output of around 80 horsepower. Its ease of use and dependable performance made it a mainstay on farms across the country.
About the 5240
The Case IH 5240 was part of the Maxxum series, introduced in the 1990s to provide a modern and efficient tractor option. Production ran from 1990 to 1996. It features an International Harvester 268 cubic inch (4.4L) 4-cylinder diesel engine producing approximately 95 engine horsepower. Transmission options included a standard synchro range transmission with various speed configurations, most commonly a 16-speed forward and 8-speed reverse. The PTO delivers around 80 horsepower and offers both 540 and 1000 RPM options, increasing versatility. The hydraulic system had a capacity of around 17 GPM, powering two or three remote valves depending on the configuration. A Category II 3-point hitch provided a lift capacity of roughly 6,500 lbs. Commonly used for row crop work, haying operations, livestock management, and light tillage, the 5240 distinguished itself with its comfortable cab, reliable engine, and versatile PTO options compared to smaller utility tractors in the Case IH lineup.
5240 Specifications
| Engine | International Harvester 95 HP 268 ci Diesel |
|---|---|
| PTO HP | 80 HP @ 540/1000 RPM |
| Transmission | Synchro Range 16F/8R |
| Hydraulics | 17 GPM, 2-3 remotes |
| 3-Point Hitch | Category II, 6500 lbs |
| Fuel Capacity | 30 gallons |
| Weight | 9,500 lbs |
| Years Produced | 1990-1996 |
5240 Maintenance Tips
- Check and change the engine oil and filter every 250 hours. Use the recommended oil type and a quality filter to ensure optimal engine performance.
- Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and maintain hydraulic system efficiency.
- Keep the fuel system clean by using clean fuel and replacing the fuel filter regularly, especially before seasonal storage.
- Before storing the tractor for extended periods, drain fluids, grease all fittings, and protect the tires from sunlight to prevent deterioration.
5240 History & Background
The Case IH 5240 was introduced in 1990 as part of the Maxxum series, designed to offer farmers a modern and efficient tractor option. While there were no major redesigns during its production run, slight improvements and options were added over the years. The 5240 is remembered for its comfortable cab and dependable performance, solidifying its place as a popular mid-size tractor in agricultural history.
Frequently Asked Questions
Which fuel lift pump is suitable for the Case IH 5240?
The 87319987 - Pump, Fuel Lift is a direct replacement for the Case IH 5240.
What PTO control cable is used on the 5240?
The 120557A2 - PTO Control Cable is designed to fit the Case IH 5240.
What oil filter fits the 5240?
The LF3349 - Filter, Lube, Full-Flow Spin-On is a suitable replacement oil filter for the Case IH 5240. Always verify fitment.
What are common replacement parts for the Case IH 5240?
Commonly replaced parts for the Case IH 5240 include the 87681147 - Belt, Fan, 1997129C1 - Plate, Friction, Transmission, 282775A1 - Switch, Ignition, WL1200 - Work Lamp, LED, Flood, Rectangle, and 128483A1 - O-Ring. The LF3349 - Filter, Lube, Full-Flow Spin-On is also a frequent replacement.

651818R91 - BEARING
SKU: 651818R91
457 in stock

ZP0750125010 - Ball Joint
SKU: ZP0750125010
303 in stock

T103767 - Tie Rod Clamp
SKU: T103767
24 in stock

T102913 - Steering Cylinder Cylinder End
SKU: T102913
72 in stock

N14388 - Cylinder End (LH)
SKU: N14388
32 in stock

N14377 - Cylinder End
SKU: N14377
303 in stock

D149730 - Cylinder End (LH)
SKU: D149730
69 in stock

D149728 - Cylinder End (RH)
SKU: D149728
143 in stock

9968017 - Zinc 8.8 M24X1.5 MFD Steering Cylinder RH Thread Jam Nut
SKU: 9968017
31 in stock

81878551 - Zinc 8.8 M24X1.5 MFD Steering Cylinder LH Thread Jam Nut
SKU: 81878551
Out of stock

652080R91 - Inner Cone
SKU: 652080R91
457 in stock

3057055R91 - Inner Cone
SKU: 3057055R91
457 in stock

1534224C1 - Tie Rod Tube
SKU: 1534224C1
49 in stock

1531204C1 - Short Tie Rod
SKU: 1531204C1
45 in stock

1531203C1 - Long Tie Rod
SKU: 1531203C1
46 in stock

126145A1 - RH Ball Joint
SKU: 126145A1
143 in stock

126144A1 - Ball Joint (LH)
SKU: 126144A1
69 in stock

2852114 - Water Pump
SKU: 2852114
53 in stock

287066 - Tapered Bearing Cup
SKU: 287066
118 in stock

WL6482R - Hi / Low RH LED Headlight
SKU: WL6482R
207 in stock

WL6481L - Hi / Low LH LED Headlight
SKU: WL6481L
214 in stock

WL3405 - RH Front / LH Rear Amber LED Warning Light
SKU: WL3405
173 in stock

WL3404 - LH Front / RH Rear Amber LED Warning Light
SKU: WL3404
165 in stock

WL1205 - Side Mount Rectangle Flood LED Work Lamp
SKU: WL1205
120 in stock
