Case IH 3230 Tractor Parts
Find parts for your Case IH 3230 Tractor. We stock OEM and quality aftermarket replacements ready to ship.
The Case IH 3230 tractor, manufactured from 1994 to 1997, was a popular utility tractor known for its reliability and versatility. Powered by a 59 horsepower diesel engine, it offered a PTO horsepower of around 50, making it suitable for a variety of farming tasks. Its user-friendly design and robust construction made it a favorite among farmers for haying, livestock operations, and general farm work.
About the 3230
The Case IH 3230 was introduced in 1994 as part of the Case IH 30 Series, a line of utility tractors designed for efficiency and durability. Production continued until 1997. This model features an International Harvester 239 cubic inch (3.9L) 4-cylinder diesel engine producing approximately 59 horsepower. The transmission is typically a gear-type, offering multiple speeds forward and reverse, commonly an 8x8 Synchro Shift. The PTO delivers approximately 50 horsepower, and often included both 540 RPM independent and ground speed options. Hydraulic capacity is around 12.5 GPM, providing ample flow for implements and loader work, usually with two rear remotes. The 3-point hitch is a Category II, capable of lifting approximately 3300 lbs, making it suitable for operating various implements. This tractor found common application in row crop operations (small farms), hay production, livestock management, and light tillage. It stands out due to its simplicity, ease of maintenance, and a good balance of power and maneuverability, differentiating it from larger, more complex models in the Case IH lineup.
3230 Specifications
| Engine | International Harvester 59 HP 239ci Diesel |
|---|---|
| PTO HP | 50 HP @ 540 RPM |
| Transmission | Gear, 8x8 Synchro Shift |
| Hydraulics | 12.5 GPM, 2 remotes |
| 3-Point Hitch | Category II, 3300 lbs |
| Fuel Capacity | 22 gallons |
| Weight | 5300 lbs |
| Years Produced | 1994-1997 |
3230 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250 hours using a high-quality diesel engine oil meeting API CH-4 or higher specifications. Regularly inspect the air filter and clean or replace as needed.
- Hydraulic Maintenance: Check hydraulic fluid levels regularly and change the hydraulic fluid and filter every 500 hours. Use the correct type of hydraulic fluid specified in the operator's manual.
- Fuel System Care: Use clean, fresh diesel fuel and add a fuel stabilizer if the tractor will be stored for extended periods. Drain the fuel/water separator regularly to prevent water from entering the fuel system.
- Seasonal Storage: Before storing the tractor for the winter, fill the fuel tank to prevent condensation, grease all lubrication points, and disconnect the battery. Store the tractor in a dry, sheltered location.
3230 History & Background
The Case IH 3230 was introduced in the mid-1990s as part of a broader effort to offer reliable and versatile utility tractors. There were no major redesigns during its production run, highlighting the original design's solid foundation. The 3230 played a significant role in providing farmers with a dependable workhorse for diverse agricultural applications.
Frequently Asked Questions
Which water pump fits the Case IH 3230?
The 3132739R94 - Water pump is designed to fit the Case IH 3230 model.
What replacement ignition switch is recommended for the Case IH 3230?
A suitable replacement ignition switch for the Case IH 3230 is the 3107556R1 - Switch w/ 2 Keys, Ignition.
Which LED headlight is compatible with the Case IH 3230?
The WL6481L - Headlight, LED, LH, Hi / Low is a compatible LED headlight option for the Case IH 3230.
What are some common replacement parts for the Case IH 3230?
For routine maintenance and repairs on the Case IH 3230, commonly replaced parts include the ST553 - Bearing, Pilot (sealed), NT12 - Nut, Front Wheel, 527658R91 - Tie Rod, Short, 3125322R2 - Disc, Clutch Driven, 87703630 - Lamp, Amber LED Flasher/Tail Light, and 358958R2 - Bushing, Upright Spindle.

SK445 - Piston Liner Kit
SKU: SK445
2 in stock

SRK724 - Liner Sealing Ring Kit
SKU: SRK724
20 in stock

ZP0750125014 - Ball Joint
SKU: ZP0750125014
71 in stock

VPJ3210 - Tie Rod End
SKU: VPJ3210
9 in stock

CAR49001 - Ball Joint (RH)
SKU: CAR49001
71 in stock

9967993 - 4WD Front Axle Bushing
SKU: 9967993
43 in stock

85805975 - Steering Cylinder Ball Joint
SKU: 85805975
71 in stock

83974364 - Ball Joint (RH)
SKU: 83974364
71 in stock

83957758 - Ball Joint (RH)
SKU: 83957758
71 in stock

83957097 - Ball Joint (RH)
SKU: 83957097
71 in stock

65079C91 - Long Tie Rod
SKU: 65079C91
213 in stock

612884R1 - Hub Cap
SKU: 612884R1
46 in stock

527658R91 - Short Tie Rod
SKU: 527658R91
237 in stock

43747D - Tie Rod Clamp
SKU: 43747D
403 in stock

1966127C1 - Ball Joint (LH)
SKU: 1966127C1
13 in stock

1966125C1 - Ball Joint (RH)
SKU: 1966125C1
71 in stock

1537872C1 - Steering End
SKU: 1537872C1
23 in stock

137048A1 - Tie Rod End (RH)
SKU: 137048A1
63 in stock

137047A1 - Tie Rod End (LH)
SKU: 137047A1
9 in stock

1332805C2 - Outer Tie Rod
SKU: 1332805C2
188 in stock

112508A1 - Tie Rod
SKU: 112508A1
13 in stock

3136053R92 - Water Pump
SKU: 3136053R92
144 in stock

WL6482R - Hi / Low RH LED Headlight
SKU: WL6482R
207 in stock

WL6481L - Hi / Low LH LED Headlight
SKU: WL6481L
214 in stock
