Case IH 2090 Tractor Parts
Browse Case IH 2090 Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The Case IH 2090 tractor, manufactured from 1972 to 1977, was a popular choice for farmers needing a reliable and powerful machine. It featured a robust 110 horsepower diesel engine, delivering ample power for various field tasks. With a PTO horsepower rating of approximately 95, the 2090 excelled in powering implements for haying, tillage, and row crop applications.
About the 2090
The Case IH 2090 was introduced in 1972 as part of Case's '90 Series' of tractors, designed to offer improved comfort and performance compared to earlier models. Production continued through 1977. Powering the 2090 is a Case-built 451 cubic inch (7.4 liter) 6-cylinder diesel engine producing approximately 110 engine horsepower. The transmission is a gear-drive type, typically offered in either a 6-speed forward, 2-speed reverse transmission or a 12-speed forward, 4-speed reverse transmission with partial power shift. The PTO delivers approximately 95 horsepower and offers a 540 RPM option. The hydraulic system capacity is around 17.5 GPM, feeding multiple remote valves for implement control. It features a Category II 3-point hitch, providing a lift capacity of approximately 5,300 lbs. Common farming applications for the 2090 include row crop cultivation, hay baling, livestock operations (feeding/manure handling), and light tillage. It distinguished itself from smaller models in the lineup with its larger engine and higher horsepower, making it suitable for more demanding tasks, while being more compact and maneuverable than the larger frame models.
2090 Specifications
| Engine | Case 451 CI 110 HP Diesel |
|---|---|
| PTO HP | 95 HP @ 540 RPM |
| Transmission | Gear Drive, 6/2 or 12/4 partial power shift |
| Hydraulics | 17.5 GPM, 2-3 remotes |
| 3-Point Hitch | Category II, 5300 lbs lift |
| Fuel Capacity | 39 gallons |
| Weight | 12,000 lbs |
| Years Produced | 1972-1977 |
2090 Maintenance Tips
- Check and change the engine oil and filter every 125-250 hours, depending on operating conditions and oil type. Use an oil specifically formulated for diesel engines.
- Inspect hydraulic fluid levels and condition regularly. Change the hydraulic fluid and filter according to the manufacturer's recommendations (typically every 500-1000 hours).
- Keep the fuel system clean and free of contaminants. Use a fuel filter and consider adding a fuel stabilizer, especially during seasonal storage.
- Before storing the tractor for the off-season, drain fluids, grease all fittings, and protect exposed metal parts with a rust inhibitor. Store indoors if possible.
2090 History & Background
The Case IH 2090 debuted in 1972, representing a significant step forward in tractor design with improved operator comfort and enhanced hydraulic capabilities compared to its predecessors. While no major redesigns occurred during its production run (1972-1977), the 2090 established itself as a reliable workhorse, contributing to increased farming efficiency during that era.
Frequently Asked Questions
Which alternator is suitable for the Case IH 2090?
The A46932 - Alternator, Delco is a suitable replacement for the Case IH 2090.
What PTO clutch friction plate fits the 2090?
For the Case IH 2090, the 1981228C1 - Plate, PTO Clutch Friction is recommended.
What water filter fits the 2090?
The WF2071 - Filter, Water, Spin-On (QTY 12) is a compatible spin-on water filter for the Case IH 2090.
What are some recommended replacement parts for the Case IH 2090?
Some recommended replacement parts for the Case IH 2090 include the K917962 - THERMOSTAT-180, the A47038 - Seal Kit, Hydrostatic Steering Hand Pump, a A67336 - Brake Plate, Steel, the WL7606 - Light Assembly, LED, Flood, a 87271837 - Switch, Flasher Control, and the 1342786C1 - Gasket, Exhaust Manifold.

A160176 - Muffler
SKU: A160176
11 in stock

A147065 - Muffler
SKU: A147065
15 in stock

SK661 - Piston Liner Kit
SKU: SK661
24 in stock

WBKCA3 - Wheel Bearing Kit
SKU: WBKCA3
57 in stock

F22580 - CASE-IH
SKU: F22580
114 in stock

B93222 - Wheel Bearing Kit
SKU: B93222
18 in stock

A160200 - Short Tie Rod End
SKU: A160200
23 in stock

A160199 - Long Tie Rod
SKU: A160199
9 in stock

A160197 - Long Tie Rod End
SKU: A160197
60 in stock

A160166 - Tie Rod Tube
SKU: A160166
17 in stock

A149033 - Tie Rod Tube
SKU: A149033
33 in stock

A145857 - Tie Rod Wedge
SKU: A145857
27 in stock

A145846 - Spacer
SKU: A145846
167 in stock

A143876 - Tie Rod End (LH)
SKU: A143876
11 in stock

112204 - Tie Rod Assembly
SKU: 112204
2 in stock

112203 - Tie Rod Assembly
SKU: 112203
16 in stock

199352A1 - Water Pump
SKU: 199352A1
146 in stock

LM603049-I - Tapered Roller Bearing Cone
SKU: LM603049-I
336 in stock

LM603011-I - Tapered Bearing Cup
SKU: LM603011-I
94 in stock

WL7610 - Trapezoid LED Light Assembly
SKU: WL7610
98 in stock

WL7606 - Flood LED Light Assembly
SKU: WL7606
92 in stock

WL1300 - Rectangle Hi / Low Flood / Spot Combo LED Work Lamp
SKU: WL1300
243 in stock

D71346 - Bulb
SKU: D71346
497 in stock

A42294 - Sealed Beam Bulb (12 Volt)
SKU: A42294
340 in stock
