Case IH SUPER-M Tractor Parts
Replacement parts for the Case IH Super M Tractor. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The Case IH Super M tractor, manufactured from 1952 to 1954, was a popular and reliable workhorse on farms across America. Powered by a gasoline engine producing around 45 horsepower at the drawbar, it offered sufficient power for various agricultural tasks. Its robust design and straightforward operation made it a favorite among farmers seeking a dependable tractor for plowing, cultivating, and other fieldwork.
About the SUPER M
The Case IH Super M, building upon the legacy of the Farmall M, was introduced to provide increased power and improved features. Production ran from 1952 to 1954. It was equipped with an IHC C-264 gasoline engine, delivering approximately 45 drawbar horsepower. This 4-cylinder engine had a displacement of 264 cubic inches. The Super M came standard with a mechanical 5-speed transmission. The PTO delivered around 41 horsepower, typically at 540 RPM. The hydraulic system had a capacity of approximately 13 GPM. The tractor featured a Category II 3-point hitch, allowing it to handle a range of implements. Common farming applications included row crop work, haying operations, and light tillage tasks. The Super M distinguished itself from its predecessors with enhancements to the engine and hydraulic systems, providing better performance and ease of use. Compared to larger models in the Case IH lineup at the time, the Super M offered a more compact and maneuverable option suitable for smaller farms or specific tasks.
SUPER M Specifications
| Engine | IHC C-264 45 HP Gasoline |
|---|---|
| PTO HP | 41 HP @ 540 RPM |
| Transmission | Mechanical 5-speed |
| Hydraulics | 13 GPM, 2 remotes |
| 3-Point Hitch | Category II, 2500 lbs |
| Fuel Capacity | 20 gallons |
| Weight | 5500 lbs |
| Years Produced | 1952-1954 |
SUPER M Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 125 hours of operation using the recommended oil type and filter.
- Hydraulic Maintenance: Regularly check hydraulic fluid levels and inspect for leaks. Replace hydraulic filters according to the manufacturer's schedule.
- Fuel System Care: Use clean, fresh fuel and consider adding a fuel stabilizer, especially during periods of infrequent use. Inspect the fuel filter regularly and replace as needed.
- Seasonal Storage: Before storing the tractor for an extended period, drain the fuel tank and carburetor or add a fuel stabilizer. Disconnect the battery and store it in a cool, dry place.
SUPER M History & Background
The Case IH Super M was introduced in 1952 as an upgrade to the earlier Farmall M series. While retaining much of the M's robust design, the Super M featured improvements to the engine and hydraulics. It played a significant role in the post-war agricultural boom, providing farmers with a reliable and versatile tractor for a variety of tasks.
Frequently Asked Questions
Which starter motor is compatible with the Case IH SUPER M?
The 63608D - Starter, Delco - w/o relay start is designed to fit the Case IH SUPER M, providing reliable starting power.
What tune-up kit is recommended for the Case IH SUPER M?
The 21A9R - Tune Up Kit is a comprehensive option for maintaining the ignition system of your Case IH SUPER M.
Which radiator cap is suitable for the Case IH SUPER M?
For the Case IH SUPER M, the 163361 - Radiator Cap (4 Lb) is a direct fit for maintaining proper cooling system pressure.
What are common replacement parts for the Case IH SUPER M?
For routine maintenance and wear, common replacement parts for the Case IH SUPER M include the 370832R91 - Strainer, Fuel Assembly, 16131DA - Belt, Fan, 1963810C2 - Brake Disc, Heavy Duty, 69789C91 - Bearing, Release (sealed), 396546R93 - Ignition Coil - 6 Volt W/O External Resistor or 12 Volt W/ External Resistor, and 407487R1 - Spark Plug Wire Set (4 Cyl).

VTK517 - Valve Train Kit
SKU: VTK517
4 in stock

SK271 - Piston Liner Kit
SKU: SK271
44 in stock

SD152 - Cylinder Liner
SKU: SD152
11 in stock

60381 - Tie Rod Boot
SKU: 60381
249 in stock

48704DA - Wheel Hub Seal
SKU: 48704DA
56 in stock

14274-I - Tapered Bearing Cup
SKU: 14274-I
31 in stock

14138A-I - Tapered Roller Bearing Cone
SKU: 14138A-I
154 in stock

REF200 - Headlamp Reflector
SKU: REF200
13 in stock

GC200 - Glass Headlight Lens
SKU: GC200
213 in stock

CLP200 - Headlamp Clamp
SKU: CLP200
13 in stock

529068 - Bulb
SKU: 529068
115 in stock

45640DB - Headlamp Assembly (6 Volt)
SKU: 45640DB
32 in stock

1156L24 - Replaces Bulb #1156 (2 Pack) 2400 Lumens LED Bulb
SKU: 1156L24
56 in stock

1156-LED - Replaces Bulb #1156 (2 Pack) LED; 600 Lumens Bulb
SKU: 1156-LED
127 in stock

OK264 - Major Engine Overhaul Kit
SKU: OK264
Out of stock

IK264 - In Frame Engine Overhaul Kit
SKU: IK264
Out of stock

128190C91 - Hydraulic Pump
SKU: 128190C91
7 in stock

51502D - Fender Spacers
SKU: 51502D
1144 in stock

51500FEK - Fender Extension Kit
SKU: 51500FEK
14 in stock

51500DB - Fender (RH/LH)
SKU: 51500DB
19 in stock

66424DBX - PTO Shield
SKU: 66424DBX
11 in stock

51484DX - PTO Shaft w/ Clamp Guard
SKU: 51484DX
7 in stock

373304R92 - PTO Brake Band W/ Lining
SKU: 373304R92
14 in stock

364477R91 - PTO Rear Seal
SKU: 364477R91
87 in stock
