Case IH MXU125 Tractor Parts
Browse Case IH MXU125 Tractor replacement parts. Everything from routine maintenance items to hard-to-find components.
The Case IH MXU125 tractor, manufactured from 2003 to 2007, was a versatile workhorse appreciated by farmers for its reliability and power. Powered by a 125 engine horsepower diesel engine and delivering a robust PTO, the MXU125 was well-suited for a variety of farming tasks. Its efficient design and comfortable cab made it a popular choice for both small and large operations.
About the MXU125
The Case IH MXU125 was introduced as part of the MXU series, known for its modern design and improved performance compared to previous models. Production spanned from 2003 to 2007. The tractor features a Case IH engine rated at 125 engine horsepower. This is a 6.7-liter (409 cubic inch) turbocharged diesel engine providing ample power for demanding tasks. Transmission options included a semi-powershift transmission offering multiple speeds, providing flexibility for various field conditions. The independent PTO delivers approximately 100 PTO horsepower, available in both 540 and 1000 RPM configurations. The hydraulic system boasts a capacity of around 26 GPM, supporting multiple remotes for implements. It's equipped with a Category II 3-point hitch, offering a lift capacity of approximately 6,900 lbs. Common applications include row crop work, hay production, livestock operations, and general tillage. The MXU125 distinguishes itself from other models in the MXU lineup with its optimized balance of power and fuel efficiency, making it a cost-effective solution for many farming needs.
MXU125 Specifications
| Engine | Case IH 125 HP 6.7L Diesel |
|---|---|
| PTO HP | 100 HP @ 540/1000 RPM |
| Transmission | Semi-Powershift Multiple Speeds |
| Hydraulics | 26 GPM, Multiple remotes |
| 3-Point Hitch | Category II, 6900 lbs |
| Fuel Capacity | 40 Gallons |
| Weight | 13,000 lbs |
| Years Produced | 2003-2007 |
MXU125 Maintenance Tips
- Engine Oil & Filter: Change engine oil and filter every 250-300 hours using recommended oil type to maintain engine health.
- Hydraulic System: Regularly check hydraulic fluid levels and inspect for leaks. Replace hydraulic filters according to the manufacturer's schedule to prevent contamination.
- Fuel System: Use clean, high-quality diesel fuel and check the fuel filter regularly for blockages. Drain any water accumulation from the fuel tank to prevent corrosion and fuel injector issues.
- Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, change engine oil, grease all fittings, and disconnect the battery. Store in a dry location to prevent rust and corrosion.
MXU125 History & Background
The Case IH MXU125 was part of the MXU series tractors introduced in the early 2000s, representing a significant upgrade in design and technology over previous Case IH models. This series was known for its more modern styling, improved operator comfort, and increased efficiency, solidifying Case IH's position in the agricultural equipment market.
Frequently Asked Questions
Which hydraulic filter is compatible with the Case IH MXU125?
The Case IH MXU125 utilizes a spin-on hydraulic filter. We recommend 47131180 - Filter, Hydraulic; Spin On for optimal performance.
What replacement PTO shaft is available for the Case IH MXU125?
For the Case IH MXU125, a direct replacement PTO shaft is 87308746 - Shaft, PTO.
What cab air filter is recommended for the Case IH MXU125?
The Case IH MXU125 uses a specific cab air filter. Consider the 87726675 - Filter; Cab Air for maintaining clean cab air.
What are common parts needed for the MXU125?
For the Case IH MXU125, commonly needed parts include the 87329736 - Filter, Fuel; In-Line, 47131180 - Filter, Hydraulic; Spin On, J911572 - Belt, Fan, Alt, WP, 87726675 - Filter; Cab Air, 83948358 - Seal, Front Wheel, and 87391136 - Brake Band, PTO Clutch.

87395648 - MFWD Ball Joint
SKU: 87395648
52 in stock

81864106 - Long Tie Rod
SKU: 81864106
5 in stock

81864100 - Tie Rod End
SKU: 81864100
43 in stock

81863815 - Barrel End Steering Cylinder Ball Joint
SKU: 81863815
11 in stock

81863813 - Tie Rod
SKU: 81863813
31 in stock

81812303 - SUB TO WBKFD6
SKU: 81812303
369 in stock

80512725 - SUB TO WBKFD6
SKU: 80512725
369 in stock

5197798 - Tie Rod Assembly
SKU: 5197798
44 in stock

5168941 - Tie Rod Assembly (4WD)
SKU: 5168941
9 in stock

5117314 - Tie Rod
SKU: 5117314
55 in stock

2852114 - Water Pump
SKU: 2852114
53 in stock

167269 - O-Ring
SKU: 167269
9 in stock

128825 - O-Ring
SKU: 128825
2750 in stock

WL7541L - Warning Light (LH)
SKU: WL7541L
294 in stock

WL7540R - Warning Light (RH)
SKU: WL7540R
293 in stock

WL2449L - Hi / Low LH LED Headlight
SKU: WL2449L
184 in stock

WL2448R - Hi / Low RH LED Headlight
SKU: WL2448R
187 in stock

WL1078 - Rectangle Flood LED Work Lamp
SKU: WL1078
161 in stock

9847313-LED - Replacement For #894 Bulb 1000 Lumens Bulb; LED
SKU: 9847313-LED
11 in stock

9847313 - 12V 37.5W #894 Bulb
SKU: 9847313
50 in stock

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED
SKU: 9703399-LED
288 in stock

87283179-LED - Replacement For H4 Bulb 600 Lumens Bulb; LED
SKU: 87283179-LED
190 in stock

87283179 - Inner H4-12V Bulb
SKU: 87283179
73 in stock

82018390 - Pipe Type Amber Rotating Beacon
SKU: 82018390
651 in stock
