Case IH MXM120 Tractor Parts

Shop Case IH MXM120 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.

The Case IH MXM120 tractor, manufactured from 2003 to 2007, is a reliable workhorse for various farming applications. Powered by a 120 engine horsepower diesel engine, and boasting approximately 100 PTO horsepower, the MXM120 quickly became a favorite among farmers due to its robust design, comfortable cab, and versatile performance in the field. It offers a great balance of power and efficiency.

About the MXM120

The Case IH MXM120 was produced between 2003 and 2007 and falls within the MXM series known for its blend of power and comfort. The MXM120 is equipped with a Case IH 6.7L 6-cylinder diesel engine, delivering approximately 120 engine horsepower. This engine provides ample power for a variety of tasks while maintaining good fuel efficiency. The transmission is typically a partial powershift, offering multiple forward and reverse speeds for precise control. PTO horsepower is around 100, with both 540 and 1000 RPM options available for compatibility with various implements. The hydraulic system offers a flow rate around 26 GPM, supporting multiple remote valves for hydraulic implements. It features a Category II 3-point hitch with a lift capacity around 6,945 lbs, making it suitable for row crop work, hay production, livestock operations, and light to medium tillage. What sets the MXM120 apart from other models in the lineup is its balanced power-to-weight ratio and comfortable operator environment, making it a versatile choice for many farming operations.

MXM120 Specifications

EngineCase IH 6.7L 120 HP Diesel
PTO HP100 HP @ 540/1000 RPM
TransmissionPartial Powershift, 16F/16R
Hydraulics26 GPM, 2-3 remotes
3-Point HitchCategory II, 6,945 lbs
Fuel Capacity47.6 gallons
Weight12,125 lbs
Years Produced2003-2007

MXM120 Maintenance Tips

  • Engine Oil and Filter: Change the engine oil and filter every 250 hours using the recommended Case IH specification oil to ensure optimal engine performance and longevity.
  • Hydraulic System Maintenance: Regularly inspect hydraulic lines and fittings for leaks. Replace hydraulic filters every 500 hours to prevent contamination and maintain proper hydraulic function.
  • Fuel System Care: Use high-quality diesel fuel and check the fuel filter regularly. Drain water from the fuel tank periodically to prevent fuel system issues, especially during seasonal storage.
  • Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, change the engine oil and filter, grease all fittings, and disconnect the battery. Store the tractor in a dry place to prevent corrosion.

MXM120 History & Background

The Case IH MXM120 was introduced in 2003 as part of the MXM series, representing an evolution in tractor design and technology. While it didn't undergo major redesigns during its production run, it solidified Case IH's reputation for producing reliable and versatile mid-range tractors that catered to a broad range of farming needs.

Frequently Asked Questions

Which thermostat fits the Case IH MXM120?

The 87800842 - Thermostat is the correct replacement for the MXM120 model.

What PTO brake band is used on the MXM120?

The E0NNB726AB - Brake Band, PTO is suitable for the MXM120.

Which right-hand warning light fits the Case IH MXM120?

The WL7540R - Warning Light (RH) is a direct fit for the MXM120.

What are some recommended replacement parts for the Case IH MXM120?

For the MXM120, consider replacing common wear items such as the 47131180 - Filter, Hydraulic; Spin On, the VPD6108 - Filter, Separator, Fuel/Water, and various O-rings like the 86629543 - O-Ring. Other frequently needed parts include the WL2448R - Headlight, LED, RH, Hi / Low, the 82028130 - Switch, Oil Pressure Sender, and the 82027922 - GAS STRUT, CAB DOOR (LH/ RH).

Showing 1-24 of 186 products
