Case IH MX170 Tractor Parts

Case IH MX170 Tractor parts in stock. Quality OEM and aftermarket replacement parts with fast shipping and competitive prices.

The Case IH MX170 tractor, manufactured from 1997 to 2002, was a popular choice for farmers needing a versatile and powerful machine. Powered by a Cummins 8.3L diesel engine producing approximately 170 horsepower, with a PTO horsepower around 140, the MX170 delivered reliable performance in various field operations. Its robust design and comfortable cab made it a favorite for demanding agricultural tasks.

About the MX170

The Case IH MX170 was introduced as part of the MX series, known for its blend of power and operator comfort. Production ran from 1997 to 2002. Under the hood lies a Cummins 8.3L inline 6-cylinder diesel engine, delivering a rated engine power of 170 horsepower. The engine features a turbocharger for increased efficiency and power output. The transmission is a full powershift transmission offering a range of speeds for different field conditions. PTO horsepower is rated around 140 HP, available at both 540 and 1000 RPM. The hydraulic system provides a flow rate around 29 GPM, with typically three remote valves. The 3-point hitch is a Category II/III, offering a lift capacity of approximately 8,500 lbs. The MX170 was commonly used for row crop operations, hay production, livestock feeding, and tillage. Compared to other models in the MX lineup, the MX170 offered a sweet spot of power and maneuverability, making it well-suited for medium to large-scale farming operations.

MX170 Specifications

EngineCummins 8.3L 170 HP Diesel
PTO HP140 HP @ 540/1000 RPM
TransmissionFull Powershift, 18F/6R
Hydraulics29 GPM, 3 remotes
3-Point HitchCategory II/III, 8500 lbs lift capacity
Fuel Capacity74 gallons
Weight16,700 lbs
Years Produced1997-2002

MX170 Maintenance Tips

  • Check the engine oil level daily and change the oil and filter every 250 hours of operation using the recommended oil type (e.g., 15W-40).
  • Inspect hydraulic fluid levels regularly and replace the hydraulic filter every 500 hours to prevent contamination and ensure optimal hydraulic system performance.
  • Use a fuel conditioner regularly, especially during cold weather, to prevent fuel gelling and maintain the fuel system; also, drain the fuel/water separator frequently.
  • Before seasonal storage, fill the fuel tank to prevent condensation, change engine oil, lubricate all grease fittings, and disconnect the battery to prevent discharge.

MX170 History & Background

The Case IH MX170 was launched in 1997 as part of the MX series, replacing earlier models in the Case IH lineup. It represented a step forward in tractor design, offering increased power, improved hydraulics, and enhanced operator comfort. The MX170 became a popular model during its production run due to its reliability and versatility in various agricultural applications.

Frequently Asked Questions

Which replacement starter fits the Case IH MX170?

The recommended replacement starter for the MX170 is 114799A1 - Starter, Bosch.

Which locking fuel cap is available for the Case IH MX170?

A locking fuel cap option for the MX170 is the 84602136 - Cap, Fuel, Locking w/ 2 Keys.

What replacement alternator is recommended for the Case IH MX170?

For the Case IH MX170, the A187873 - ALTERNATOR is a recommended replacement.

Showing 1-24 of 258 products
ZP0750125010 - Ball Joint

ZP0750125010 - Ball Joint

SKU: ZP0750125010

$91.36

303 in stock

N14377 - Cylinder End

N14377 - Cylinder End

SKU: N14377

$91.36

303 in stock

A145857 - Tie Rod Wedge

A145857 - Tie Rod Wedge

SKU: A145857

$4.78

27 in stock

9968017 - Zinc 8.8 M24X1.5 MFD Steering Cylinder RH Thread Jam Nut

9968017 - Zinc 8.8 M24X1.5 MFD Steering Cylinder RH Thread Jam Nut

SKU: 9968017

$16.86

31 in stock

86502997 - Tie Rod

86502997 - Tie Rod

SKU: 86502997

$61.93

14 in stock

44995098 - Wheel Seal

44995098 - Wheel Seal

SKU: 44995098

$21.99

198 in stock

247523A1 - Ball Joint Assembly

247523A1 - Ball Joint Assembly

SKU: 247523A1

$99.56

21 in stock

1280662C1 - Long; 2WD Tie Rod

1280662C1 - Long; 2WD Tie Rod

SKU: 1280662C1

$50.18

68 in stock

1280661C1 - Jam Nut (1-1/8" NF)

1280661C1 - Jam Nut (1-1/8" NF)

SKU: 1280661C1

$14.71

14 in stock

1280658C1 - Short; 2WD Tie Rod

1280658C1 - Short; 2WD Tie Rod

SKU: 1280658C1

$36.96

43 in stock

1280657C1 - Tie Rod; 2WD Tube

1280657C1 - Tie Rod; 2WD Tube

SKU: 1280657C1

$53.88

29 in stock

2852114 - Water Pump

2852114 - Water Pump

SKU: 2852114

$80.33

53 in stock

WL8313R - Hi / Low RH Flood / Spot Combo LED Headlight

WL8313R - Hi / Low RH Flood / Spot Combo LED Headlight

SKU: WL8313R

$179.46

233 in stock

WL8312L - Hi / Low Flood / Spot LH LED Headlight

WL8312L - Hi / Low Flood / Spot LH LED Headlight

SKU: WL8312L

$179.46

245 in stock

WL1205 - Side Mount Rectangle Flood LED Work Lamp

WL1205 - Side Mount Rectangle Flood LED Work Lamp

SKU: WL1205

$104.76

120 in stock

WL1200 - Rectangle Flood LED Work Lamp

WL1200 - Rectangle Flood LED Work Lamp

SKU: WL1200

$98.50

379 in stock

EAJ973 - 8" Adapter Harness

EAJ973 - 8" Adapter Harness

SKU: EAJ973

$9.26

40 in stock

E35556 - 10 Watt Dome Lamp; 12V Bulb

E35556 - 10 Watt Dome Lamp; 12V Bulb

SKU: E35556

$4.28

354 in stock

D71346 - Bulb

D71346 - Bulb

SKU: D71346

$2.14

497 in stock

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED

SKU: 9703399-LED

$19.84

288 in stock

87703630 - Amber LED Flasher/Tail Light Lamp

87703630 - Amber LED Flasher/Tail Light Lamp

SKU: 87703630

$61.89

88 in stock

87283179-LED - Replacement For H4 Bulb 600 Lumens Bulb; LED

87283179-LED - Replacement For H4 Bulb 600 Lumens Bulb; LED

SKU: 87283179-LED

$19.90

190 in stock

87283179 - Inner H4-12V Bulb

87283179 - Inner H4-12V Bulb

SKU: 87283179

$8.50

73 in stock

82018390 - Pipe Type Amber Rotating Beacon

82018390 - Pipe Type Amber Rotating Beacon

SKU: 82018390

$71.83

651 in stock
