Case IH MAXXUM-125 Tractor Parts
Shop Case IH MAXXUM-125 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.
The Case IH Maxxum 125 is a versatile agricultural tractor known for its reliability and performance in various farming applications. Manufactured from 2008-2015, it features a powerful FPT 6.7L diesel engine producing approximately 125 engine horsepower and around 105 PTO horsepower. Its robust design and advanced features made it a popular choice for farmers needing a capable and efficient machine.
About the MAXXUM 125
The Case IH Maxxum 125 tractor was part of the Maxxum series, introduced to provide farmers with a range of horsepower options in a mid-size utility tractor. Production spanned from 2008 to 2015. The engine is an FPT (Fiat Powertrain Technologies) 6.7-liter, 6-cylinder diesel engine, delivering around 125 horsepower. The engine's high torque output made it suitable for demanding tasks. Several transmission options were available, including a standard 16x16 semi-powershift transmission and an optional 17x16 transmission with auto field shift. PTO horsepower is approximately 105 hp, with both 540 and 1000 RPM options available. The hydraulic system capacity is around 29 GPM, with multiple remote valves for implement control. The 3-point hitch is a Category II or III, offering a lift capacity of approximately 9,400 lbs. Commonly used for row crop work, hay production, livestock operations, and light tillage, the Maxxum 125 stood out for its comfortable cab, ease of operation, and versatility compared to smaller utility tractors and larger row-crop tractors.
MAXXUM 125 Specifications
| Engine | FPT 6.7L 125 HP Diesel |
|---|---|
| PTO HP | 105 HP @ 540/1000 RPM |
| Transmission | Semi-Powershift 16x16 |
| Hydraulics | 29 GPM, 3 remotes |
| 3-Point Hitch | Category II/III, 9400 lbs |
| Fuel Capacity | 45 gallons |
| Weight | 13,500 lbs |
| Years Produced | 2008-2015 |
MAXXUM 125 Maintenance Tips
- Check and change the engine oil and filter every 250-300 hours using a high-quality oil that meets Case IH specifications.
- Regularly inspect hydraulic fluid levels and change the hydraulic filter every 500 hours to prevent contamination and maintain optimal performance.
- Use a fuel additive to prevent gelling during cold weather and inspect fuel filters regularly to ensure a clean fuel supply, as modern diesel engines are sensitive to fuel quality.
- Before seasonal storage, ensure the fuel tank is full to prevent condensation, grease all lubrication points, and disconnect the battery to prevent drain.
MAXXUM 125 History & Background
The Case IH Maxxum 125 was introduced in 2008 as part of the Maxxum series, offering a mid-range horsepower option for farmers. There were no major redesigns during its production run, making it a consistently reliable tractor in the Case IH lineup. Its popularity cemented the Maxxum name as a reliable workhorse in modern agriculture.
Frequently Asked Questions
Which fuel lift pump is suitable for the Maxxum 125?
For the Maxxum 125, the recommended fuel lift pump is 2830266 - Pump, Fuel Lift.
Which PTO shafts are available for the Maxxum 125?
The Maxxum 125 can use a 47130743 - Shaft, PTO (540 RPM) for standard applications, or a 47132584 - Shaft, PTO; 1000 RPM for implements requiring higher speeds.
Which hydraulic filter is recommended for the Maxxum 125?
A suitable hydraulic spin-on filter for the Maxxum 125 is 47131180 - Filter, Hydraulic; Spin On. This part is a direct replacement for previous numbers like 1931182 and 8186397.
What are some recommended maintenance and replacement parts for the Maxxum 125?
To keep your Maxxum 125 running smoothly, consider these essential replacement parts: 87726675 - Filter; Cab Air, J911572 - Belt, Fan, Alt, WP, 5197798 - Tie Rod Assembly, and 87391136 - Brake Band, PTO Clutch. Additionally, you might consider upgrading your lighting with a WL1078 - Work Lamp, LED, Flood, Rectangle or replacing worn seating with a MSG95GGRC-ASSY - Grammer Seat Assembly, CHARCOAL MATRIX CLOTH.

VPA4146 - Upper (L/ Head Gasket) Gasket Set
SKU: VPA4146
13 in stock

87395648 - MFWD Ball Joint
SKU: 87395648
52 in stock

87332622 - Tie Rod Assembly
SKU: 87332622
3 in stock

81863815 - Barrel End Steering Cylinder Ball Joint
SKU: 81863815
11 in stock

81863813 - Tie Rod
SKU: 81863813
31 in stock

5197798 - Tie Rod Assembly
SKU: 5197798
44 in stock

2852114 - Water Pump
SKU: 2852114
53 in stock

WL1078 - Rectangle Flood LED Work Lamp
SKU: WL1078
161 in stock

9703399-LED - Replaces Bulb #H3 1000 Lumens Bulb; LED
SKU: 9703399-LED
288 in stock

82018390 - Pipe Type Amber Rotating Beacon
SKU: 82018390
651 in stock

VPA4148 - Upper (L/ Head Gasket) Gasket Set
SKU: VPA4148
4 in stock

84277822 - HOOD STRUT
SKU: 84277822
27 in stock

87744542 - Rear Window Glass
SKU: 87744542
25 in stock

87566892 - LH Glass; Lower Front
SKU: 87566892
9 in stock

87566891 - RH Glass; Lower Front
SKU: 87566891
Out of stock

87560791 - Door (RH) Glass
SKU: 87560791
1 in stock

87560786 - Door (LH) Glass
SKU: 87560786
Out of stock

87304261 - LH Glass; Lower Front
SKU: 87304261
3 in stock

87304259 - RH Glass; Lower Front
SKU: 87304259
Out of stock

87304257 - Front Windshield Glass
SKU: 87304257
24 in stock

82036570 - HOOD STRUT
SKU: 82036570
19 in stock

82022486 - CAB GAS REAR WINDOW STRUT
SKU: 82022486
36 in stock

87391136 - PTO Clutch Brake Band
SKU: 87391136
74 in stock

87347166 - PTO Snap Ring
SKU: 87347166
315 in stock
