Case IH MAXXUM-115 Tractor Parts

MAXXUM 115 parts and accessories

The Case IH MAXXUM 115, manufactured from 2008-2015, is a versatile agricultural tractor powered by a dependable 115 HP diesel engine. Known for its excellent power-to-weight ratio and comfortable cab, the MAXXUM 115 quickly became a favorite among farmers for various tasks. With a PTO horsepower of around 95, it efficiently handles a wide range of implements.

The Case IH MAXXUM 115 tractor was part of the MAXXUM series, known for bridging the gap between utility and row crop tractors. Production years spanned from 2008 to 2015. It features a 6.7L FPT (Fiat Powertrain Technologies) diesel engine, delivering approximately 115 horsepower. This engine is a four-stroke, turbocharged, and intercooled diesel, known for its reliability and fuel efficiency. The transmission options varied, including a range of powershift transmissions offering speeds from 16x16 up to 24x24 with creeper options for specialized applications. PTO horsepower typically falls around 95 HP, with both 540 and 1000 RPM options available. The hydraulic system provides a robust flow, typically around 29 GPM, with 2 to 4 rear remotes. The three-point hitch is a Category II or III, offering a lift capacity around 7,200 lbs. The MAXXUM 115 found use in various applications, including row crop work, hay production, livestock operations, and general tillage. What distinguishes it from smaller tractors is its heavier build, higher horsepower, and advanced transmission options, making it capable of handling more demanding tasks than smaller utility tractors, while remaining more maneuverable and economical than larger row crop tractors.

Specifications

Engine	FPT 6.7L 115 HP Diesel
PTO HP	95 HP @ 540/1000 RPM
Transmission	Powershift 16x16 or 24x24
Hydraulics	29 GPM, 2-4 remotes
3-Point Hitch	Category II/III, 7,200 lbs
Fuel Capacity	45 gallons
Weight	12,500 lbs
Years Produced	2008-2015

Maintenance Tips

Check engine oil levels daily and change the oil and filter every 250 hours of operation, using the recommended oil type and filter for the FPT 6.7L engine.
Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and ensure optimal hydraulic performance.
Use a fuel additive to prevent fuel gelling and water accumulation, especially during colder months. Replace fuel filters according to the manufacturer's recommendations.
Before storing the tractor for extended periods, completely fill the fuel tank, add a fuel stabilizer, and disconnect the battery to prevent corrosion and ensure easy starting when brought back into service.

History & Background

The Case IH MAXXUM 115 was introduced as part of the updated MAXXUM series, aiming to provide a balance of power and versatility for mid-sized farming operations. It incorporated advancements in engine technology and transmission options compared to previous models. The MAXXUM 115 became a popular choice due to its reliability and adaptability to various agricultural tasks, contributing to the continued success of the MAXXUM tractor line.

Frequently Asked Questions

What engine is in the Case Ih MAXXUM 115?

The Case IH MAXXUM 115 is equipped with a 6.7L FPT (Fiat Powertrain Technologies) diesel engine producing approximately 115 horsepower.

What is the PTO horsepower on a MAXXUM 115?

The PTO horsepower on a Case IH MAXXUM 115 is approximately 95 HP. It offers both 540 and 1000 RPM PTO speed options.

What oil filter fits the MAXXUM 115?

The Case IH MAXXUM 115 typically uses a Case IH oil filter part number 84221273. Cross-references include Fleetguard LF16010 and Baldwin B7377.

What are common parts needed for the MAXXUM 115?

Common parts needed for the Case IH MAXXUM 115 include engine oil filters, fuel filters, hydraulic filters, belts, hydraulic seals, steering components, clutch parts (if applicable), and various sensors.
