Case IH MAGNUM-210 Tractor Parts

MAGNUM 210 parts and accessories

The Case IH Magnum 210 tractor, manufactured from 2006 to 2010, offered farmers a robust and reliable workhorse. Powered by a 210 HP Case IH engine, it delivered ample power for a variety of tasks. With a PTO horsepower of around 175 HP, the Magnum 210 became popular due to its versatility and solid performance in diverse agricultural applications.

The Case IH Magnum 210 was part of the Magnum series, known for its blend of power and operator comfort. Production ran from 2006 to 2010. Under the hood, it features a Case IH 6.7L 6-cylinder diesel engine producing a rated 210 horsepower. The engine's displacement is 408 cubic inches. Transmission options included a full powershift transmission, offering smooth gear changes on the go, typically with 18 forward and 4 reverse speeds. The rear PTO delivers approximately 175 horsepower and offers both 540 and 1000 RPM speeds. The hydraulic system boasts a flow rate around 40 GPM, providing ample power for implements, and often includes 3-4 remote valves. A Category III 3-point hitch with a lift capacity exceeding 9,500 lbs allows for handling a wide range of implements. The Magnum 210 was commonly used for row crop operations, hay production, livestock farming, and tillage. It distinguished itself from smaller models with its increased horsepower and hydraulic capacity, while offering a more economical alternative to larger Magnums.

Specifications

Engine	Case IH 6.7L 210 HP Diesel
PTO HP	175 HP @ 540/1000 RPM
Transmission	Full Powershift 18F/4R
Hydraulics	40 GPM, 3-4 remotes
3-Point Hitch	Category III, 9,500 lbs lift
Fuel Capacity	100 gallons
Weight	18,500 lbs
Years Produced	2006-2010

Maintenance Tips

Engine Oil and Filter: Change the engine oil and filter every 250-300 hours using a high-quality oil that meets Case IH specifications. Inspect the oil regularly for contamination.
Hydraulic System: Check the hydraulic fluid level regularly and change the hydraulic filters every 500 hours. Use only Case IH approved hydraulic fluid to avoid damage to the system.
Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter every 500 hours. Drain any water from the fuel tank regularly to prevent fuel system problems.
Seasonal Storage: Before storing the tractor for the winter, fill the fuel tank to prevent condensation, change the engine oil and filter, grease all fittings, and disconnect the battery. Store in a dry location.

History & Background

The Case IH Magnum 210 was introduced in 2006 as part of a refreshed Magnum series, building on the legacy of the original Magnum tractors. It offered improved engine technology and comfort features. The Magnum series as a whole has been a significant contributor to modern agriculture, providing farmers with reliable and powerful tractors for decades.

Frequently Asked Questions

What engine is in the Case Ih MAGNUM 210?

The Case IH Magnum 210 is equipped with a Case IH 6.7L 6-cylinder turbocharged diesel engine producing 210 horsepower.

What is the PTO horsepower on a MAGNUM 210?

The Case IH Magnum 210 PTO horsepower is approximately 175 HP, and it offers both 540 and 1000 RPM PTO speeds.

What oil filter fits the MAGNUM 210?

The recommended oil filter for the Case IH Magnum 210 is a Case IH filter part number 87803420. Common cross-references include Wix 57202, and Baldwin B7377.

What are common parts needed for the MAGNUM 210?

Common wear parts for the Case IH Magnum 210 include engine oil filters, fuel filters, hydraulic filters, air filters, fan belts, hydraulic seals, steering components, and clutch parts. Maintaining these parts ensures optimal performance and longevity.
