Case IH HYDRO-86 Tractor Parts
Replacement parts for the Case IH HYDRO-86 Tractor. Browse our selection of OEM and aftermarket parts — filters, belts, hydraulics, electrical, and more.
The Case IH Hydro 86 was a popular tractor manufactured from 1981 to 1984, known for its smooth hydrostatic transmission. Powered by a reliable 82 HP diesel engine, it delivered approximately 68 PTO horsepower. Farmers appreciated its ease of use and versatility in various agricultural tasks, making it a valuable asset for row crop and livestock operations.
About the Hydro 86
The Case IH Hydro 86, produced between 1981 and 1984, was part of the 86 series, known for their advancements in operator comfort and efficiency. It featured an International Harvester (IH) D-358 5.9L 6-cylinder diesel engine, producing approximately 82 engine horsepower. This engine's displacement ensured ample power for a variety of tasks. A key feature was its hydrostatic transmission, offering infinite speed control and ease of operation, a departure from traditional gear-driven tractors. The Hydro 86 provided approximately 68 PTO horsepower, available in the standard 540 RPM configuration. Its hydraulic system delivered around 15 GPM of flow, with typically two remote valves for implements. The 3-point hitch was a Category II, offering a lift capacity of around 4,700 lbs. Common applications included row crop work like planting and cultivating, hay baling and moving, livestock feeding and manure handling, and light tillage. Compared to gear-driven 86 series tractors, the Hydro 86 offered superior ease of use, especially for tasks requiring frequent speed changes or precise control. However, it sometimes lacked the raw pulling power of its gear-driven counterparts in very heavy tillage applications.
Hydro 86 Specifications
| Engine | International Harvester D-358 82 HP 5.9L Diesel |
|---|---|
| PTO HP | 68 HP @ 540 RPM |
| Transmission | Hydrostatic Infinite speeds |
| Hydraulics | 15 GPM, 2 remotes |
| 3-Point Hitch | Category II, 4700 lbs |
| Fuel Capacity | 30 gallons |
| Weight | 8,100 lbs |
| Years Produced | 1981-1984 |
Hydro 86 Maintenance Tips
- Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using a high-quality diesel engine oil that meets API CH-4 or better specifications.
- Hydraulic System Maintenance: Check the hydraulic fluid level regularly and change the hydraulic filters every 500 hours of operation. Use only fluids meeting Case IH specifications to prevent damage to the hydrostatic transmission.
- Fuel System Care: Use clean, high-quality diesel fuel and replace the fuel filters every 250 hours to prevent fuel system problems. Consider using a fuel additive to prevent gelling in cold weather.
- Seasonal Storage: Before storing the tractor for the off-season, completely fill the fuel tank to prevent condensation. Change the engine oil and filter, grease all fittings, and disconnect the battery. Store the tractor in a dry location to prevent rust and corrosion.
Hydro 86 History & Background
The Case IH Hydro 86 was introduced in 1981 as part of the IH 86 series, offering a hydrostatic transmission option for increased ease of use. It represented a significant step forward in tractor technology, providing farmers with a more user-friendly and efficient machine for various agricultural applications. While it was only produced for a few years, it remains a sought-after tractor for its unique capabilities.
Frequently Asked Questions
Which water pump fits the Case IH Hydro 86?
The 673162C1 - WATER PUMP is a direct replacement for the Case IH Hydro 86.
What replacement alternator is available for the Hydro 86?
A reliable replacement alternator for the Hydro 86 is the 1103184 - Alternator, Delco.
What oil filter fits the Hydro 86?
For the Hydro 86, the LF3316 - Filter, Lube, Full-Flow Spin-On (QTY 12) is a suitable replacement.
What are common parts needed for the Hydro 86?
Common wear items for the Hydro 86 include the LF3316 - Filter, Lube, Full-Flow Spin-On (QTY 12), FF5019 - Filter, Fuel, Spin-On (QTY 12), 384006R92 - Tie Rod, Inner, 359984R93 - Tie Rod, Outer, and WBKIH3 - Wheel Bearing Kit.

VTK310 - Valve Train Kit
SKU: VTK310
Out of stock

VTK291 - Valve Train Kit
SKU: VTK291
2 in stock

SK445 - Piston Liner Kit
SKU: SK445
2 in stock

SRK724 - Liner Sealing Ring Kit
SKU: SRK724
20 in stock

SD602 - Cylinder Liner
SKU: SD602
7 in stock

671806C1 - Tach Drive
SKU: 671806C1
65 in stock

383917R1 - Tube
SKU: 383917R1
238 in stock

359986R1 - Clamp
SKU: 359986R1
340 in stock

359984R1 - outer Ref 13 - Tie rod
SKU: 359984R1
415 in stock

223313 - Complete Tie Rod Assembly
SKU: 223313
349 in stock

LM603049-I - Tapered Roller Bearing Cone
SKU: LM603049-I
336 in stock

LM603011-I - Tapered Bearing Cup
SKU: LM603011-I
94 in stock

LM48548-I - Tapered Roller Bearing Cone
SKU: LM48548-I
794 in stock

LM48510-I - Tapered Bearing Cup
SKU: LM48510-I
340 in stock

WL7610 - Trapezoid LED Light Assembly
SKU: WL7610
98 in stock

WL7606 - Flood LED Light Assembly
SKU: WL7606
92 in stock

WL2116 - 4 1/2" Diameter Trapezoid LED Sealed Beam
SKU: WL2116
341 in stock

WL1116 - 4 1/2" Diameter Flood LED Sealed Beam
SKU: WL1116
1157 in stock

C5NN13N359E - Warning Lamp / Turn Signal (12 Volt)
SKU: C5NN13N359E
96 in stock

A42294 - Sealed Beam Bulb (12 Volt)
SKU: A42294
340 in stock

87271837 - Flasher Control Switch
SKU: 87271837
390 in stock

373662R1 - Sealed Beam Bulb (12 Volt)
SKU: 373662R1
246 in stock

130609 - AMBER FL LIGHT
SKU: 130609
96 in stock

OK310 - Major Engine Overhaul Kit
SKU: OK310
Out of stock
