Case IH HYDRO-186 Tractor Parts

Shop Case IH HYDRO-186 Tractor parts. From filters and fluids to blades and belts, we carry the replacements you need to keep running.

The Case IH Hydro 186, manufactured from 1971 to 1979, was a popular agricultural tractor known for its hydrostatic transmission. Powered by a 108 horsepower diesel engine, this tractor delivered approximately 95 PTO horsepower. Its efficient hydrostatic drive system provided farmers with precise control and ease of operation, making it a favorite for various field tasks.

About the Hydro 186

The Case IH Hydro 186 tractor was introduced in 1971 and remained in production until 1979. It was designed to offer enhanced operator control and efficiency through its hydrostatic transmission. The tractor is equipped with an International Harvester D358 5.9L 6-cylinder diesel engine, producing around 108 horsepower. Its hydrostatic transmission allowed for infinitely variable speeds, providing excellent control during field operations. The PTO horsepower is rated at 95 HP, and it features a 540 RPM PTO. The hydraulic system has a capacity of approximately 15.5 GPM, typically equipped with two remote valves. The 3-point hitch is a Category II, offering a lift capacity of around 4,800 lbs. Common applications for the Hydro 186 included row crop cultivation, hay baling, livestock operations, and light tillage work. What distinguished the Hydro 186 was its hydrostatic transmission, offering smoother operation and eliminating the need for manual gear shifting, setting it apart from other gear-driven tractors in the Case IH lineup.

Hydro 186 Specifications

EngineInternational Harvester D358 108 HP 5.9L Diesel
PTO HP95 HP @ 540 RPM
TransmissionHydrostatic Infinitely Variable
Hydraulics15.5 GPM, 2 remotes
3-Point HitchCategory II, 4800 lbs
Fuel Capacity34 gallons
Weight9,440 lbs
Years Produced1971-1979

Hydro 186 Maintenance Tips

  • Engine Oil & Filter: Change engine oil and filter every 250 hours using a high-quality diesel engine oil. Regularly inspect the oil level and condition.
  • Hydraulic System: Check hydraulic fluid levels and inspect for leaks regularly. Change hydraulic fluid and filter every 500 hours or as recommended by the manufacturer. Use the correct type of hydraulic fluid to prevent damage.
  • Fuel System: Use clean, high-quality diesel fuel. Replace fuel filters annually or every 250 hours. Drain water from the fuel tank regularly to prevent contamination and injector issues.
  • Seasonal Storage: Before storing the tractor for the winter, stabilize the fuel, change engine oil and filter, grease all fittings, and disconnect the battery. Store the tractor in a dry location.

Hydro 186 History & Background

The Case IH Hydro 186 was introduced in 1971 as part of the International Harvester's (later Case IH) commitment to innovative tractor technology. This model stood out due to its hydrostatic transmission, offering a distinct advantage in control and ease of use. The Hydro 186 played a significant role in the evolution of tractor design, showcasing the benefits of hydrostatic drive in agricultural applications.

Frequently Asked Questions

Which water pump fits the Case IH Hydro 186?

The 673162C1 - WATER PUMP is a direct replacement for the Case IH Hydro 186.

What dust boot is used for the PTO control on the Hydro 186?

The 393071R2 - BOOT, DUST; IND. PTO CTRL. / DIFF. LOCK is suitable for the PTO control and differential lock on the Hydro 186.

What oil filter fits the Hydro 186?

A recommended full-flow spin-on lube filter for the Hydro 186 is the LF3316 - Filter, Lube, Full-Flow Spin-On.

What are common parts needed for the Hydro 186?

Showing 1-24 of 332 products
671806C1 - Tach Drive

671806C1 - Tach Drive

SKU: 671806C1

$121.75

65 in stock

71816C91 - Center Axle
Out of Stock

71816C91 - Center Axle

SKU: 71816C91

$1379.44

Out of stock

531851R1 - Front Axle Clamp Pin
Out of Stock

531851R1 - Front Axle Clamp Pin

SKU: 531851R1

$30.94

Out of stock

531260R92 - w/ Bushings Knee

531260R92 - w/ Bushings Knee

SKU: 531260R92

$346.28

91 in stock

39-5698 - Pivot Pin Retaining Pin
Out of Stock

39-5698 - Pivot Pin Retaining Pin

SKU: 39-5698

$3.72

Out of stock

384006R1 - inner Ref 12 - Tie rod

384006R1 - inner Ref 12 - Tie rod

SKU: 384006R1

$21.51

499 in stock

383917R1 - Tube

383917R1 - Tube

SKU: 383917R1

$49.47

238 in stock

374062R1 - Jam Nut

374062R1 - Jam Nut

SKU: 374062R1

$9.51

350 in stock

359986R1 - Clamp

359986R1 - Clamp

SKU: 359986R1

$3.90

340 in stock

359984R1 - outer Ref 13 - Tie rod

359984R1 - outer Ref 13 - Tie rod

SKU: 359984R1

$41.01

415 in stock

223313 - Complete Tie Rod Assembly

223313 - Complete Tie Rod Assembly

SKU: 223313

$95.46

349 in stock

LM603049-I - Tapered Roller Bearing Cone

LM603049-I - Tapered Roller Bearing Cone

SKU: LM603049-I

$11.19

336 in stock

LM603011-I - Tapered Bearing Cup

LM603011-I - Tapered Bearing Cup

SKU: LM603011-I

$6.03

94 in stock

LM48548-I - Tapered Roller Bearing Cone

LM48548-I - Tapered Roller Bearing Cone

SKU: LM48548-I

$7.90

794 in stock

LM48510-I - Tapered Bearing Cup

LM48510-I - Tapered Bearing Cup

SKU: LM48510-I

$3.38

340 in stock

WL7610 - Trapezoid LED Light Assembly

WL7610 - Trapezoid LED Light Assembly

SKU: WL7610

$102.38

98 in stock

WL7606 - Flood LED Light Assembly

WL7606 - Flood LED Light Assembly

SKU: WL7606

$102.38

92 in stock

WL2116 - 4 1/2" Diameter Trapezoid LED Sealed Beam

WL2116 - 4 1/2" Diameter Trapezoid LED Sealed Beam

SKU: WL2116

$83.35

341 in stock

WL1116 - 4 1/2" Diameter Flood LED Sealed Beam

WL1116 - 4 1/2" Diameter Flood LED Sealed Beam

SKU: WL1116

$70.46

1157 in stock

A42294 - Sealed Beam Bulb (12 Volt)

A42294 - Sealed Beam Bulb (12 Volt)

SKU: A42294

$14.49

340 in stock

87703630 - Amber LED Flasher/Tail Light Lamp

87703630 - Amber LED Flasher/Tail Light Lamp

SKU: 87703630

$61.89

88 in stock

87271837 - Flasher Control Switch

87271837 - Flasher Control Switch

SKU: 87271837

$77.54

390 in stock

373662R1 - Sealed Beam Bulb (12 Volt)

373662R1 - Sealed Beam Bulb (12 Volt)

SKU: 373662R1

$11.28

246 in stock

OK505 - Major Engine Overhaul Kit
Out of Stock

OK505 - Major Engine Overhaul Kit

SKU: OK505

$2046.78

Out of stock
