Case IH 970 Tractor Parts
Find parts for your Case IH 970 Tractor. We stock OEM and quality aftermarket replacements ready to ship.
The Case IH 970 tractor, manufactured from 1971 to 1976, was a reliable workhorse on farms across North America. Powered by a robust 401 cubic inch diesel engine producing around 100 horsepower and delivering approximately 84 PTO horsepower, the 970 gained popularity for its pulling power and dependability. Farmers appreciated its straightforward design and suitability for a wide range of tasks.
About the 970
The Case IH 970 was introduced in 1971 as part of the '70 Series' line, replacing earlier International Harvester models. Production continued until 1976. Its engine was a 401 cubic inch International Harvester inline 6-cylinder diesel engine producing approximately 100 engine horsepower. A gasoline version was also available, though less common. The 970 came standard with a gear-drive transmission offering 8 forward and 4 reverse speeds. PTO horsepower was rated at approximately 84, available in either 540 or 1000 RPM configurations depending on the model configuration. The hydraulic system delivered around 15 gallons per minute to power implements and steering. It featured a Category II 3-point hitch, capable of lifting around 5,800 pounds. The 970 was commonly used for row crop operations, hay production, livestock feeding, and light tillage work. What set it apart was its balance of power and simplicity; it provided a substantial upgrade in horsepower over smaller models while remaining relatively easy to maintain and operate compared to some of the larger, more complex tractors of the time.
970 Specifications
| Engine | International Harvester 100 HP 401 ci Diesel |
|---|---|
| PTO HP | 84 HP @ 540/1000 RPM |
| Transmission | Gear Drive 8 Forward, 4 Reverse |
| Hydraulics | 15 GPM, 2 remotes |
| 3-Point Hitch | Category II, 5800 lbs |
| Fuel Capacity | 36 gallons |
| Weight | 9,870 lbs |
| Years Produced | 1971-1976 |
970 Maintenance Tips
- Change engine oil and filter every 250 hours of operation using a high-quality oil meeting the specifications recommended in your operator's manual.
- Regularly check the hydraulic fluid level and condition. Change hydraulic filters according to the manufacturer's recommendations, typically every 500 hours, to prevent contamination and maintain optimal performance.
- Inspect the fuel system for leaks and ensure the fuel filter is clean to prevent fuel starvation and maintain efficient engine operation. Treat fuel with stabilizer during seasonal storage.
- Before storing your tractor for the off-season, drain the fuel tank or add a fuel stabilizer to prevent fuel degradation and rust formation in the fuel system. Also, grease all fittings and disconnect the battery or use a battery maintainer.
970 History & Background
The Case IH 970 was launched in 1971 as part of a new generation of tractors from International Harvester, later Case IH. It was designed to offer farmers a mid-range horsepower option with improved performance and features. While not undergoing major redesigns during its production run, it served as a popular and reliable tractor that helped shape the company's product line.
Frequently Asked Questions
Which thermostat is recommended for the Case IH 970?
The 3042303R1 - Thermostat (180°) is a suitable replacement for the Case IH 970.
Which PTO clutch drive plate fits the Case IH 970?
The A66364 - PTO CLUTCH DRIVE PLATE is designed for the Case IH 970 models.
Which brake disc is suitable for the Case IH 970?
The 1975469C1 - Brake Disc is a recommended replacement for the Case IH 970.
What are common parts needed for the 970?
Common replacement parts for the Case IH 970 include the A57250 - Seal, A44762 - Tie Rod End (RH Thread), Short, 1981280C1 - Clutch Plate, Sintered, A155461 - Plate, Clutch (Steel), A47044 - Alternator, Delco, and the WF2071 - Filter, Water, Spin-On for routine maintenance.

SK470 - Piston Liner Kit
SKU: SK470
13 in stock

B93222 - Wheel Bearing Kit
SKU: B93222
18 in stock

A59659 - Tube
SKU: A59659
233 in stock

A44762 - Short Tie Rod End (RH Thread)
SKU: A44762
Out of stock

A41561 - Clamp w/ Hardware
SKU: A41561
240 in stock

A41511 - Jam Nut
SKU: A41511
350 in stock

A143028 - 8 Notches Long Tie Rod End
SKU: A143028
5 in stock

112201 - Tie Rod Assembly
SKU: 112201
33 in stock

WL3005 - Combo LED Sealed Beam
SKU: WL3005
58 in stock

C5NN13N359E - Warning Lamp / Turn Signal (12 Volt)
SKU: C5NN13N359E
96 in stock

A42294 - Sealed Beam Bulb (12 Volt)
SKU: A42294
340 in stock

87271837 - Flasher Control Switch
SKU: 87271837
390 in stock

529068 - Bulb
SKU: 529068
115 in stock

373662R1 - Sealed Beam Bulb (12 Volt)
SKU: 373662R1
246 in stock

371461R92 - Sealed Beam; Rear Work Lamp (12V) 4409X Floodlamp
SKU: 371461R92
200 in stock

130609 - AMBER FL LIGHT
SKU: 130609
96 in stock

1156L24 - Replaces Bulb #1156 (2 Pack) 2400 Lumens LED Bulb
SKU: 1156L24
56 in stock

1156-LED - Replaces Bulb #1156 (2 Pack) LED; 600 Lumens Bulb
SKU: 1156-LED
127 in stock

F64499 - Rear Window Seal
SKU: F64499
7 in stock

F63925 - Inner Chrome Handle
SKU: F63925
1 in stock

CFM360 - Floor Mat
SKU: CFM360
49 in stock

A42677X - Window Seal
SKU: A42677X
5 in stock

A66365 - PTO Clutch Driven Plate
SKU: A66365
1042 in stock

A66364 - PTO CLUTCH DRIVE PLATE
SKU: A66364
777 in stock
