Case IH 9170 Tractor Parts

9170 parts and accessories

The Case IH 9170 tractor, manufactured from 1988 to 1993, was a powerful workhorse on farms across North America. Powered by a Cummins N14 diesel engine producing around 330 horsepower, and boasting a robust PTO, the 9170 quickly became known for its reliability and ability to handle demanding tasks. Its popularity stemmed from its size, power and durability.

The Case IH 9170 was part of the 90 series tractor lineup, produced from 1988 to 1993. This model was designed to offer high horsepower and improved productivity to meet the evolving demands of modern farming operations. At its heart, the 9170 features a Cummins N14 inline 6-cylinder diesel engine. This engine, displacing 855 cubic inches (14.0 L), delivered approximately 330 engine horsepower. The 9170 came standard with a 12-speed partial power shift transmission, providing a wide range of speeds to match various field conditions. The independent PTO system offered both 540 and 1000 RPM options. Its hydraulic system delivered around 38 GPM of flow, allowing for the operation of multiple implements simultaneously. Equipped with a Category III 3-point hitch, the 9170 could handle a variety of implements used in row crop farming, tillage, and livestock operations. This model was particularly adept at heavy tillage, pulling large planters, and powering large hay balers. The 9170 distinguished itself from other models in the Case IH lineup with its high horsepower and heavy-duty construction, making it suitable for larger farms and more demanding tasks.

Specifications

Engine	Cummins N14 330 HP 855 ci Diesel
PTO HP	265 HP @ 1000 RPM
Transmission	Partial Power Shift 12-Speed
Hydraulics	38 GPM, 4 remotes
3-Point Hitch	Category III, 8,444 lbs
Fuel Capacity	185 gallons
Weight	23,148 lbs
Years Produced	1988-1993

Maintenance Tips

Change engine oil and filter every 250-300 hours of operation using the recommended oil type.
Regularly inspect hydraulic fluid levels and filters, replacing filters according to the manufacturer's recommendations. Check for leaks and address them promptly to prevent system damage.
Use high-quality fuel and ensure the fuel system is free of contaminants. Change fuel filters as recommended. Consider using a fuel additive for winter storage.
Before seasonal storage, thoroughly clean the tractor, change all fluids and filters, and protect exposed metal parts with a rust inhibitor. Store indoors if possible to prevent weather damage.

History & Background

The Case IH 9170 was introduced in 1988 as part of the 90 series tractors, representing a leap in power and technology for Case IH. It filled a crucial gap in the market for farmers needing a robust, high-horsepower tractor, and remains a significant model in the history of large agricultural equipment.

Frequently Asked Questions

What engine is in the Case Ih 9170?

The Case IH 9170 is powered by a Cummins N14 inline 6-cylinder diesel engine, producing approximately 330 horsepower with a displacement of 855 cubic inches (14.0 liters).

What is the PTO horsepower on a 9170?

The Case IH 9170 has a PTO horsepower rating of approximately 265 HP. It offers both 540 and 1000 RPM PTO options for versatile implement compatibility.

What oil filter fits the 9170?

The Case IH 9170 typically uses a Fleetguard LF3349 or a Wix 51791 oil filter. Cross-references include Fram PH3985 and Baldwin B1441. Always verify compatibility with your specific engine and model year.

What are common parts needed for the 9170?

Common parts needed for the Case IH 9170 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, radiator hoses, hydraulic seals, steering components, clutch discs, and various wear parts associated with tillage implements.
