Case IH 9130 Tractor Parts

Find parts for your Case IH 9130 Tractor. We stock OEM and quality aftermarket replacements ready to ship.

The Case IH 9130 tractor, manufactured from 1987 to 1993, was a powerful and versatile workhorse on farms across North America. Powered by a Cummins 6CT8.3 210 HP diesel engine, its robust design and ample 170 PTO horsepower made it a popular choice for demanding tillage and planting operations. Farmers appreciated its reliability and ability to handle large implements.

About the 9130

The Case IH 9130 was introduced in 1987 as part of the 90 Series tractor lineup, replacing earlier models and offering enhanced power and performance. Its heart is a Cummins 6CT8.3 inline 6-cylinder diesel engine, producing approximately 210 horsepower. This engine boasts a displacement of 505 cubic inches (8.3 liters) and provides reliable power for various agricultural tasks. The 9130 primarily featured a 20-speed manual transmission with partial power shift, providing a wide range of speeds for optimal field operation. The tractor delivers 170 PTO horsepower, offering both 540 and 1000 RPM PTO speeds, increasing implement versatility. With a hydraulic flow rate of around 30 GPM and typically equipped with 3 remote valves, the 9130 offered substantial hydraulic power for operating implements like planters and cultivators. The 3-point hitch is a Category II, providing a lift capacity of approximately 8,500 lbs. Common applications included row crop farming, hay production, livestock operations, and primary tillage. The 9130 distinguished itself through its powerful engine and robust transmission, offering farmers a reliable platform for diverse agricultural tasks.

9130 Specifications

EngineCummins 6CT8.3 210 HP Diesel
PTO HP170 HP @ 1000 RPM
Transmission20-speed Partial Power Shift
Hydraulics30 GPM, 3 remotes
3-Point HitchCategory II, 8500 lbs
Fuel Capacity100 gallons
Weight19,500 lbs
Years Produced1987-1993

9130 Maintenance Tips

  • Engine Oil & Filter: Change engine oil and filter every 250 hours using the recommended grade oil for your climate. Regular changes prevent excessive wear.
  • Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Use only recommended hydraulic fluid to prevent damage to seals and components.
  • Fuel System: Use a fuel conditioner additive, especially during colder months, to prevent fuel gelling and maintain optimal fuel system performance. Replace the fuel filter every year.
  • Seasonal Storage: Before storing the tractor for the off-season, completely fill the fuel tank to prevent condensation and rust. Disconnect the battery and store it in a cool, dry place.

9130 History & Background

Introduced in 1987, the Case IH 9130 was part of the 90 Series, designed to offer farmers increased power and efficiency. This series filled a crucial need for larger farms requiring versatile tractors that could handle a variety of demanding tasks. While the 9130 didn't undergo major redesigns during its production run, it remains a respected tractor in agricultural history for its reliability and performance.

Frequently Asked Questions

Which water pump fits the Case IH 9130 tractor?

For the Case IH 9130, the J802975 - Pump, Water is a suitable replacement.

What friction disc is recommended for the PTO clutch on a Case IH 9130?

The 33-1518T2 - Friction Disc, Input / 2nd / PTO Clutch is an ideal component for the PTO clutch in the Case IH 9130.

What oil filter fits the 9130?

A recommended oil filter for the Case IH 9130 is the LF734 - Filter, Lube, Full-Flow Spin-On.

What are common wear parts for the Case IH 9130?

Showing 1-24 of 203 products
2852114 - Water Pump

2852114 - Water Pump

SKU: 2852114

$80.33

53 in stock

WL9325KT - 10 Lights LED Light Kit

WL9325KT - 10 Lights LED Light Kit

SKU: WL9325KT

$1039.32

7 in stock

WL1200 - Rectangle Flood LED Work Lamp

WL1200 - Rectangle Flood LED Work Lamp

SKU: WL1200

$98.50

379 in stock

WL1035 - Flood Hi/Lo Beam LED Sealed Beam

WL1035 - Flood Hi/Lo Beam LED Sealed Beam

SKU: WL1035

$128.53

121 in stock

EAJ973 - 8" Adapter Harness

EAJ973 - 8" Adapter Harness

SKU: EAJ973

$9.26

40 in stock

E35556 - 10 Watt Dome Lamp; 12V Bulb

E35556 - 10 Watt Dome Lamp; 12V Bulb

SKU: E35556

$4.28

354 in stock

D71346 - Bulb

D71346 - Bulb

SKU: D71346

$2.14

497 in stock

529068 - Bulb

529068 - Bulb

SKU: 529068

$2.83

115 in stock

22-665T1 - LED Amber Flasher / Turn Signal Lamp

22-665T1 - LED Amber Flasher / Turn Signal Lamp

SKU: 22-665T1

$44.00

431 in stock

1157L24 - Replaces Bulb #1157 (2 Pack) 2400 Lumens LED Bulb

1157L24 - Replaces Bulb #1157 (2 Pack) 2400 Lumens LED Bulb

SKU: 1157L24

$37.00

121 in stock

1156L24 - Replaces Bulb #1156 (2 Pack) 2400 Lumens LED Bulb

1156L24 - Replaces Bulb #1156 (2 Pack) 2400 Lumens LED Bulb

SKU: 1156L24

$37.57

56 in stock

1156-LED - Replaces Bulb #1156 (2 Pack) LED; 600 Lumens Bulb

1156-LED - Replaces Bulb #1156 (2 Pack) LED; 600 Lumens Bulb

SKU: 1156-LED

$14.49

127 in stock

A185714 - Gas Strut

A185714 - Gas Strut

SKU: A185714

$23.69

366 in stock

9706806 - Cab Door (RH/LH) Gas Strut

9706806 - Cab Door (RH/LH) Gas Strut

SKU: 9706806

$23.69

366 in stock

1280263C1 - Door Strut

1280263C1 - Door Strut

SKU: 1280263C1

$23.69

378 in stock

A61195 - O-Ring

A61195 - O-Ring

SKU: A61195

$1.97

319 in stock

98370C2 - Expansion Valve (block type)

98370C2 - Expansion Valve (block type)

SKU: 98370C2

$33.96

83 in stock

87033212 - Expansion Valve (block type)

87033212 - Expansion Valve (block type)

SKU: 87033212

$35.07

79 in stock

605880T1 - Expansion Valve

605880T1 - Expansion Valve

SKU: 605880T1

$33.96

83 in stock

605818T2 - Receiver Drier

605818T2 - Receiver Drier

SKU: 605818T2

$53.76

7 in stock

604087T1 - Expansion Valve

604087T1 - Expansion Valve

SKU: 604087T1

$33.96

83 in stock

602921T94-R - Sanden Style w/ Clutch (9103) Re-mfg Compressor

602921T94-R - Sanden Style w/ Clutch (9103) Re-mfg Compressor

SKU: 602921T94-R

$269.58

24 in stock

602921T94 - Sanden Style w/ Clutch (9103) New Compressor

602921T94 - Sanden Style w/ Clutch (9103) New Compressor

SKU: 602921T94

$269.58

24 in stock

60-5880T1 - Expan.Valve

60-5880T1 - Expan.Valve

SKU: 60-5880T1

$35.07

79 in stock
